Chapter 2 Box Camera

The Box Camera series offers fixed focal or varifocal models, ranging from
1.3 to 5 megapixel and is designed with an automatic infrared cut filter for
day and night surveillance.
Box Camera
Model No.
GV-BX120D
GV-BX130D-0
GV-BX130D-1
GV-BX140DW
GV-BX220D-2
GV-BX220D-3
Specifications
Varifocal
Lens
Fixed Lens
Varifocal
Lens
Megapixel, Auto Iris,
f:2.8 ~ 12 mm, F/1.4,
1/3" CS Lens
Megapixel, Auto Iris,
f: 2.8 ~ 12 mm,
F/1.4, 1/3'' CS Lens
Megapixel, Fixed Iris,
f: 4 mm, F/1.4,
1/3'' CS Lens
Megapixel, Fixed Iris,
f: 2.8 ~ 12 mm,
F/1.4, 1/3'' CS Lens
Megapixel, Auto Iris,
f: 2.8 ~ 6 mm,
F/1.3, 1/3'' CS Lens
Megapixel, Auto Iris,
f: 2.8 ~ 12 mm,
F/1.4, 1/3'' CS Lens
Description
1.3 MP, H.264,
Low Lux, D/N
1.3 MP, H.264,
D/N
1.3 MP, H.264,
D/N
1 MP, H.264,
D/N, WDR Pro
2 MP, H.264,
D/N
