Muratec MFX-1330 Field Engineering Manual page 37

Machine Parameter 020
Initial
Switch
Setting
7 1 Mirror carriage standby
position adjustment
6 0
5 0
Adjusts the number of the
4 1
steps from the home sensor
3 0
of the mirror carriage OFF
2 1
to the standby position.
1 1
0 1
1 step = 0.0212 mm
Note: These values
are factory set and should
not be adjusted unless
instructed by a Muratec
technical representative.
Machine Parameter 021
Initial
Switch
Setting
7 0
Mirror carriage transfer mode
position adjustment
6 0
5 0
Adjusts the number of the
4 0
steps from the home sensor
3 0
of the mirror carriage OFF
2 0
to the transfer mode position.
1 0
0 0
1 step = 0.0212 mm
Machine Parameter 022 ∼ 024 --- Factory use only
Adjust
Switch 76543210
127steps 01111111
80 steps 01010000
50 steps 00110010
20 steps 00010100
10 steps 00001010
3 steps
2 steps
1 step
When Switch 7 is "1", it means " - ". For example,
"10000001" means "-0.14 mm".
Adjust
Switch 76543210
127steps 01111111
64 steps 01000000
:
32 steps 00100000
16 steps 00010000
8 steps
-8 steps
-16 steps 10010000
-32 steps 10100000
-64 steps 11000000
-127steps
3-9
Usage/Comments
Settings
+17.89 mm
:
+11.26 mm
:
+7.04 mm
:
+2.82 mm
:
+1.41 mm
:
00000011 +0.42 mm
00000010 +0.28 mm
00000001 +0.14 mm
00000000 9.15 mm
Usage/Comments
Settings
+2.70 mm
:
+1.36 mm
+0.68 mm
:
+0.34 mm
:
00001000 +0.17 mm
:
00000000 21.5 mm
:
10001000 -0.17 mm
:
-0.34 mm
:
-0.68mm
:
-1.36 mm
:
11111111 -2.70mm
Initial setting
