[LAN Configuration]
Note the Wireless Settings are only available in GV-CBW120 / 220 and
GV-CAW120 / 220. According to the network environment, select Wired or
Wireless. Before enabling the Wireless option, follow the steps in 12.1.3
Configuring the Wireless Connection to configure the wireless settings first.
[LAN Configuration]
Dynamic IP address: The network environment has a DHCP server
which will automatically assign a dynamic IP address to the camera.
Click the Test DHCP button to see the currently assigned IP address
or look up the dynamic IP address using GV-IP Device Utility.
Static IP address: Assign a static IP or fixed IP to the camera. Type
the camera's TCP/IP and DNS parameters in the Configure
connection parameters section.
PPPoE: The network environment is xDSL connection. Type the
Username and Password provided by ISP to establish the connection.
If you use the xDSL connection with dynamic IP addresses, first use
the DDNS function to obtain a domain name linking to the camera's
changing IP address.
[Configure connection parameters]
Type the camera's IP address, Subnet Mask, Router/Gateway, Primary
DNS server and Secondary DNS server.
Parameters
IP address
Subnet Mask
Router/Gateway
Primary DNS server
Secondary DNS server
For details on Dynamic DNS Server Settings, see 16.7.3 Advanced TCP/IP.
16
Wired Ethernet
192.168.0.10
255.255.255.0
192.168.0.1
192.168.0.1
192.168.0.2
Administrator Mode
Default
Wireless
192.168.100.10
255.255.255.0
192.168.0.1
192.168.0.1
192.168.0.2
