Quick Start Guide

GV-IP Camera H.264
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
ICH264-QG-Z-EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-CBW120 and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-CBW120

Summary of Contents for GeoVision GV-CBW120

  • Page 1: Quick Start Guide

    Quick Start Guide GV-IP Camera H.264 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. ICH264-QG-Z-EN...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Safety Notice For GV-CBW120 and GV-CBW220: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.

  • Page 4: Table Of Contents

    Contents Introduction ................vii Options ..................xix Note for Connecting to GV-System .........xxi Note for Recording..............xxii Note for Adjusting Focus and Zoom ........xxiii Note for Installing Camera Outdoor ........xxiv Note for Closing the Bullet Camera Cover......xxvi Note for USB Storage and WiFi Adapter ......xxvii 1.
  • Page 5 3.2 Overview .................19 3.3 Installation ................20 3.4 Connecting the Camera............22 4. IR Arctic Box Camera ............23 4.1 Packing List................23 4.2 Overview .................24 4.3 Installation ................25 4.4 Connecting the Camera............29 4.4.1 Wire Definition............29 5. Mini Fixed Dome & Mini Fixed Rugged Dome .....31 5.1 Packing List................31 5.2 Overview .................32 GV-MFD120 / 130 / 220 / 320 / 520 ........32...
  • Page 6 7.3 Installation ................55 7.3.1 Adjusting the Angles ..........57 7.3.2 Adjusting Lens and Inserting a Memory Card .....60 7.3.3 Inserting the Sun-Shield Cover........62 7.4 Connecting the Camera............63 7.4.1 Wire Definition............63 7.4.2 Connecting the Power Cable........65 8. Ultra Bullet Camera..............66 8.1 Packing List................66 8.2 Overview .................67 8.3 Installation ................69 8.4 Connecting the Camera............73...
  • Page 7 11. Vandal Proof IP Dome (Part II) ..........101 11.1 Packing List .................101 11.2 Overview ................104 11.3 Installation ................106 11.4 Connecting the Camera............116 11.4.1 Connecting the Power Cable........116 11.4.2 Connecting the I/O Device........117 12. Fixed IP Dome ..............118 12.1 Packing List .................118 12.1.1 Packing List for Hard-Ceiling Mount .......118 12.1.2 Packing List for In-Ceiling Mount ......119 12.2 Overview ................120...
  • Page 8 15.3 Installation ................149 15.3.1 Ceiling Mount............149 15.3.2 L-Shaped Wall Mount ..........151 15.4 Connecting the Camera............154 16. Accessing the Camera............155 16.1 System Requirement ............155 16.2 Accessing the Live View ............156 16.2.1 Checking the Dynamic IP Address ......157 16.2.2 Configuring the IP Address........159 16.2.3 Configuring the Wireless Connection......161 16.3 Adjusting Image Clarity............165 16.3.1 Using Focus Adjustment Cap .........167...

  • Page 9: Introduction

    Introduction Welcome to the GV-IPCam H.264 Quick Start Guide. In this quick guide, you will find information on the installation and basic configurations of the GV-IPCam H.264 series. Camera Model No. Description 1.3 MP Low Lux, H.264, Varifocal GV-BX120D D/N, Auto Iris, f: 2.8 ~ 12 Lens mm, F/1.4, 1/3’’...
  • Page 10 Camera Model No. Description 3 MP, H.264 D/N, GV-BX320D-0 Auto Iris, f: 3.1 ~ 8 mm, F/1.2, 1/3’’ CS Lens 3 MP, H.264 D/N, Varifocal GV-BX320D-1 Auto Iris, f: 2.8 ~ 6 mm, Lens F/1.3, 1/3’’ CS Lens 5 MP, H.264 D/N, Manual GV-BX520D Iris, f: 4.5 ~ 10 mm, F/1.6, 1/2’’...
  • Page 11 Camera Model No. Description 2 MP / 3 MP, H.264 D/N, GV-BX2400-0F WDR Pro, Fixed Iris, f: 4 GV-BX3400-0F mm, F/1.5, 1/3’’ CS Lens 2 MP / 3 MP, H.264 D/N, GV-BX2400-1F WDR Pro, Fixed Iris, f: 8 GV-BX3400-1F mm, F/1.6, 1/2.5’’ CS Lens 2 MP / 3 MP, H.264 D/N, GV-BX2400-2F WDR Pro, Fixed Iris, f: 12...
  • Page 12 Camera Model No. Description GV-UBX1301-0F 1.3 MP, H.264 D/N, Fixed GV-UBX1301-1F Iris, f: 3 / 4 / 8 mm, F/1.6, 1/3” M12 Lens GV-UBX1301-2F GV-UBX2301-0F 2 MP, H.264 D/N, Fixed Ultra Box Fixed GV-UBX2301-1F Iris, f: 3 / 4 / 8 mm, F/1.6, Camera Lens 1/3”...
  • Page 13 Camera Model No. Description 2 MP / 3 MP, H.264, D/N, GV-BX2400-E WDR Pro, Auto Iris, f: 3 ~ 10.5 mm, F/1.4, 1/2.7’’ CS GV-BX3400-E IR Arctic Varifocal Lens Lens Camera 5 MP, H.264, D/N, GV-BX5300-E Manual Iris, f: 4.5 ~ 10 mm, F/1.6, 1/2’’...
  • Page 14 Camera Model No. Description 1.3 MP Super Low Lux / 2 GV-MDR1500-3F MP WDR Pro / 2 MP Super GV-MDR2400-3F Low Lux / 3 MP WDR Pro / GV-MDR2500-3F 5 MP, H.264, Color, Fixed GV-MDR3400-3F Iris, f: 8 mm, F/1.6, 1/3’’ Mini GV-MDR5300-3F M12 Mount...
  • Page 15 Camera Model No. Description 1.3 MP Super Low Lux / 2 GV-MFD1501-2F MP WDR Pro / 2 MP Super GV-MFD2401-2F Low Lux / 3 MP WDR Pro / GV-MFD2501-2F 5 MP, H.264, Color, Fixed GV-MFD3401-2F Iris, f: 8 mm, F/1.6, 1/3’’ GV-MFD5301-2F M12 Mount 1.3 MP Super Low Lux / 2...
  • Page 16 Camera Model No. Description 1.3 MP Low Lux / 1.3 MP Super Low Lux / 2 MP GV-BL1210 WDR Pro / 2 MP Super GV-BL1510 Motorized Low Lux / 3 MP WDR GV-BL2410 Varifocal Pro, H.264, D/N, Auto Iris, Lens GV-BL2510 3X Optical Zoom, f: 3 ~ 9 Bullet...
  • Page 17 Camera Model No. Description GV-UBL3401-0F 3 MP, Fixed Iris, WDR Ultra GV-UBL3401-1F Pro, f: 3 / 4 / 8 / 12 mm, Bullet Fixed Lens F/1.6, 1/3’’ M12 Lens GV-UBL3401-2F Camera Mount GV-UBL3401-3F 1.3 MP Low Lux, H.264 Target GV-EBL1100-0F D/N , Fixed Iris, f: 3.8 / 6 Bullet Fixed Lens...
  • Page 18 Camera Model No. Description GV-VD120D (IK10+, Transparent Cover) GV-VD121D 1.3 MP H.264, D/N, (IK10+, Smoked Cover) Low Lux, Auto Iris GV-VD122D (IK7, Transparent Cover) GV-VD123D (IK7, Smoked Cover) GV-VD220D (IK10+, Transparent Cover) GV-VD221D 2 MP H.264, D/N, (IK10+, Smoked Cover) Auto Iris GV-VD222D (IK7, Transparent Cover)
  • Page 19 Camera Model No. Description GV-VD1530 (Coming) 1.3 MP Super Low Lux / 2 GV-VD2430 MP WDR Pro / 2 MP High Power IR (Coming) LEDs, Super Low Lux / 3 MP GV-VD2530 Varifocal Lens WDR Pro, H.264, D/N, (Coming) Auto Iris GV-VD3430 (Coming) 1.3 MP Super Low Lux / 2...
  • Page 20 GV-CB220 f: 3.35 mm, F/2.4, 1/3’’ M12 Lens Cube Fixed 1.3 MP / 2 MP, Camera Lens H.264, Wireless, GV-CBW120 Fixed Iris, f: 3.35 GV-CBW220 mm, F/2.4, 1/3’’ M12 Lens GV-PT130D 1.3 MP / 2 MP / 3 Fixed GV-PT220D MP H.264 D/N,...

