Muratec MFX-1330 Field Engineering Manual page 77

Memory Switch 00 - Dialer
Initial
Switch
Setting
7 0 Factory use only
6 0 Factory use only
5 0 CED detection condition
4 0
3 0 DIS detect time after dialing
0: 55 sec
1: 70 sec
2 1 CED detection
0: No
1: Yes
1 1 Dial tone detection
0: Do not dial
1: Dial
0 0 Phone line type for the first
phone line
0: PSTN
1: PBX
Adjust
Sets whether the detection should be strict or not.
Switch
Sets the time DIS signal is detected after dialing a
number.
Can be use to ignore CED detection if noise on the
telephone line is mistaken as a 2100 Hz CED
signal.
Determines if the machine proceeds with dialing or
indicates an error if no dial tone is detected within
five seconds of going off-hook.
When set to PSTN, the machine checks for dial
tone and acts according to the setting of memory
switch 00, bit 1. When set to PBX, the machine
always dials a given number of seconds after going
off-hook. Memory switch 001 sets the number of
seconds.
3-49
Usage/Comments
Normal
350ms 500ms 700ms 1000ms
5 0 0 1
4 0 1 0
Strict
1
1
