Muratec MFX-1330 Field Engineering Manual page 79

Memory Switch 02 ∼ 03 --- Factory use only
Memory Switch 04 - Dialer
Initial
Switch
Setting
7 0 Factory use only
6 0 Factory use only
5 0 Factory use only
4 0 Factory use only
3 1 DTMF attenuation
2 0
1 0
0 0
Memory Switch 04...DTMF attenuation
Switch -15 -14 -13
dB dB dB
3 1 1
2 1 1
1 1 1
0 1 0
Memory Switch 05 - Dialer
Initial
Switch
Setting
7 0 Factory use only
6 1 Ring signal detect time
5 1
4 0
3 0 Number of CI signal detection
in Fax/Tel Ready mode
0: Detect 1 time
1: Detect 2 times
2 0 Dual ring detection
0: No
1: Yes
1 0 Long ring detection
0: No
1: Yes
0 1 Frequency of the CI signal
detection
0: No
1: Yes
Memory Switch 06 ∼09 --- Factory use only
Adjust
-12 -11 -10 -9
dB dB dB dB
1 1 1 1 1
1 1 0 0 0
0 0 1 1 0
1 0 1 0 1
Adjust
Usage/Comments
See table below
Note: The setting of this switch is available only
when setting other than 0.
-8 -7 -6 -5
dB dB dB dB
1 0 0 0
0 1 1 1
0 1 1 0
0 1 0 1
Usage/Comments
Set the time that an incoming ring will not be detected
after hanging up. (Fax/Tel Ready mode only.)
Switch 6 5 4
0 0 0 100 ms
0 0 1 200 ms
0 1 0 300 ms
0 1 1 400 ms
1 0 0 500 ms
1 0 1 600 ms
1 1 0 700 ms
1 1 1 800 ms
Select the number of detection time of CI signal in the
Fax/Tel Ready mode or in the ringer silent mode.
Incoming calls are answered according to this setting
regardless of the number of rings chosen in the User
Settings.
When enabled, the machine is able to auto answer
an incoming ring with an off time of 120 - 60 ms.
Allows the machine to respond to an incoming ring
if the ring on time is longer than two seconds.
When disabled, the unit will not check the frequency of
the incoming CI signal.
3-51
-4 -3 -2 -1 -0
dB dB dB dB dB
0 0 0 0 0
1 0 0 0 0
0 1 1 0 0
0 1 0 1 0