  • Page 21: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Accessory Description The power adapter is available for all GV-IP Camera (except the IR Arctic Cameras). For supported Power Adapter regions, see Options in GV-IPCam H.264 User’s Manual on the Software CD.
  • Page 22 Accessory Description The GV-WiFi Adapter is a plug-and-play device designed to connect GV-BX1200 Series / 1300 series / 1500 series / 2400 series / 2500 series / 3400 series / 5300 series and GV-MFD1501 series / GV-WiFi Adapter 2401 series / 2501 series / 3401 series / 5301 series to wireless network.

  • Page 23: Note For Connecting To Gv-System

    Note for Connecting to GV-System The GV-IPCAM H.264 is designed to work with GV-System, a hybrid or digital video management system. Note the following when GV-IPCAM H.264 is connected to GV-System: By default, the images are recorded to the memory card inserted to the GV-IP Camera H.264 (except GV-IR Arctic Camera and Target Series, which are not equipped with a memory card slot).

  • Page 24: Note For Recording

    Note for Recording By default, the images are recorded to the memory card inserted to the GV-IP Camera H.264 (except GV-IR Arctic Camera and Target Series, which are not equipped with a memory card slot). Make sure the Write recording data into local storage option is enabled. If this option is disabled, the camera will stop recording to the memory card while the live view is accessed through Web browsers or other applications.

  • Page 25: Note For Adjusting Focus And Zoom

    Note for Adjusting Focus and Zoom When adjusting the Focus and Zoom Screws (on Box Camera, IR Arctic Box Camera, Mini Fixed Dome, Bullet Camera, Vandal Proof IP Dome and Fixed IP Camera), please do not over tighten the Focus and Zoom screws. The screws only need to be as tight as your finger can do it;...

  • Page 26: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the IR Arctic Box Camera, Bullet Camera, Ultra Bullet Camera, Target Bullet Camera, Vandal Proof IP Dome or Mini Fixed Rugged Dome outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables.
  • Page 27 After opening the camera cover, ensure the screws are tightened and the cover is in place. The silica gel bag loses it effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air.

  • Page 28: Note For Closing The Bullet Camera Cover

    Note for Closing the Bullet Camera Cover To ensure that the camera performs its full capacity against water and dust, adhere to the following guidelines when closing the Bullet Camera cover: Line up the dots Tighten the camera cover until the dots on the cover and the body line up as indicated below.

  • Page 29: Note For Usb Storage And Wifi Adapter

    Note for USB Storage and WiFi Adapter Mind the following limitations and requirements for using USB storage and GV-WiFi Adapter: The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above. The USB hard drive’s storage capacity must not exceed 2TB. USB flash drives and USB hubs are not supported.
  • Page 30 xxviii...

  • Page 31: Box Camera

    1. Box Camera 1.1 Packing List • Box Camera • Terminal Block • Fixed Focal or Varifocal Megapixel Lens • Six Lens Rings • One Lens Ring (for GV-BX140DW only) • Video Out Wire • Camera Holder • GV-IPCAM H.264 Software CD •...

  • Page 32: Overview

    1.2 Overview GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D 12 13 Note: The Auto Iris Connector (No. 7) is only functional in GV-BX120D, GV-BX130D-0, GV-BX220D and GV-BX320D. The Light Sensor (No. 11) is only available in GV-BX140DW. Keep the Light sensor unobscured for accurate light detection.
  • Page 33 Box Camera Name Description Connects I/O devices. For details, see I/O Terminal Block, Box Camera Chapter, I/O Terminal Block GV-IPCam H.264 User’s Manual on the Software CD. Indicates the power is supplied. For detail, Power LED see the table below. Auto Iris Plug the iris control cable to the connector.

  • Page 34: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series

    GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series Note: The Auto Iris Connector (No. 8) is only functional for varifocal models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 3400. The Iris Screw (No.
  • Page 35 Box Camera Name Description Audio In Connects a microphone for audio input. Connects I/O devices. For details, see I/O I/O Terminal Terminal Block, Box Camera Chapter, Block GV-IPCam H.264 User’s Manual on the Software CD. Indicates the power is supplied. For detail, see Power LED the table below.

  • Page 36: Accessory Installation

    1.3 Accessory Installation 1.3.1 C-Mount Lenses When you use a C-mount lens, it requires a certain distance from the camera’s imaging chip to focus the lens. Mount the supplied C-mount lens adapter / lens ring to the camera, and then attach the lens onto the camera body.

  • Page 37: Infrared Illuminators (Gv-Ir Led / Gv-Ir Led T2)

    Box Camera 1.3.2 Infrared Illuminators (GV-IR LED / GV-IR LED T2) Connect the infrared illuminator to the terminal block on the camera. See I/O Terminal Block, Box Camera Chapter, GV-IPCam H.264 User’s Manual on the Software CD, or GV-IR LED User’s Manual. Access the Web interface of the camera.
  • Page 38 GV-IR LED T2 Click Apply. For Trigger by Input and Trigger IR by D/N functions, see the Video Settings section, Administrator Mode Chapter in the GV-IPCam H.264 User’s Manual in the Software CD.

  • Page 39: Connecting The Camera

    Box Camera 1.4 Connecting the Camera The Box Camera is designed for indoor use. Please make sure the installing site is shielded from rain and moisture. GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 40 Optionally connect to input / output devices or an infrared illuminator. For details, see Infrared Illuminator and I/O Terminal Block, Box Camera Chapter, GV-IPCam H.264 User’s Manual on the Software Connect power using one of the following methods: • Plug the power adapter to the power port. •...

  • Page 41: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series

    Box Camera GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera. Connect to network using one of the following methods: •...
  • Page 42 Optionally connect to input / output devices or an infrared illuminator. For details, see Infrared Illuminator and I/O Terminal Block, Box Camera Chapter, GV-IPCam H.264 User’s Manual on the Software Connect power using one of the following methods: • Plug the power adapter to the power port. •...

