10
SET MODE
Others set mode (Continued)
■
TX Delay (50M)
If the transceiver transmits power before an external
device, such as a linear amplifier, is ready to
operate, the transmitted power will be reflected back
and can damage the transceiver. Therefore a time
delay can be set to delay the transceiver output until
the external device is ready.
Time-Out Timer (CI-V)
If a continuous transmission exceeds the
selected time period, this function will cut off the
transmission, to prevent a prolonged transmission.
Set the Time-Out Timer function to ON, and select
a time of 3, 5, 10, 20 or 30 minutes, or turn the
function OFF. (default: OFF)
Quick Dualwatch
When this item is set to ON, holding down
[DUALWATCH] for 1 second sets the sub readout
frequency to the main readout frequency, and
activates dualwatch operation.

Quick SPLIT

When this item is set to ON, holding down [SPLIT]
for 1 second sets the unselected VFO's readout
frequency and operating mode to the selected
VFO's readout, and activates split operation.
(default: ON)
See page 97 for details.
FM SPLIT Offset (HF)
Sets the offset (difference between transmit and
receive frequencies) for the quick split function. This
setting is used for HF bands in
is used to input the repeater offset for an HF band.
The offset frequency can be set from –9.999 to
+9.999 MHz in 1 kHz steps. (default: –0.100 MHz)
FM SPLIT Offset (50M)
Sets the offset (difference between transmit and
receive frequencies) for the quick split function. This
setting is used for 50 MHz band FM mode only, and is
used to input the repeater offset for the 50 MHz band.
The offset frequency can be set from –9.999 to
+9.999 MHz in 1 kHz steps. (default: –0.500 MHz)

SPLIT LOCK

When this item is ON, the main dial can be used to
adjust the transmit frequency while pushing [XFC],
even while the lock function is activated.
(default: OFF)
137
FM mode only and
the
OFF
Set the TX delay time on the 50 MHz band to 10,
15, 20, 25, or 30 milliseconds, or select "OFF" for no
delay time, depending on the needs of your external
device. (default: OFF)
OFF
NOTE: This function will be activated only when
you transmit using CI-V commands, or pushing
[TRANSMIT] on the transceiver.
ON
• OFF : Quick dualwatch OFF
• ON : Quick dualwatch ON (default)
ON
• OFF : Quick split OFF
• ON : Quick split ON
–0.100MHz
–0.500MHz
OFF
• OFF : Split lock OFF
• ON : Split lock ON
See pages 96 and 97 for split frequency operation
details.
