RECEIVE AND TRANSMIT
D USB mouse operation
If you connect a USB mouse to the transceiver,
a mouse pointer appears on the spectrum scope
screen.
Now, you can change the frequency by using the
mouse.
Clicking while holding down [XFC] changes the
transmit frequency.
• Mouse operation on the center mode screen
Button Operation
Click
Left
Drag
Right Click/Drag
• Mouse operation on the fixed mode screen
Button Operation
Click
Left
Drag
Right Click/Drag
Changing frequencies in the drag operation differ,
depending on the tuning step settings.
79
Description
The frequency changes to the
clicked point and the mouse
pointer moves to the center of
the screen.
The frequency changes to
the clicked point and the
mouse pointer moves to the
center of the screen, and then
the frequency increases or
decreases.
The right button temporarily
changes the frequency.
While holding the button,
same action as the left button,
but release it to return to the
original frequency.
Description
The frequency and marker
change to the clicked point
The frequency and marker
change to the clicked point
and then the frequency
increases or decreases.
The right button temporarily
changes the frequency.
While holding the button,
same action as the left button,
but release it to return to the
original frequency.
Mouse pointer
