16.7.2 Wireless Client Mode

Note this function is only supported in GV-CBW120 / 220 and GV-CAW120
/ 220. Set up the client mode before enabling the wireless function.
Network type: Select the network mode Ad Hoc or Infrastructure.
Infrastructure: Connect to the Internet via the Access Point. This
mode further gives wireless access to the Internet or data sharing
under a previously wired environment.
Ad-Hoc: A Peer-to-Peer mode. This mode connects to other
computer with the WLAN card, and does not need the Access
Point to connect to each other.
Network name (SSID): The SSID (Service Set Identify) is a unique
name that identifies a particular wireless network. Type SSID of the
Wireless LAN group or Access Point you are going to connect to.
282
Figure 16-26