  • Page 43: Ultra Box Camera

    2. Ultra Box Camera 2.1 Packing List • Ultra Box Camera • Supporting rack • Screw x 3 • Screw anchor x 3 • GV-IPCAM H.264 Software CD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: Power adapter can be purchased upon request.

  • Page 44: Overview

    2.2 Overview Name Description Audio Out Connects a speaker for audio output. Resets the camera to factory defaults. See 19 Default Restoring to Factory Default Settings in the Quick Start Guide LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds.

  • Page 45: Installation

    Ultra Box Camera 2.3 Installation You can stand the Ultra Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Ultra Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 46 Connect the network and power cables to the camera. See 2.4 Connecting the Camera in the Quick Start Guide. Access the live view. See 16.2 Accessing the Live View in the Quick Start Guide. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 47: Connecting The Camera

    Ultra Box Camera 2.4 Connecting the Camera Connect power using one of the following methods: • Plug the power adapter to the 5V terminal block. The power adapter is an optional device. For detail, see Options in the Quick Start Guide. •...

  • Page 48: Target Box Camera

    3. Target Box Camera 3.1 Packing List • Target Box Camera • Supporting rack • Screw x 3 • Screw anchor x 3 • GV-IPCAM H.264 Software CD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: Power adapter can be purchased upon request.

  • Page 49: Overview

    Target Box Camera 3.2 Overview Name Description Resets the camera to factory defaults. See 19 Default Restoring to Factory Default Settings in the Quick Start Guide. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. DC 12V Connects to power.

  • Page 50: Installation

    3.3 Installation You can stand the Target Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Target Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 51 Target Box Camera Connect the network and power cables to the camera. See 3.4 Connecting the Camera in the Quick Start Guide. Access the live view. See 16.2 Accessing the Live View in the Quick Start Guide. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 52: Connecting The Camera

    3.4 Connecting the Camera Connect power using one of the following methods: • Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the Quick Start Guide. • Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 53: Ir Arctic Box Camera

    4. IR Arctic Box Camera 4.1 Packing List  IR Arctic Box Camera  Screw Anchor x 4  Screw x 4  Washer x 4  Big Torx Wrench  Small Torx Wrench  Silica Gel Bag x 2 ...

  • Page 54: Overview

    4.2 Overview Note: The Iris Screw (no. 7) is only available in GV-BX520D-E / 5300-E. Name Description Silica gel bag Desiccant that keeps the camera housing dry. IR power plug Supplies power to the built-in IR LEDs. Focus Screw Adjusts the focus of the camera. Module screw Holds the module in place.

  • Page 55: Installation

    IR Arctic Box Camera 4.3 Installation The IR Arctic Box Camera is designed for outdoor use. Mark the installation site and drill four holes for screw anchors. Insert the supplied screw anchors. Secure the camera to the wall using the supplied washers and screws. Connect the camera to the network and supply power via the PoE cable.
  • Page 56 Tilt Adjustment Pan Adjustment Based on the live view, adjust the image clarity using the GV-IP Device Utility program. For details, see 16.3 Adjusting Image Clarity in e Quick Start Guide. Unscrew the cover with the supplied small torx wrench.
  • Page 57 IR Arctic Box Camera Hold the connectors and unplug them. IMPORTANT: Unscrew and remove the cover carefully. Pulling the cover off may cause damages to the inner wiring of the camera. Adjust the focus, zoom and iris screws. Focus screw Iris screw Zoom screw...
  • Page 58 Replace the silica gel bag. Paste the sticker to the front side of the silica gel bag. Press the sticker several times to make sure it adheres properly and paste the silica gel bag to the indicated place. IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, you must replace the silica gel bag every time you open the camera and conceal the silica gel bag in the camera within 2 minutes of exposing to open air.

  • Page 59: Connecting The Camera

    IR Arctic Box Camera 4.4 Connecting the Camera 4.4.1 Wire Definition Wire Color Definition Black (thick) Black BNC TV out Green RCA Audio Out Pink RCA Audio In Follow the steps below to connect the camera: Optionally connect a speaker (green) and an external microphone (pink).
  • Page 60 Optionally connect the camera’s cable to the GV-PA481 PoE adapter as illustrated below. The power and network will be supplied simultaneously. POWER & DATA OUT DATA IN Rear Panel Ethernet Cable Power Hub/Router GV-BX-E The status LED of the camera will be on. Note: For using the IR Arctic Box Camera, ensure that you: enable the IR LED function on the Web interface after loading the default settings.

  • Page 61: Mini Fixed Dome & Mini Fixed Rugged Dome

    5. Mini Fixed Dome & Mini Fixed Rugged Dome 5.1 Packing List • Mini Fixed Dome or Mini Fixed Rugged Dome with 3 options for its LAN connector (M12, Waterproof or Non-Waterproof) • Torx Wrench • Self Tapping Screw x 2 •...

  • Page 62: Overview

    5.2 Overview GV-MFD120 / 130 / 220 / 320 / 520 Name Description Resets the camera to factory default. See Default Button 19. Restoring to Default Settings later in the Quick Start Guide. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle. Built-In Microphone Provides one-way audio.

  • Page 63: Led Indicator

    Mini Fixed & Rugged Dome Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store recording data. LED Indicator LED Name Description 1. Link Turns only when the network is connected. 2. ACT Turns on when data are being transmitted.

  • Page 64: Gv-Mfd1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series

    GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series Name Description Microphone Receives sound. Pan Screw Loosens the screw to pan. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle. Resets the camera to factory default. See Default Button 19 Restoring to Factory Default Settings.
  • Page 65 Mini Fixed & Rugged Dome LED Name Description 1. Link Turns on (green) when the network is connected. 2. ACT Turns on (orange) when data are being transmitted. 3. Status Turns on (red) when the system is ready. 4. Power Turns on (green) when power is on.

  • Page 66: Gv-Mdr

    GV-MDR Name Description Silica gel bag Absorbs the moisture inside the camera. Prevents water or moisture from entering Conceal paper the camera. Lens Receives image inputs. Rotation Disc Rotates the camera lens. Pan Disc Pans the camera lens. Tilt Screw Loosens to tilt the camera.
  • Page 67 Mini Fixed & Rugged Dome Name Description Turns red when the power is on. Flashes Power and status orange light twice when the system is ready. LAN LED Turns on when the network is connected. Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store recording data.
  • Page 68 Waterproof Connector For this connector type, see 6.4.2 GV-MDR to install the supplied cable connector. Non-waterproof (Smaller) Connector...

  • Page 69: Installation

    Mini Fixed & Rugged Dome 5.3 Installation To install a Mini Fixed Dome, make sure the installing site is shielded from rain and moisture. GV-MFD Series Unscrew the housing cover using the supplied torx wrench. Put the camera on the desired location and make 2 marks on the ceiling for screw anchors.
  • Page 70 Tilt Adjustment Insert a memory card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. Memory Card Slot Secure the housing cover using the supplied torx wrench. 10. Optionally conceal the cable opening with the supplied cable stopper. Cable stopper...

