Table of Contents

Advertisement

Quick Links

See also: User Manual
GV-IPCam H.264
User's Manual
Before attempting to connect or operate this product,
ICH264TIV212-A
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-BX120D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-BX120D

Summary of Contents for GeoVision GV-BX120D

  • Page 1 GV-IPCam H.264 User's Manual Before attempting to connect or operate this product, ICH264TIV212-A please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Safety Notice FCC Compliance for GV-CBW120/220 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.
  • Page 4 Firmware Model Model Number Version GV-BX120D Varifocal Lens GV-BX130D-0 Varifocal Lens GV-BX130D-1 Fixed Lens GV-BX140DW Box Camera V2.11...
  • Page 5 Firmware Model Model Number Version GV-BX1200-0F ~ 2F GV-BX1300-0F ~ 2F GV-BX1500-0F ~ 2F Fixed Lens GV-BX2400-0F ~ 2F GV-BX2500-0F ~ 2F GV-BX3400-0F ~ 2F GV-BX1200-3V GV-BX1300-3V GV-BX1500-3V GV-BX2400-3V Box Camera V2.11 GV-BX2500-3V Varifocal Lens GV-BX2400-4V GV-BX3400-4V GV-BX3400-5V GV-BX5300-6V GV-BX1500-8F GV-BX2400-8F Fixed Lens GV-BX2500-8F...
  • Page 6 Firmware Model Model Number Version GV-BX120D-E GV-BX220D-E GV-BX320D-E GV-BX520D-E IR Arctic Box Varifocal Lens V2.11 GV-BX1500-E Camera GV-BX2400-E GV-BX3400-E GV-BX5300-E GV-MFD120 GV-MFD130 GV-MFD220 GV-MFD320 GV-MFD520 Mini Fixed V2.11 Fixed Lens Dome GV-MFD1501 Series GV-MFD2401 Series GV-MFD2501 Series GV-MFD3401 Series GV-MFD5301 Series...
  • Page 7 Firmware Model Model Number Version GV-MDR120 GV-MDR220 V2.11 GV-MDR320 GV-MDR520 Mini Fixed Fixed Lens GV-MDR1500 Series Rugged Dome GV-MDR2400 Series V2.12 GV-MDR2500 Series GV-MDR3400 Series GV-MDR5300 Series Coming GV-EFD1100-0F Target Mini Fixed Lens Fixed Dome V1.00 GV-EFD1100-1F GV-EBL1100-0F Target Bullet Fixed Lens V1.00 Camera...
  • Page 8 Firmware Model Model Number Version GV-BL120D GV-BL130D GV-BL220D GV-BL320D GV-BL1200 Varifocal Lens GV-BL1300 GV-BL1500 V2.11 GV-BL2400 Bullet Camera GV-BL2500 GV-BL3400 GV-BL1210 GV-BL1510 GV-BL2410 Motorized GV-BL2510 Varifocal Lens GV-BL3410 V2.12 GV-BL5310 NTSC PTZ Camera GV-PTZ010D V1.09 GV-PT130D PT Camera Fixed Lens V2.11 GV-PT220D GV-PT320D...
  • Page 9 Firmware Model Model Number Version GV-VD120D (IK10+, Transparent Cover) GV-VD121D (IK10+, Smoked Cover) GV-VD122D (IK7, Transparent Cover) GV-VD123D (IK7, Smoked Cover) GV-VD220D (IK10+, Transparent Cover) GV-VD221D (IK10+, Smoked Cover) GV-VD222D Vandal Proof (IK7, Transparent Cover) Varifocal Lens V2.11 IP Dome GV-VD223D (IK7, Smoked Cover) GV-VD320D...
  • Page 10 Firmware Model Model Number Version GV-VD1530 Varifocal Lens, GV-VD2430 high power IR Coming GV-VD2530 LEDs GV-VD3430 GV-VD1540 Motorized GV-VD2440 V2.11 Varifocal Lens, Vandal Proof GV-VD2540 high power IR IP Dome GV-VD3440 LEDs V2.12 GV-VD5340 Motorized GV-VD2540-E V2.11 Varifocal Lens, high power IR LEDs, extreme GV-VD5340-E V2.12...
  • Page 11 Firmware Model Model Number Version GV-FD120D GV-FD220D V2.11 GV-FD320D GV-FD1200 Varifocal GV-FD1500 Lens GV-FD2400 GV-FD2500 Fixed IP Dome GV-FD3400 GV-FD5300 V2.12 GV-FD1210 GV-FD1510 Motorized GV-FD2410 Varifocal Lens GV-FD2510 GV-FD3410...

