7.4.1 Connecting the Camera
Wire Definition
The supplied 4-pin data cable provides connections for power, ground, 1
sensor input and 1 alarm output. The wires are defined below:
No.
Wire Color
1
Red
2
Green
3
Blue
4
Black
Figure 7-9
Definition
DC 5V
Digital In
Digital Out
Ground
Ultra Bullet Camera
7
91
