Muratec MFX-1330 Field Engineering Manual page 85

Memory Switch 23 - Reception
Initial
Switch
Setting
7 0 Factory use only
6 0 V.34 reception
0: Yes
1: No
5 0 Factory use only
4 0 Factory use only
3 0 Factory use only
2 0 Factory use only
1 0 Factory use only
0 0 Factory use only
Memory Switch 24 ∼ 29 --- Factory use only
Memory Switch 30 - Modem
Initial
Switch
Setting
7 0 Number of HDLC end flags
6 0
5 1
4 0
3 0 Factory use only
2 0 Factory use only
1 0 Digital cable equalizer
0: Free
1: Hold
0 0 No use
Adjust
Individual setting for V.34 reception.
Adjust
Defines the number of HDLC end flags.
Switch 7 6 5 4
When set to "1", become efficient for the line short
break, but become weak for the line noise. It's
available only for communication at 14,400 or
12,000 bit/s.
3-57
Usage/Comments
Usage/Comments
0 0 0 0 1
0 0 0 1 2
0 0 1 0 3 Initial setting
0 0 1 1 4
0 1 0 0 5
0 1 0 1 6
0 1 1 0 7
0 1 1 1 8
1 0 0 0 9
1 0 0 1 10
1 0 1 0 11
1 0 1 1 12
1 1 0 0 13
1 1 0 1 14
1 1 1 0 15
1 1 1 1 16