  • Page 71: Gv-Mdr Series

    Mini Fixed & Rugged Dome GV-MDR Series Paste the installation sticker on the desired location. The arrow should point toward the direction that the camera faces. Drill one hole on each of the two curves for screw anchors. Drill the circle (30 mm in diameter) if you want to run the cable into the ceiling.
  • Page 72 Install the cable connector to waterproof the cable. You should have 5 parts: Prepare an internet cable with the RJ-45 connector on one end only. Connect the internet cable to the camera cable. Paste the sticker to the camera cable and slide in all the components as shown below.
  • Page 73 Mini Fixed & Rugged Dome IMPORTANT: Item 5 must be secured tightly to waterproof the cable. Access the live view. See 16.2 Accessing the Live View in the Quick Start Guide. Adjust the angles based on the live view. Pan Adjustment Tilt Adjustment Rotational Adjustment...
  • Page 74 Insert a memory card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. 10. Replace the silica gel bag. IMPORTANT: The silica gel bag loses it effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air.

  • Page 75: Connecting The Camera

    Mini Fixed & Rugged Dome 5.4 Connecting the Camera Refer to the wire definition and illustrations below to connect the power and network. 5.4.1 Wire Definition GV-MFD120 / 130 / 220 / 320 / 520 The data cable provides connections for power and network access. The wires are illustrated and defined below: Wire Color Definition...

  • Page 76: Power And Network Connection

    5.4.2 Power and Network Connection Use one of the following methods to power on and connect your camera to network: • Wired connection with PoE: Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.

  • Page 77: Vehicle Installation

    Mini Fixed & Rugged Dome 5.4.3 Vehicle Installation To install the Mini Fixed Rugged Dome on a vehicle, clip the ferrite core to the camera cable. The ferrite core must be attached as close as possible to the camera with the maximum distance of 15 cm. Max.

  • Page 78: Target Mini Fixed Dome

    6. Target Mini Fixed Dome 6.1 Packing List • Target Mini Fixed Dome • Screw x 2 • Screw anchor x 2 • GV-IPCAM H.264 Software CD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: Power adapter can be purchased upon request.

  • Page 79: Overview

    Target Mini Fixed Dome 6.2 Overview Name Description Lens Receives image inputs. Pan Screw Loosens the screw to adjust pan angle. Tilt Screw Loosens the screw to adjust tilt angle. Microphone Receives sound. Default Button Resets the camera to factory default. See 19 Restoring to Factory Default Settings.

  • Page 80: Installation

    6.3 Installation The Target Mini Fixed Dome can be installed on the wall or the ceiling. Before installing the camera, make sure the installing site is shielded from rain and moisture. Open the housing cover by turning. Place the camera where you want to install it and make 2 marks on the ceiling or the wall for screw anchors.
  • Page 81 Target Mini Fixed Dome Thread the power and / or network cable(s) through the oval-shaped hole or the cable opening on the side, and connect the camera to network and power. For details, see 6.4 Connecting the Camera. Secure the Target Mini Fixed Dome to the ceiling or the wall with the self-tapping screws.

  • Page 82: Connecting The Camera

    6.4 Connecting the Camera Connect power using one of the following methods: • Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual. • Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 83: Bullet Camera

    7. Bullet Camera 7.1 Packing List • Bullet Camera • Lens (Megapixel and Built-In 16 IR LEDs) • Self Tapping Screw x 3 • Plastic Screw Anchor x 3 • Torx Wrench x 2 • Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screws x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) •...

  • Page 84: Overview

    7.2 Overview Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10). Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default. Default Button See 19.

  • Page 85: Installation

    Bullet Camera 7.3 Installation The Bullet Camera is designed for outdoor use and can be mounted on ceiling and wall. Slide the cable clamp to the camera base. Cable Clamp Install the Bullet Camera to the wall / ceiling. Remove the protection sticker from the camera’s cover. Connect the power, network and other cables to the camera.
  • Page 86 Loosen the camera’s cover, adjust the lens and focus, and insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. See 7.3.2 Adjusting Lens and Inserting a Memory Card in the Quick Start Guide. Fasten the camera’s cover.

  • Page 87: Adjusting The Angles

    Bullet Camera 7.3.1 Adjusting the Angles The Bullet Camera is designed to be adjustable in three shafts. Tip: The three shafts are designed to offer easy and flexible ceiling / wall mount installation. First Shaft You can adjust the camera body by 360 degrees to the right or the left. Unscrew the panning lock screw with the torx wrench.
  • Page 88 Second Shaft You can adjust the camera body up and down by 90, 112.5, 135, 157.5 or 180 degrees by using the gears inside the camera body and the camera base. Unscrew the tilting lock screw with the torx wrench. Tilting Lock Screw Torx Wrench Hold the camera body, and move the camera base to the right to...
  • Page 89 Bullet Camera Third Shaft You can adjust the camera base by 360 degrees. Unscrew the base fixing screw with the torx wrench. Torx Wrench Base Fixing Screw Adjust the angle of camera base, and fasten the base fixing screw. 0~360°...

  • Page 90: Adjusting Lens And Inserting A Memory Card

    7.3.2 Adjusting Lens and Inserting a Memory Card To adjust the camera’s lens to produce a clear image and insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot, follow the steps below. Loosen the camera’s cover. Camera＇...
  • Page 91 Bullet Camera Slightly pull out the camera module. Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. Memory Card Slot Push the camera module back and fasten the fixing screw. Insert a new silica gel bag to the camera module. IMPORTANT: 1.

  • Page 92: Inserting The Sun-Shield Cover

    7.3.3 Inserting the Sun-Shield Cover After setting up the Bullet Camera, now you can install the sun-shield cover to the camera. Fasten the hexagon screws either on top or below the camera. Hexagon Screws Put the sun-shield cover on top of hexagon screws. Make sure to aim the rear hexagon screw at the edge of the sun-shield cover’s aperture for optimal sun-shield performance.

  • Page 93: Connecting The Camera

    Bullet Camera 7.4 Connecting the Camera Connect your Bullet Camera to power, network and the cables needed. 7.4.1 Wire Definition The cable of the Bullet Camera is illustrated and defined below: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange) DC 12V- / AC 24V - (Black) GND (Yellow)
  • Page 94 Note that the Audio In and Out connectors may also come as terminal blocks: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange) DC 12V- / AC 24V - (Black) GND (Yellow) Audio In (Brown) Audio Out (Green) Ethernet (PoE) Wire Color Definition...

  • Page 95: Connecting The Power Cable

    Bullet Camera 7.4.2 Connecting the Power Cable There are two ways to supply power to the Bullet Camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. •...

  • Page 96: Ultra Bullet Camera

    8. Ultra Bullet Camera 8.1 Packing List • Ultra Bullet Camera (with Waterproof or Non-Waterproof LAN connector) • Camera Stand • Black Rubber • Self Tapping Screw x 3 • Plastic Screw Anchor x 3 • Torx Wrench • Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) •...

  • Page 97: Overview

    Ultra Bullet Camera 8.2 Overview Panel Name Description Connects to the data cable. For details, see Power & I/O 8.4. Connecting the Camera in the Quick Start Connector Guide. Resets all configurations to factory default. See Default Button 19. Restoring to Default Settings in the Quick Start Guide.
  • Page 98 LAN Connector The Ultra Bullet Camera provides two connector types. Select an option based on your installation environment. • Option 1 (Waterproof) To waterproof the cable, install the supplied cable connector. See 8.4.3 Waterproofing the Cable in the Quick Start Guide. •...

