SET MODE

■ Others set mode

Calibration Marker
This item is used for a simple frequency check of the
transceiver. (default: OFF)
See p. 13-5 for calibration procedure.
NOTE: Turn the calibration marker OFF after
checking the frequency of the transceiver.
Beep (Confirmation)
A beep sounds each time a switch is pushed to con-
firm it. This function can be turned OFF for silent op-
eration. (default: ON)
The beep output level can be set in level set mode.
(p. 12-6)
Beep (Band Edge)
When you tune into or out of an amateur band's fre-
quency range, a beep sounds. This functions inde-
pendently of the confirmation beep setting (above).
A different beep tone sounds when you tune in or
out of an amateur band's frequency range. A reg-
ular beep sounds when you tune into a band, and
an lower tone error beep will sound when you
tune out of a band.
The beep output level can be set in the level set
mode. (p. 12-6)
When "ON (User)" or "ON (User) & TX Limit" is se-
lected, [BAND] appears in the display above the func-
tion switch . Up to 30 band edge frequencies
F-5
can be programmed in the band edge screen.
See p. 3-14 for programming details.
Beep Sound
Sets the desired key-touch beep frequency within
500 to 2000 Hz in 10 Hz steps. (default: 1000 Hz)
Time–Out Timer (CI–V)
Turns the Time-Out Timer function ON (3, 5, 10, 20
or 30 minutes) or OFF. If a continuous transmission
exceeds the selected time period, the transmission
will be cut off, to prevent a prolonged transmission.
(default: OFF)
NOTE: This function will be activated only when
you transmit using CI-V commands, or pushing
.
TRANSMIT
OFF
ON
ON (Default)
• OFF : Band edge beep is OFF.
• ON (Default) : When you tune into or out of the
default amateur band's frequency
range, a beep sounds. (default)
• ON (User) : When you tune outside of, or back
into a user programmed amateur
band's frequency range, a beep
sounds.
• ON (User) & TX Limit
: When you tune outside of, or back
into a user programmed amateur
band's frequency range, a beep
sounds. Transmission is also inhib-
ited outside the programmed band.
1000Hz
OFF
