Gv-Mdr120 / 220 / 320 / 520 - GeoVision GV-IPCAM User Manual

5.3.2 GV-MDR120 / 220 / 320 / 520

No. Name
1 Silica gel bag
2 Conceal paper
3 Lens
4 Rotation Disc
5 Pan Disc
6 Tilt Screw
7 Built-In Microphone
8 Default Button
5
3
1
4
2
5
8
9
10
Figure 5-2
Description
Absorbs the moisture inside the camera.
Prevents water or moisture from entering
the camera.
Receives image inputs.
Rotates the camera lens.
Pans the camera lens.
Loosens to tilt the camera.
Provides one-way audio.
Resets the camera to factory default. See
18.3 Restoring to Factory Default
Settings.
Mini Fixed & Rugged Dome
6
7
53
