■ Others set mode

Calibration Marker
This item is used for a simple frequency check of the
transceiver.
See page 155 for calibration procedure.
Beep (Confirmation)
A beep sounds each time a switch is pushed to confirm
it. This function can be turned OFF for silent operation.
The beep output level can be set in the level set
mode. (p. 131)
Beep (Band Edge)
When you tune into or out of an amateur band's
fre quency range, a beep sounds. This functions
inde pendently of the confirmation beep setting (as
described above).
The beep output level can be set in the level set
mode. (p. 131)
When "ON (User)" or "ON (User) & TX Limit" is
selected, [BAND] appears in the display above the
function switch (F-5).
Up to 30 band edge frequencies can be
programmed in band edge screen.
(See page 35 for programming details.)

Beep Sound

Sets the desired beep frequency within 500 to
2000 Hz in 10 Hz steps. (default: 1000 Hz)
RF/SQL Control
The [RF/SQL] control can be set as the RF/squelch
control (default), the squelch control only (RF gain is
fixed at maximum) or 'Auto' (RF gain control in SSB,
CW, RTTY and PSK, squelch control in AM and FM).
See pages 2 and 37 for details. (default: RF+SQL)
TX Delay (HF)
If the transceiver transmits power before the external
device, such as a linear amplifier, is ready to
operate, the transmitted power will be reflected back
and can damage the transceiver. Therefore a time
delay can be set to delay the transceiver output until
the external device is ready.
OFF
• OFF : Calibration marker OFF (default)
• ON : Calibration marker ON
NOTE: Turn the calibration marker OFF after
checking the frequency of the transceiver.
ON
• OFF : Confirmation beep OFF
• ON : Confirmation beep ON (default)
ON (Default)
• OFF : Band edge beep is OFF
• ON (Default) : When you tune into or out of the
default amateur band's frequency
range, a beep sounds. (default)
• ON (User) : When you tune outside of, or back
into a user programmed amateur
band's frequency range, a beep
sounds.
• ON (User) & TX Limit
: When you tune outside of, or back
into a user programmed amateur
band's frequency range, a beep
sounds. Transmission is also inhibited
outside the programmed band.
1000Hz
RF+SQL
: [RF/SQL] control as RF gain control
• AUTO
in SSB, CW, RTTY and PSK, squelch
control in AM and FM
• SQL : [RF/SQL] control as squelch control
• RF+SQL : [RF/SQL] control as RF/squelch control
OFF
Set the TX delay time on the HF bands to 10, 15,
20, 25, or 30 milliseconds, or select "OFF" for no
delay time, depending on the needs of your external
device. (default: OFF)
☞
10
SET MODE
Continued on the next page.
