5.5 Connecting the Camera

Refer to the wire definition and illustrations below to connect the power and
network.

5.5.1 Wire Definition

GV-MFD Series
The data cable provides connections for power and network access. The
wires are illustrated and defined below:
No. Wire Color
1 Yellow
2 Orange
3 Gray
GV-MDR Series
Power and network connectivity is provided through a PoE cable.
Wire Color
Gray
62
Figure 5-16
Definition
DC 12V+
GND
PoE, Ethernet
Definition
PoE, Ethernet
