12
CONTROL COMMAND
D Command table (continued)
Cmd. Sub Data
cmd.
16 02
12
22
32
40
41
42
43
44
45
46
47
48
4F
50
55
56
57
58
17* 1 see p. 167 Send CW messages
18 00
01
19 00
1A 00 see p. 169 Send/read memory contents
01 see p. 166 Send/read band stacking register contents
02 see p. 166 Send/read memory keyer contents
03 00 to 49 Send/read the selected filter width
04 00 to 13 Send/read the selected AGC time constant
05 0001 see p. 168 Send/read SSB RX HPF/LPF
0002 00 to 10 Send/read SSB RX Tone (Bass) level
0003 00 to 10 Send/read SSB RX Tone (Treble) level
0004 see p. 168 Send/read AM RX HPF/LPF
* While transmitting in the CW mode, or if the Break-in
1
function is ON, the transceiver transmits CW code when
the PC sends this command.
The power ON command (18 01) is available only when
2
*
the transceiver is remote standby mode. The transceiver
accepts the control command only from the [REMOTE] jack.
161
Description
00 Preamp OFF
01 Preamp 1 ON
02 Preamp 2 ON
00 AGC FAST selection
01 AGC MID selection
02 AGC SLOW selection
00 Noise blanker OFF
01 Noise blanker ON
00 Audio peak filter OFF
01 Audio peak filter WIDE ON
(320 Hz is selected when SHARP APF is set)
02 Audio peak filter MID ON
(160 Hz is selected when SHARP APF is set)
03 Audio peak filter NAR ON
(80 Hz is selected when SHARP APF is set)
00 Noise reduction OFF
01 Noise reduction ON
00 Auto notch function OFF
01 Auto notch function ON
00 Repeater tone OFF
01 Repeater tone ON
00 Tone squelch OFF
01 Tone squelch ON
00 Speech compressor OFF
01 Speech compressor ON
00 Monitor function OFF
01 Monitor function ON
00 VOX function OFF
01 VOX function ON
00 BK-IN function OFF
01 Semi BK-IN function ON
02 Full BK-IN function ON
00 Manual notch function OFF
01 Manual notch function ON
00 Twin peak filter OFF
01 Twin peak filter ON
00 Dial lock function OFF
01 Dial lock function ON
00 15 kHz roofing filter selection
01 6 kHz roofing filter selection
02 3 kHz roofing filter selection
00 SHARP selection for DSP filter type
01 SOFT selection for DSP filter type
00 WIDE selection for manual notch width
01 MID selection for manual notch width
02 NAR selection for manual notch width
00 WIDE selection for SSB transmit bandwidth
01 MID selection for SSB transmit bandwidth
02 NAR selection for SSB transmit bandwidth
Turn OFF the transceiver
Turn ON the transceiver* 2
Read the transceiver ID
( SSB, CW, PSK: 00=50 Hz, 40=3600 Hz;
RTTY: 00=50 Hz, 31=2700 Hz;
AM: 00=200 Hz, 49=10 kHz)
( 00=OFF, 01=0.1/0.3 seconds,
13=6.0/8.0 seconds)
(00=–5, 10=+5)
(00=–5, 10=+5)
Cmd. Sub Data
cmd.
1A 05 0005 00 to 10 Send/read AM RX tone (Bass) level
(00=–5, 10=+5)
0006 00 to 10 Send/read AM RX Tone (Treble) level
(00=–5, 10=+5)
0007 see p. 168 Send/read FM RX HPF/LPF
0008 00 to 10 Send/read FM RX tone (Bass) level
(00=–5, 10=+5)
0009 00 to 10 Send/read FM RX Tone (Treble) level
(00=–5, 10=+5)
0010 see p. 168 Send/read CW RX HPF/LPF
0011 see p. 168 Send/read RTTY RX HPF/LPF
0012 see p. 168 Send/read PSK RX HPF/LPF
0013 00 to 10 Send/read SSB TX Tone (Bass) level
(00=–5, 10=+5)
0014 00 to 10 Send/read SSB TX Tone (Treble) level
(00=–5, 10=+5)
0015 00 to 10 Send/read AM TX Tone (Bass) level
(00=–5, 10=+5)
0016 00 to 10 Send/read AM TX Tone (Treble) level
(00=–5, 10=+5)
0017 00 to 10 Send/read FM TX Tone (Bass) level
(00=–5, 10=+5)
0018 00 to 10 Send/read FM TX Tone (Treble) level
(00=–5, 10=+5)
0019 see p. 168 Send/read SSB TX bandwidth for WIDE
0020 see p. 168 Send/read SSB TX bandwidth for MID.
0021 see p. 168 Send/read SSB TX bandwidth for NARROW
0022 0000 to Send/read DRIVE gain
0255 (0000=0%, 0255=100%)
0023 0000 to Send/read speech level
0255 (0000=0%, 0255=100%)
0024 0000 to Send/read CW sidetone level
0255 (0000=0%, 0255=100%)
0025 00 CW sidetone level limit OFF
01 CW sidetone level limit ON
0026 0000 to Send/read beep level
0255 (0000=0%, 0255=100%)
0027 00 Beep level limit OFF
01 Beep level limit ON
0028 00 Squelch mute effect OFF (squelch is fixed
open) for audio output from USB-B connector
01 Squelch mute effect ON for audio output from
USB-B connector
0029 0000 to Send/read modulation level for audio input to
0255 USB-B connector (0000=0%, 0255=100%)
0030 00 [MIC] selection for MOD input connector
during DATA OFF
01 [ACC] selection for MOD input connector
during DATA OFF
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA OFF
03 [USB] selection for MOD input connector
during DATA OFF
0031 00 [MIC] selection for MOD input connector
during DATA1
01 [ACC] selection for MOD input connector
during DATA1
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA1
03 [USB] selection for MOD input connector
during DATA1
0032 00 [MIC] selection for MOD input connector
during DATA2
01 [ACC] selection for MOD input connector
during DATA2
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA2
03 [USB] selection for MOD input connector
during DATA2
Description
