Icom IC-7600 Instruction Manual page 85

Sweep Speed
Select the sweep speed for the ±25 kHz span
selection from SLOW, MID and FAST.
Sweep Speed
Select the sweep speed for the ±50 kHz span
selection from SLOW, MID and FAST.
Sweep Speed
Select the sweep speed for the ±100 kHz span
selection from SLOW, MID and FAST.
Sweep Speed
Select the sweep speed for the ±250 kHz span
selection from SLOW, MID and FAST.
Fixed Edges
Set the scope edge frequencies for fixed mode for
bands below 1.6 MHz.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 1.6 to 2 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 2 to 6 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 6 to 8 MHz band is selected.
(± 25k)
(± 50k)
(± 100k)
(± 250k)
( 0.03 − 1.60)
( 1.60 − 2.00)
( 2.00 − 6.00)
( 6.00 − 8.00)
RECEIVE AND TRANSMIT
FAST
FAST
FAST
FAST
0.750 − 1.250 MHz
• Set the frequencies within 0.030 to 1.600 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge
frequency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
1.800 − 2.000 MHz
• Set the frequencies within 1.600 to 2.000 MHz
range in 1 kHz steps.
3.500 − 4.000 MHz
• Set the frequencies within 2.000 to 6.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge
frequency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
7.000 − 7.300 MHz
• Set the frequencies within 6.000 to 8.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge
frequency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
☞ Continued on the next page.