  • Page 12: Table Of Contents

    For GV-IPCam H.264 models that support WDR, the WDR effect is achieved through software programming........9 2.3 Overview..................10 2.3.1 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D................10 2.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series......
  • Page 13 Series / 2500 Series / 3400 Series / 5300 Series......16 2.5 Accessory Installation ..............18 2.5.1 C-Mount Lenses..............18 2.5.2 Infrared Illuminators (Optional) ..........19 2.6 I/O Terminal Block ..............20 2.6.1 Pin Assignment ..............20 2.6.2 Connecting to GV-Relay V2 (Optional) ........ 21 Chapter 3 Ultra Box Camera ..........22 3.1 Packing List................23 3.2 Features..................24...
  • Page 14 5.6.2 Disabling Status LED under Low Light Conditions ....47 Chapter 6 Mini Fixed Dome & Mini Fixed Rugged Dome.................48 6.1 Packing List................51 6.2 Features..................52 6.3 Overview..................55 6.3.1 GV-MFD120 / 130 / 220 / 320 / 520........55 6.3.2 GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series..............
  • Page 15 8.4.1 Connecting the Camera ............87 8.4.2 Adjusting the Angles ............91 8.4.3 Adjusting Lens and Inserting a Memory Card ...... 95 8.4.4 Installing the Sun-Shield Cover ........... 98 Chapter 9 Ultra Bullet Camera........99 9.1 Packing List................101 9.2 Features...................102 9.3 Overview..................104 9.4 Installation................106 9.4.1 Connecting the Camera ............
  • Page 16 11.7.2 Voltage Load Expansion (Optional) ......... 137 11.8 PTZ Control ................138 11.8.1 The PTZ Control Panel............. 138 11.8.2 Automatic Focus .............. 140 11.8.3 PTZ Camera Settings............140 11.8.4 Image Settings ..............142 11.8.5 Preset Settings..............145 11.8.6 Sequence Settings ............148 11.8.7 Auto Pan Settings ............
  • Page 17 13.5.1 Wire Definition..............178 13.5.2 Power Connection............179 13.5.3 Voltage Load Expansion (Optional) ......... 180 Chapter 14 Vandal Proof IP Dome (Part II) ....181 14.1 Packing List................183 14.2 Features.................186 14.3 Overview................188 14.4 Installation................190 14.5 Connecting the Camera ............200 14.5.1 Power Connection............200 14.5.2 I/O Device Connections...........
  • Page 18 16.2 Features.................225 16.3 Overview................226 16.4 Installation................227 16.5 Connecting the Camera ............229 Chapter 17 Advanced Cube Camera......230 17.1 Packing List................231 17.2 Features.................232 17.3 Overview................233 17.4 Installation................235 17.5 Connecting the Camera ............237 Chapter 18 Getting Started ..........238 18.1 Accessing the Live View............238 18.1.1 Checking the Dynamic IP Address........
  • Page 19 19.2.7 Video and Audio Configuration ........275 19.2.8 Remote Configuration ............. 277 19.2.9 Camera Name Display ............ 277 19.2.10 Image Enhancement ............. 277 19.2.11 Visual PTZ ..............278 19.2.12 Digital PTZ ..............281 19.2.13 I/O Control..............283 19.2.14 Visual Automation ............284 19.2.15 Network Status..............
  • Page 20 20.3.9 Speaker ................330 20.4 Monitoring ................331 20.4.1 Monitoring Settings for Target Series....... 332 20.5 Recording Schedule .............333 20.5.1 Recording Schedule Settings .......... 333 20.5.2 I/O Monitoring Settings ............ 334 20.6 Remote ViewLog ..............335 20.7 Network .................336 20.7.1 LAN Configuration............336 20.7.2 Wireless Client Mode ............
  • Page 21 Chapter 22 Advanced Applications......371 22.1 Upgrading System Firmware..........371 22.1.1 Using the Web Configuration Interface ......373 22.1.2 Using the IP Device Utility..........374 22.2 Backing Up and Restoring Settings ........376 22.3 Restoring to Factory Default Settings........378 22.4 Verifying Watermark .............. 390 22.4.1 Accessing AVI Files ............390 22.4.2 Running Watermark Proof..........391 22.4.3 The Watermark Proof Window ..........392...
  • Page 22 A. Settings for Internet Explorer 8 ..........423 B. Supported Lenses for Box Camera.......... 424 C. Resolution and Frame Rate ............425 D. Support Lists................431 E. RTSP Protocol Command ............437 F. The CGI Command ..............438 G. Dual Stream Support List ............440 H.

  • Page 23: Naming And Definition

    Naming and Definition GeoVision Analog and Digital Video Recording Software. The GV-System also refers to GV-Multicam GV-System System, GV-NVR System, GV-DVR System and GV- Hybrid DVR System at the same time.