  • Page 99: Installation

    Put the sun-shield cover on top of the hexagon screws. For optimal sun-shield performance, make sure the rear hexagon screw is at the end of the opening. Sun-Shield Cover IMPORTANT: The GeoVision logo on the sun-shield cover should be closer to the front of the camera.
  • Page 100 Fasten the Philips head screws with the plastic screw spacers. Philips Head Screw Plastic Screw Spacer Optionally insert a micro SD card to the camera. Unscrew and open the back panel with the supplied torx wrench. Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the card slot.
  • Page 101 Ultra Bullet Camera Replace the silica gel bag. IMPORTANT: 1. The silica gel loses its effectiveness when the dry camera is opened. To keep the interior dry, replace the silica gel bag every time you open the camera and conceal the gel bag in the camera within two minutes of exposing to the open air.
  • Page 102 Install the camera to the wall or ceiling using the screw anchors and self-tapping screws. You can also stand the camera on a plain surface. Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 8.4 Connecting the Camera and 8.4.3 Waterproofing the Cable in the Quick Start Guide.

  • Page 103: Connecting The Camera

    Ultra Bullet Camera 8.4 Connecting the Camera 8.4.1 Wire Definition The supplied 4-pin data cable provides connections for power, ground, 1 sensor input and 1 alarm output. The wires are defined below: Wire Color Definition DC 5V Green Digital In Blue Digital Out Black...

  • Page 104: Power Connection

    8.4.2 Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. • Plug the power adaptor to the terminal block as shown below. The power adapter is an optional device.

  • Page 105: Waterproofing The Cable

    Ultra Bullet Camera 8.4.3 Waterproofing the Cable Waterproof the option 1 LAN / PoE cable (see 8.2 Overview) using the supplied cable connector. The cable connector can be dissembled into 5 parts: Prepare an internet cable with the RJ-45 connector on one end only. Connect the internet cable to the LAN / PoE connector.
  • Page 106 Move all the components toward the LAN / PoE connector, fit item 4 to item 2, secure item 3 to the camera cable and finally secure item 5 to item 2 tightly. IMPORTANT: Item 5 must be secured tightly to waterproof the LAN / PoE connector.

  • Page 107: Target Bullet Camera

    9. Target Bullet Camera 9.1 Packing List • Target Bullet Camera • Sun-Shield Cover • Silica Gel Tape x 2 • Supporting Rack • Screw x 4 • Screw Anchor x 3 • GV-IPCAM H.264 Software CD • GV-IPCAM H.264 Quick Start Guide •...

  • Page 108: Overview

    9.2 Overview Panel Name Description Power Connects to the data cable. For details, see Connector 9.4.1 Connecting the Camera. Resets all configurations to factory default. See Default Button 19. Restoring to Factory Default Settings.
  • Page 109 Target Bullet Camera IMPORTANT: 1. The silica gel loses its effectiveness when the camera is opened. If you open the camera to access the load default button, replace the silica gel tape by taping the new silica gel tape to the inside of the camera cover. Make sure you conceal the silica gel tape in the camera within two minutes of exposing to the open air.

  • Page 110: Installation

    You can install the camera to the ceiling or wall. Follow the steps below. Slide the sun-shield cover onto the top of the camera. Note: The GeoVision logo on the sun-shield cover should be closer to the front of the camera.
  • Page 111 Target Bullet Camera Ceiling Mount: Secure the supporting rack to the opening on the sun-shield cover Wall Mount: Insert and tighten the supplied screw on the sun-shield cover. Secure the supporting rack to the bottom.
  • Page 112 Install the camera to the wall or ceiling using the screw anchors and self-tapping screws. You can also stand the camera on a plain surface. Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 9.4 Connecting the Camera in the Quick Start Guide.

  • Page 113: Connecting The Camera

    Target Bullet Camera 9.4 Connecting the Camera 9.4.1 Wire Definition The data cable provides connections for power, ground and network access. The wires are defined below: Wire Color Definition DC 12V Black Ground Black (thick) PoE, Ethernet...

  • Page 114: Power Connection

    9.4.2 Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. • Plug the power adaptor to the terminal block as shown below. The power adapter is an optional device.

  • Page 115: Vandal Proof Ip Dome (Part I)

    10. Vandal Proof IP Dome (Part I) The information in this chapter applies to GV-VD120D / 121D / 122D / 123D / 220D / 221D / 222D / 223D / 320D / 321D / 322D / 323D / 1500 / 2400 / 3400.
  • Page 116 • GV-IPCAM H.264 Quick • GV-IPCam H.264 Software Start Guide • GV-NVR Quick Start Guide • GV-NVR Software DVD Note: 1. Focus Adjustment Cap is only needed and supplied for IK10+ models. 2. Power adapter can be purchased upon request.

  • Page 117: Overview

    Vandal Proof IP Dome (Part I) 10.2 Overview Name Description Turns on (green) when the power is on and Power LED turns off when there is no power supply. Turns on (green) when the system Status LED operates normally and turns off when system error occurs.
  • Page 118 Name Description Zoom Screw Adjusts the zoom of the camera. Focus Screw Adjusts the focus of the camera. Silica Gel Bag Absorbs moisture in the camera body.

  • Page 119: Installation

    Vandal Proof IP Dome (Part I) 10.3 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, there are two ways to install the Vandal Proof IP Dome: hard-ceiling mount and in-ceiling mount. Note: The standard package allows you to install the camera to the power box of 4"...
  • Page 120 Unscrew thread lock Unscrew the inner housing Take out the camera body...
  • Page 121 Vandal Proof IP Dome (Part I) Mark the position of four screw holes on the desired installation location, and drill holes in the marked locations. Drill the ellipse part if you wish to put the wires through it. Insert the screw anchors to the 4 holes on the ceiling. Secure the back cover to the ceiling with 4 ceiling screws.
  • Page 122 Access the live view. See 16.2. Accessing the Live View in the Quick Start Guide. Adjust the camera to a desired angle as illustrated below. Tip: The 3-axis mechanism offers flexible and easy installation. Pan Adjustment Tilt Adjustment...
  • Page 123 Vandal Proof IP Dome (Part I) Rotational Adjustment 10. Hold the focus adjustment cap on top of the camera view and adjust for image clarity using the GV-IP Device Utility program. For details, see 16.3 Adjusting Image Clarity in the Quick Start Guide. Focus Screw Zoom Screw 11.
  • Page 124 IMPORTANT: 1. The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag to the camera within 2 minutes of exposing to open air.

  • Page 125: In-Ceiling Mount

    Vandal Proof IP Dome (Part I) 10.3.2 In-Ceiling Mount Follow step 1 in the Hard-Ceiling Mount section to remove the housing cover, thread lock and back cover, and take out the camera body. Cut out a circle with a diameter of 142 mm on the ceiling. Insert a blue screw to the indicated holes on the camera body.
  • Page 126 Screw in a plastic clip to the blue screw, hold it with one hand and use a screw driver to rotate the blue screw until the plastic clip moves half way down. Plastic Clip Secure a T-cap on top of the blue screw with a small screw cap and a T-cap screw.
  • Page 127 Vandal Proof IP Dome (Part I) Insert the camera to the ceiling with the plastic screws moved inward. Move the blue screws out and rotate the blue screw with a screw driver until the plastic clip and the bottom of the camera body clamps the ceiling tightly.

