Icom IC-7600 Instruction Manual page 87

Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 30 to 45 MHz band is selected.
Fixed Edges
Set the scope edge frequencies for fixed mode
scope when the 45 to 60 MHz band is selected.
(30.00 − 45.00)
(45.00 − 60.00)
RECEIVE AND TRANSMIT
30.000 − 30.500 MHz
• Set the frequencies within 30.000 to 45.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge
frequency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
50.000 − 50.500 MHz
• Set the frequencies within 45.000 to 60.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge
frequency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
4
4
78
