8.4.2 L-Shaped Wall Mount

You may wall-mount the GV-PTZ010D / GV-PT110D camera with or
without the mounting cover.
1. Take the wall mount bracket and make 2 marks on the wall for
screw anchors.
2. Drill the marks and insert 2 screw anchors.
3. Insert the long screws and leave enough distance (approximately 2
mm) to hang the wall mount bracket later.
2 mm
Long
Screw
Figure 8-7
Figure 8-6
Wall
8
PTZ Camera
103