  • Page 128: Connecting The Camera

    10.4 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other cables. 10.4.1 Wire Definition The cables for Vandal Proof IP Dome are illustrated and defined below. Shielding ground DC 12V- / AC 24V- DC 12V+ / AC 24V+ Digital in (oragne) Digital out (brown) Ground (yellow)
  • Page 129 Vandal Proof IP Dome (Part I) Note: To use the TV out function, connect the black BNC connector to a monitor and select your signal format (NTSC or PAL) at the TV Out field on the Web interface. For details, see Video Settings, Administrator Mode Chapter, GV-IPCam H.264 User’s Manual on the Software CD.

  • Page 130: Connecting The Power Cable

    10.4.2 Connecting the Power Cable There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. •...

  • Page 131: Vandal Proof Ip Dome (Part Ii)

    11. Vandal Proof IP Dome (Part II) The information in this chapter applies to GV-VD1530 / 1540 / 2430 / 2440 / 2530 / 2540 / 2540-E / 3430 / 3440 / 5340 / 5340-E. 11.1 Packing List • Vandal Proof IP Dome •...
  • Page 132 • RJ-45 Connector x 2 • Back Plate • Installation sticker • Screw Anchor x 4 Ceiling mount template • Long Screw x 4 • Flat Screw • Short Screw x 2 • Silica Gel Bag • Sticker (for Silica Gel Bag) •...
  • Page 133 Vandal Proof IP Dome (Part II) • GV-IPCAM H.264 Quick • GV-NVR Software DVD Start Guide • GV-NVR Quick Start Guide Note: 1. Power adapter can be purchased upon request. 2. You can choose to run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter with a self-prepared PG21 conduit connector and conduit pipe (of 1/2’’, 3/4’’...

  • Page 134: Overview

    11.2 Overview...
  • Page 135 Vandal Proof IP Dome (Part II) Name Description LED Indicators The power LED (top) turns on (green) when the power is on and turns off when there is no power supply. The status LED (bottom) turns on (green) when the system operates normally and turns off when system error occurs.

  • Page 136: Installation

    11.3 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Note: The standard package allows you to install the camera to the power box of 4" square and double gang. You may also install the camera to ceilings, wall surfaces, wall corners (concave or convex), and poles using the optional mounting kits.
  • Page 137 Vandal Proof IP Dome (Part II) B. Unplug the conduit connector inside the housing and disintegrate the connector. You should have 4 parts: C. Remove the terminal block from the power adapter. D. Thread the audio wires (optional), TV out wire (optional), adapter wires and I/O wires (optional) through the conduit entry and then through part 1, 2, 3 and 4 of the conduit connector.
  • Page 138 For part 2, there are 8 holes each labeled with its diameter. Remove the plugs and push the wires to the corresponding hole listed below: Plug Hole Diameter Applied to 2.6 mm Audio in and audio out TV out wire 2 mm Adapter wires 1.8 mm...
  • Page 139 Vandal Proof IP Dome (Part II) Connect the wires to the camera. Install the terminal blocks to the power adapter and I/O devices. See 11.4 Connecting the Camera in the Quick Start Guide. Install the supplied RJ-45 connector to the Internet cable. Plug all the connectors to the camera panel.
  • Page 140 Sort out the wires at the back. You can have the wires come out from position A, B or both. The instructions here describe sorting wires for position A. From the back of the camera housing, unscrew and rotate the plate to one side, sort out the wires and secure the plate back.
  • Page 141 Vandal Proof IP Dome (Part II) Secure the back plate to the ceiling. A. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces. Ceiling mount template B. Drill 3 holes for screws. The recommended ones are indicated as ‘1’.
  • Page 142 Secure the camera to the ceiling. Secure the safety lock to the camera using a short screw. Use flat screw for number 1 and small screw for number 2. Thread all the wires into the ceiling and connect them. Note: To use the TV out function, connect the black BNC connector to a monitor and select your signal format (NTSC or PAL) at the TV Out field on the Web interface.
  • Page 143 Vandal Proof IP Dome (Part II) C. Secure the camera using the torx wrench Access the live view. See 16.2 Accessing the Live View in the Quick Start Guide. Adjust the camera’s angle, focus and zoom of the camera. Pan Adjustment...
  • Page 144 Tilt Adjustment Rotational Adjustment...
  • Page 145 Vandal Proof IP Dome (Part II) Replace the silica gel bag and secure the camera cover using the torx wrench. IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag within 2 minutes of exposing to open air.

  • Page 146: Connecting The Camera

    11.4 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other wires needed. 11.4.1 Connecting the Power Cable There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.

  • Page 147: Connecting The I/O Device

    Vandal Proof IP Dome (Part II) 11.4.2 Connecting the I/O Device The Box Camera support one digital input and one digital output of dry contact. Function Digital Output Digital Input For details on how to enable an installed I/O device, see I/O Settings, Administrator Mode Chapter, GV-IPCam H.264 User’s Manual on the Software CD.

  • Page 148: Fixed Ip Dome

    12. Fixed IP Dome 12.1 Packing List 12.1.1 Packing List for Hard-Ceiling Mount • Fixed IP Dome • Torx Wrench • Mounting Plate • Short Screw Anchor x 3 • Ceiling Screw x 3 • Plate Screw x 3 • TV-out Wire •...

  • Page 149: Packing List For In-Ceiling Mount

    Fixed IP Dome 12.1.2 Packing List for In-Ceiling Mount • In-Ceiling Housing Cover • Mounting Plate • Mounting Bracket x 3 • Copper Pillar x 3 • Copper Pillar Screw x 6 • Bracket Screw x 3 • Thread Lock Screw •...

  • Page 150: Overview

    12.2 Overview 10 11 12 13 14 15 Name Description Focus Screw Adjusts the focus of the camera. Zoom Screw Adjusts the zoom of the camera. Rotational Screw Loosens to adjust the camera angle. Tilt Screw Loosens the screw to tilt the camera. Pan Disc Loosens to pan the camera.
  • Page 151 Fixed IP Dome Name Description Audio Out Connects a speaker for audio output. LAN / PoE Connects to a 10/100 Ethernet or PoE. Connects to I/O devices. For details, see I/O Terminal Block Fixed IP Dome Chapter in the GV-IPCam H.264 User’s Manual on the Software CD.

  • Page 152: Installation

    12.3 Installation The Fixed IP Camera is designed for indoors. With the standard packing, there are three ways to install the Fixed IP Camera: hard-ceiling mount, in-ceiling mount and wall-surface mount. Note: You may also install the camera to ceilings, wall corners (concave or convex), and poles using the optional mounting kits.
  • Page 153 Fixed IP Dome Take out the camera body Secure the camera body and the mounting plate to the ceiling with the three ceiling screws. Ceiling mounting plate Connect the network and power cables to the camera. See 12.4 Connecting the Camera in the Quick Start Guide. Access the live view.
  • Page 154 Pan Adjustment Tilt Adjustment Rotational Adjustment...
  • Page 155 Fixed IP Dome Adjust for image clarity using the GV-IP Device Utility program. For details, see 16.3 Adjusting Image Clarity in the Quick Start Guide. Focus Screw Zoom Screw Secure the housing cover as shown in step 2. Remove the indicated part when necessary.

