Remote Configuration; Camera Name Display; Image Enhancement - GeoVision GV-IPCAM User Manual

15.2.8 Remote Configuration

You can upgrade firmware over the network. Click the Show System
Menu button (No. 8, Figure 15-3), and select Remote Config. The Remote
Config dialog box will appear.
[Firmware Upgrade] In this tab, you can upgrade the firmware over the
Internet. For details, see Advanced Applications, Chapter 18.

15.2.9 Camera Name Display

To display the streaming name on the image, click the Show System
Menu button (No. 8, Figure 15-3), and select Show Camera Name.

15.2.10 Image Enhancement

To enhance the image quality of live video, click the Show System Menu
button (No. 8, Figure 15-3), and select Image Enhance. This dialog box
appears.
De-Interlace: Converts the interlaced video into non-interlaced video.
De-Block: Removes the block-like artifacts from low-quality and
highly compressed video.
Enable DirectDraw: Activates the DirectDraw function.
Figure 15-13
15
Accessing the Camera
223
