■ ACC set mode

USB Audio SQL
Sets the squelch condition of the USB audio which
is output from the [USB] (B) connector on the rear
panel.
The same audio signals are output from [USB] (B)
and the ACC sockets.
• The beep tones and the voice synthesizer
announcements are not output.
• The received audio output level cannot be adjusted with
the [AF] control.
USB MOD Level
Sets the input modulation level of the [USB] (B)
connector from 0% to 100% in 1% steps.
(default: 50%)
DATA OFF MOD
Selects the desired connector(s) for modulation
input when data mode is not in use.
DATA1 MOD
Selects the desired connector(s) for modulation
input when data 1 mode (D1) is in use.
DATA2 MOD
Selects the desired connector(s) for modulation
input when data 2 mode (D2) is in use.
DATA3 MOD
Selects the desired connector(s) for modulation
input when data 3 mode (D3) is in use.
.
OFF (OPEN)
• OFF (OPEN): The received audio is always output
regardless of the squelch condition.
(default)
• ON : The received audio is output
according to the squelch condition
(open/close).
50 %
MIC,ACC
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC1] (pin 4).
• MIC,ACC : Use the signals from [MIC] and [ACC1]
(pin 4). (default)
• USB : Use the signals from [USB] (B).
ACC
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC1] (pin 4).
(default)
• MIC,ACC : Use the signals from [MIC] and [ACC1]
(pin 4).
• USB : Use the signals from [USB] (B).
MIC,ACC
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC1] (pin 4).
• MIC,ACC : Use the signals from [MIC] and [ACC1]
(pin 4). (default)
• USB : Use the signals from [USB] (B).
MIC
• MIC : Use the signals from [MIC]. (default)
• ACC : Use the signals from [ACC1] (pin 4).
• MIC,ACC : Use the signals from [MIC] and [ACC1]
(pin 4).
• USB : Use the signals from [USB] (B).
☞
10
SET MODE
Continued on the next page.