  • Page 156: In-Ceiling Mount

    12.3.2 In-Ceiling Mount Follow step 2 in the Hard-Ceiling Mount section to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the ceiling and cut a circle on the ceiling along the edge of the sticker. On the mounting plate, locate the 3 holes labeled as 1 and insert the 3 copper pillars from the back side.
  • Page 157 Fixed IP Dome Place the 3 mounting brackets at the indent next to the copper pillars (labeled as 2 on the mounting plate) and secure them using the 3 bracket screws. Place the mounting plate on the camera body with the copper pillars inserted in the locations indicated below.
  • Page 158 On the back side, make sure the black plastic clips are slightly above the ceiling board and pointing outward. Back Side Front Side 10. Tighten the bracket screws from the front side of the camera. 11. Connect the network and power cables to the camera. See 12.4 Connecting the Camera in the Quick Start Guide.
  • Page 159 Fixed IP Dome 15. Place the housing cover on the camera body with the GeoVision logo pointing toward the front of the camera.

  • Page 160: Wall-Surface Mount

    12.3.3 Wall-Surface Mount Follow step 2 in the Hard-Ceiling Mount section to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the wall. Drill the three red dots, and the ellipse mark only if you wish to run the wires into the wall.
  • Page 161 Fixed IP Dome Follow steps 6 and 7 in the Hard-Ceiling Mount section to adjust the angle, focus and zoom of the camera. Follow step 8 in the Hard-Ceiling Mount section to secure the housing cover.

  • Page 162: Connecting The Camera

    12.4 Connecting the Camera Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Optionally connect a monitor using a Video Out wire. Enable the function by selecting the signal format in the TV Out field in the Web interface.

  • Page 163: Cube Camera

    13. Cube Camera 13.1 Packing List • Cube Camera • Supporting Rack • Screw x 3 • Screw Anchor x 3 • GV-IPCAM H.264 Quick • GV-IPCam H.264 Software Start Guide • GV-NVR Quick Start Guide • GV-NVR Software DVD Note: Power adapter can be purchased upon request.

  • Page 164: Overview

    Turns green when the camera is connected to the LAN LED Internet. Turns blue when the wireless service is enabled (for GV-CBW120 / 220 only). Stand screw Connects to the Supporting Rack. Resets to factory default. For details, see 19.
  • Page 165 Cube Camera Name Description Wireless LAN Indicates that the camera supports wireless Receiver connection (for GV-CBW120/220 only).

  • Page 166: Installation

    13.3 Installation Follow the steps below to install, connect to and adjust your Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Drill the marks and insert the screw anchors. Secure the supporting rack onto the wall using the supplied screws. Screw the camera onto the supporting rack and fasten the indicated screw.
  • Page 167 Cube Camera Adjust the angles of the camera based on live view and fasten the indicated screw. For GV-CBW120/220, to connect to the Internet through wireless service, follow the steps in 16.2.3 Configuring the Wireless Connection in the Quick Start Guide.

  • Page 168: Connecting The Camera

    See 16. Accessing the Camera in the Quick Start Guide. IMPORTANT: Be sure to use the GeoVision power adapter to power up the camera. To use your own power cable, make sure you look up the...

  • Page 169: Advanced Cube Camera

    14. Advanced Cube Camera 14.1 Packing List • Cube Camera • Supporting Rack • Screw x 3 • Screw Anchor x 3 • GV-IPCAM H.264 Quick • GV-IPCam H.264 Software Start Guide • GV-NVR Quick Start Guide • GV-NVR Software DVD Note: Power adapter can be purchased upon request.

  • Page 170: Overview

    14.2 Overview 2 3 4 5 6 7 Name Description Plays sounds for tampering and motion alarm, and listens to the audio around the camera. To Speaker set up alarm sound, see Speaker section, Administrator Mode Chapter, GV-IPCam H.264 User’s Manual on the Software CD. PIR sensor Passive infrared sensor.
  • Page 171 Advanced Cube Camera Name Description Stand screw Connects to the Supporting Rack. Power port Connects to the power adapter. Reflects system status of the camera. See the Ready LED below table. Reflects LAN status of the camera. See the below LAN LED table.

  • Page 172: Installation

    14.3 Installation Follow the steps below to install, connect to and adjust your Advanced Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Drill the marks and insert the screw anchors. Secure the supporting rack onto the wall using the supplied screws. Screw the camera onto the supporting rack and fasten the indicated screw.
  • Page 173 Advanced Cube Camera Connect the network and power cables to the camera. See 14.5 Connecting the Camera in the Quick Start Guide. Access the live view. See 16.2 Accessing the Live View in the Quick Start Guide. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 174: Connecting The Camera

    14.4 Connecting the Camera Use a standard network cable to connect the camera to your network. Connect power using one of the following methods: • Plug the power adapter to the power port. The power adapter is an optional device. For detail, see Options in the Quick Start Guide. •...

  • Page 175: Pt Camera

    15. PT Camera 15.1 Packing List • GV-PT130D/220D/320D • Mounting Base • Mounting Cover • Wall Mount Bracket • Screw Anchor x 3 • Long Screw x 3...
  • Page 176 • Short Screw x 3 • Round Screw x 3 • Terminal Block • Washer x 3 • GV-IPCAM H.264 Software CD • Washer x 3 • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: Power adapter can be purchased upon request.

  • Page 177: Overview

    PT Camera 15.2 Overview 6 7 8...
  • Page 178 Name Description DC 12V / AC 24V Connects to a DV 12V or AC 24V Power Terminal Block Adapter. LAN / PoE Connects to a 10/100 Ethernet or PoE. Connects to I/O terminal device. For details, see I/O Terminal Block, PTZ I/O Terminal Block Camera Chapter, GV-IPCam H.264 User’s Manual on the Software CD.

  • Page 179: Installation

    PT Camera 15.3 Installation The GV-PT series is designed for indoor usage. Make sure that the installing location is shielded from rain and moisture. There are two ways to install the camera: Ceiling Mount and L-Shaped Wall Mount. 15.3.1 Ceiling Mount Use the mounting base to make 3 marks on the wall for screw anchors.
  • Page 180 Fix the mounting base (now with the PT Camera attached) to the wall with 3 long screws. Put on the mounting cover. To fit the installation environment, you can cut the parts indicated by arrows to make an opening for wires and cables.

  • Page 181: L-Shaped Wall Mount

    PT Camera 15.3.2 L-Shaped Wall Mount You may wall-mount the GV-PT series with or without the mounting cover. Take the wall mount bracket and make 2 marks on the wall for screw anchors. Drill the marks and insert 2 screw anchors. Insert the long screws and leave enough distance (approximately 2 mm) to hang the wall mount bracket later.
  • Page 182 Hang the wall mount bracket on the screws and push the wall mount bracket downward. Make sure the long screws are tightened. Without Mounting Cover Attach the wall mount bracket with the PT Camera using 3 washers and 3 round screws.
  • Page 183 PT Camera With Mounting Cover To install the mounting cover, attach the mounting base to the camera and then put on the mounting cover. See steps 3 and 5 in 15.3.1 Ceiling Mount. Attach the wall mount bracket with the PT Camera using 3 round screws.

  • Page 184: Connecting The Camera

    15.4 Connecting the Camera Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Connect power using one of the following methods: • plugging the power adapter to the power port. The power adapter is an optional device.

