Tuner (Auto Start)
The internal antenna tuner has an automatic start
capability, which starts tuning if the SWR is high.
(default: OFF)
Tuner (PTT Start)
Tuning of the internal/external antenna tuner can
be automatically started at the moment the [PTT]
is pushed after the operating frequency is changed
(more than 1% from last-tuned frequency).
(default: OFF)
Tuner Preset Memory Clear
The preset memory* of the selected antenna can be
cleared with pushing [CLR] (F-5).
* The variable capacitor settings are memorized as
a preset point for each frequency range (100 kHz
steps) after the tuner matches an antenna.
[ANT] Switch
You can set the antenna connector selection to
automatic, manual or non-selection (when using 1
antenna only). (default: Auto)
Transverter Function
Selects the transverter operation condition from
Auto and ON. (default: Auto)
Transverter Offset
Sets the desired offset frequency for the transverter
operation within 0.000 to 99.999 MHz in 1 kHz steps.
(default: 16.000 MHz)
RTTY Mark Frequency
Selects the RTTY mark frequency. RTTY mark
frequency is switched between 1275, 1615 and
2125 Hz. (default: 2125 Hz)
OFF
• OFF : The tuner remains OFF even when the
SWR is high.
• ON : Automatic tune starts even when the tuner
is turned OFF during HF bands operation.
OFF
• OFF : Tuning starts only when [TUNER] is pushed.
• ON : (Internal antenna tuner) Tuning starts
when [PTT] is pushed on a new frequency
(more than 1% from last-tuned frequency) if
the internal antenna tuner is ON.
(External antenna tuner) Tuning always
starts when [PTT] is pushed on a new
frequency (more than 1%) regardless of the
external antenna tuner ON/OFF.
• ANT1 Push [CLR] : The preset memory of the
antenna that is connected to
[ANT 1] is cleared after pushing
[CLR] (F-5).
• ANT2 Push [CLR] : The preset memory of the
antenna that is connected to
[ANT 2] is cleared after pushing
[CLR] (F-5).
Auto
• OFF : Antenna switch is not activated and does
not function. The [ANT1] connector is
always selected.
• Manual : Antenna switch is activated and manually
selects an antenna.
• Auto : Antenna switch is activated and the
band memory memorizes the selected
antenna. See page 120 for details.
Auto
• Auto : The transceiver turns into transverter
operation condition when 2 to 13.8 V DC is
applied to [ACC2] pin 6.
• ON : Turn the transverter operation ON.
16.000MHz (14.100.0➔30.100.0)
2125
2125 Hz is automatically selected when the internal
RTTY decoder is used.
