The buttons below are available when the iPhone, iPod Touch or iPad is
positioned vertically.
Icon Name
Screen
division
PTZ
control
Snapshot
I/O
Device
Stream
change
Note: The default live view is stream 2, limited to Admin users only starting
from GV-Eye V1.2.0.
Function
Displays up to four channels on the same page if
the GV-IP device supports multiple channels.
•
Enables PTZ control. Drag across the camera
live view screen to adjust the camera position.
The following buttons are available:
•
: Zooms in and out.
•
: Adjusts the focus.
•
: Moves the camera back to Home position.
•
: Adjusts the iris. (GV-SD010 only)
•
: Moves the camera to a preset point by
typing the preset number.
Saves the current image in the mobile device.
Tap a number to force the output device to be
triggered. The I/O icon
when I/O is triggered.
Switch the live view streams.
21 Smart Device Connection
will be highlighted briefly