  • Page 185: Accessing The Camera

    16. Accessing the Camera 16.1 System Requirement To access the GV-IP Camera through the Web browser, ensure your PC connects to the network properly and meets this system requirement: • Microsoft Internet Explorer 7.x or later Note: For the users of Internet Explorer 8, additional settings are required.

  • Page 186: Accessing The Live View

    • GV-PT110D connected to the network. • GV-PTZ010D To avoid IP conflict with other GeoVision IP devices, it is advisable to re-assign a different IP address. See 16.2.2 Configuring the IP Address in the Quick Start Guide for more detail.

  • Page 187: Checking The Dynamic Ip Address

    Accessing the Camera 16.2.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Install the GV-IP Device Utility program included on the GV-IPCAM H.264 software CD. Note: The PC installed with GV-IP Device Utility must be under the same LAN with the GV-IPCAM H.264 you wish to configure.
  • Page 188 The login page appears. Type the default ID and password admin and click Apply to log in.

  • Page 189: Configuring The Ip Address

    Click Apply. The camera is now accessible by entering the assigned IP address on the Web browser. To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a one-time installation of GeoVision’s ActiveX component onto your computer.
  • Page 190 IMPORTANT: If Dynamic IP Address or PPPoE is enabled, you need to know which IP address the camera will get from DHCP server or ISP to log in. If your camera is installed in the LAN, use the GV-IP Device Utility to look up its current dynamic IP address.

  • Page 191: Configuring The Wireless Connection

    You may create wireless connection to the Internet for GV-BX1200 series / 1300 series / 1500 series / 2400 series / 3400 series / 5300, GV-MFD1501 Series / 2401 series / 3401 series / 5301 series, GV-CBW120 / 220 and GV-CAW120/220.
  • Page 192 C. Select Ad-Hoc or Infrastructure for the Network type. D. Select the Authentication Type using the drop-down list. You can also obtain this information by clicking the Access Point Survey button. E. Type the WPA-PSK Pre-shared Key or WEP depending on the encryption setting for the Access Point.
  • Page 193 Click Apply. The camera will start creating a wireless connection to the access point. Note: For GV-CBW120/220 and GV-CAW120/220, the LAN LED (No. 5, 13.2 Overview and No.11, 14.2 Overview in the Quick Start Guide) turns blue when the connection is established.
  • Page 194 Unplug the Ethernet cable.

  • Page 195: Adjusting Image Clarity

    Accessing the Camera 16.3 Adjusting Image Clarity You can adjust the image clarity using the GV-IP Device Utility. Make sure that you have connected your GV-IPCAM H.264 to the network and install the GV-IP Device Utility program under the same LAN. Note: This feature is only supported by Box Camera, IR Arctic Box Camera, Bullet Camera, Mini Fixed Dome, Mini Fixed Rugged Dome, Vandal Proof IP Dome, and Fixed IP Dome.
  • Page 196 Type the user name and password of the camera selected. The default is admin for both user name and password. This window appears. For IK10+ models (GV-VD120D / 121D / 220D / 221D / 320D / 321D / 1500 / 2400 / 3400), hold the supplied Focus Adjustment Cap over the camera view.

  • Page 197: Using Focus Adjustment Cap

    Accessing the Camera 16.3.1 Using Focus Adjustment Cap There are two types of Focus Adjustment Caps for GV-VD120D / 121D / 220D / 221D / 320D / 321D / 1500 / 2400 / 3400. Focus Adjustment Cap Type I: Hold the Focus Adjustment Cap on top of the camera view, keep it close to the lens and slightly tilt to one side to adjust the image.
  • Page 198 Do not leave a distance between the Focus Adjustment Cap and the camera.

  • Page 199: The Web Interface

    17. The Web Interface 11 12...
  • Page 200 No. Name Function Play Plays live video. Stop Stops playing video. Broadcasts to the surveillance site from a remote Microphone PC. Note this function is not available for Ultra Bullet Camera and Target Series. Transfers sounds of the surveillance site to a remote PC.
  • Page 201 The Web Interface No. Name Function Click to turn the Alarm LED on and/or adjust the LED Control brightness sensitivity. Note this function is only available for Advanced Cube Camera. Click to sound the alarm and/or adjust its volume. To sound the alarm upon motion or tampering Alarm events, see Speaker section, Administrator Mode Speaker...

  • Page 202: Upgrading System Firmware

    18. Upgrading System Firmware GeoVision periodically releases updated firmware on the website. The new firmware can be simply loaded into the GV-IPCAM H.264 by using the Web interface or IP Device Utility included in the software CD. IMPORTANT: To update the camera firmware from versions earlier than V2.07 to the latest version, back up the files in the storage device to another device before the upgrade.
  • Page 203 Click the Upgrade button to start the upgrade. WARNING: The interruption of power supply during updating causes not only update failures but also damages to the camera. In this case, please contact your sales representative and send your device back to GeoVision for repair.

  • Page 204: Restoring To Default Settings

    19. Restoring to Default Settings GeoVision periodically releases updated firmware on the website. You can restore factory default settings through the Web interface or directly on the camera. 19.1 Using the Web Interface On the left menu of Web interface, select Management and select Tools.

  • Page 205: Directly On The Camera

    Restoring to Default Settings 19.2 Directly on the Camera Box Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Release the default button when the status LED blinks.

  • Page 206: Ultra Box Camera And Target Box Camera

    Ultra Box Camera and Target Box Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 207: Mini Fixed Dome

    Restoring to Default Settings Mini Fixed Dome Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button. • GV-MFD120 / 130 / 220 / 320 / 520 Default button Status LED • GV-MFD1501 Series / 2401 Series / 3401 Series / 5301 Series Release the default button when the status LED blinks.

  • Page 208: Mini Fixed Rugged Dome

    Mini Fixed Rugged Dome Keep the power and network cables connected to the camera. Press and hold the default button. Status LED Default button Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.

  • Page 209: Bullet Camera

    Restoring to Default Settings Bullet Camera Keep the power and network cables connected to the camera. Loosen the camera’s cover and remove the Silica Gel Bag. Press and hold the default button for 8 seconds. Default button Release the default button. When the process of loading default settings is completed, the camera reboots automatically.

  • Page 210: Target Bullet Camera

    Target Bullet Camera Keep the power and network cables (or PoE) connected to the camera. Loosen the camera’s cover. Press and hold the default button for about 8 seconds. Release the default button. When the process of loading default settings is completed, the camera reboots automatically. Replace the Silica Gel Tape inside the camera cover and fasten the camera’s cover immediately.

  • Page 211: Vandal Proof Ip Dome

    Restoring to Default Settings Vandal Proof IP Dome Keep the power and network cables (or PoE) connected to the camera. Use a pin to press and hold the default button on the inner housing. Default button Status LED Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 212: Fixed Ip Dome

    Fixed IP Dome Keep the power and network cables (or PoE) connected to the camera. Use a pin to press and hold the default button on the panel. Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.

  • Page 213: Advanced Cube Camera

    Restoring to Default Settings Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED turns orange, the process of loading default settings is completed and the camera is ready for use. Advanced Cube Camera Keep the power and network cables connected to the camera.

  • Page 214: Pt Camera

    PT Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the panel. Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED turns orange, the process of loading default settings is completed and the camera is ready for use.

This manual is also suitable for:

Gv-cbw220

Table of Contents