  • Page 24: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The power adapter is available for all GV-IP Camera (except Arctic Box Camera and Mini Fixed Rugged Dome). The supported regions are listed below: •...
  • Page 25 Device Description The GV-PA191 PoE adapter is designed to provide GV-PA191 PoE power and network connection to the cameras over Adapter a single Ethernet cable. The GV-PA481 PoE adapter is designed to provide GV-PA481 PoE power and network connection to GV-BX1500-E / 2400-E / 3400-E / 5300-E over a single Ethernet Adapter cable.
  • Page 26 Device Description The smoked cover is an IK7, tinted camera cover designed for GV-Fixed IP Dome to conceal the Smoked Cover direction of the camera lens. XXIV...

  • Page 27: Note For Connecting To Gv-System

    Note for Connecting to GV-System The GV-IPCAM H.264 is designed to work with GV-System, a hybrid or digital video management system. Note the following when GV-IPCAM H.264 is connected to GV-System: By default, the images are recorded to the memory card inserted in the GV-IP Camera H.264 (except GV-IR Arctic Box Camera and Target Series, which are not equipped with a memory card slot).

  • Page 28: Note For Recording

    Note for Recording By default, the images are recorded to the memory card inserted in the GV-IP Camera H.264 (except GV-IR Arctic Box Camera and Target Series, which are not equipped with a memory card slot). Make sure the Write recording data into local storage option (see 20.1.1 Video Settings) is enabled.

  • Page 29: Note For Adjusting Focus And Zoom

    Note for Adjusting Focus and Zoom When adjusting the Focus and Zoom Screws (on Box Camera, IR Arctic Box Camera, Bullet Camera, Vandal Proof IP Dome and Fixed IP Camera), do not over tighten the Focus and Zoom screws. The screws only need to be as tight as your finger can do it.

  • Page 30: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the IR Arctic Box Camera, Bullet Camera, Ultra Bullet Camera, Target Bullet Camera, Vandal Proof IP Dome or Mini Fixed Rugged Dome outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables.
  • Page 31 After opening the camera cover, ensure the screws are tightened and the cover is in place. The silica gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air.

  • Page 32: Note For Closing The Bullet Camera Cover

    Note for Closing the Bullet Camera Cover To ensure that the camera performs its full capacity against water and dust, adhere to the following guidelines when closing the Bullet Camera cover: Line up the dots Tighten the camera cover until the dots on the cover and the body line up as indicated below.

  • Page 33: Note For Usb Storage And Wifi Adapter

    Note for USB Storage and WiFi Adapter Mind the following limitations and requirements for using USB storage and GV-WiFi Adapter: The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above. The USB hard drive’s storage capacity must not exceed 2TB. USB flash drives and USB hubs are not supported.

  • Page 34: Chapter 1 Introduction

    Chapter 1 Introduction The GV-IPCAM H.264 series offers a comprehensive range of IP cameras supporting your needs for IP surveillance in various environmental conditions. For detailed features of each model, refer to the corresponding chapter. 1.1 System Requirement To perform the GV-IPCAM H.264 operations through Web browser, ensure your PC is in good network connection, and use one of the following web browsers: •...

  • Page 35: Chapter 2 Box Camera

    Box Camera Model No. Specifications Description Auto Iris, f:2.8 ~ 12 1.3 MP, H.264, mm, F/1.4, 1/3” CS GV-BX120D Low Lux, D/N Lens Varifocal Lens Auto Iris, f: 2.8 ~ 12 1.3 MP, H.264, mm, F/1.4, 1/3’’ CS GV-BX130D-0...
  • Page 36 Box Camera Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 Varifocal 2 MP, H.264, GV-BX220D-3 mm, F/1.4, 1/3’’ CS Lens Lens Auto Iris, f:3.1 ~ 8 mm, F/1.2, 1/3” CS GV-BX320D-0 Lens 3 MP, H.264, Auto Iris, f: 2.8 ~ 6 Varifocal mm, F/1.3, 1/3’’...

  • Page 37: Specifications

    Model No. Specifications Description 1.3 MP, H.264, GV-BX1200-1F Low Lux, D/N 1.3 MP, H.264, GV-BX1300-1F 1.3 MP, H.264, GV-BX1500-1F Super Low Fixed Iris, f: 8 mm, Lux, D/N F/1.6, 1/2.5’’ CS 2 MP, H.264, Lens GV-BX2400-1F D/N, WDR Pro 2 MP, H.264, GV-BX2500-1F Super Low Lux, D/N...
  • Page 38 Box Camera Model No. Specifications Description 1.3 MP, H.264, GV-BX1200-3V Low Lux, D/N 1.3 MP, H.264, GV-BX1300-3V 1.3 MP, H.264, Auto Iris, f:2.8 ~ 12 GV-BX1500-3V Super Low mm, F/1.4, 1/2.7” CS Lux, D/N Lens 2 MP, H.264, GV-BX2400-3V D/N, WDR Pro 2 MP, H.264, Varifocal GV-BX2500-3V...

  • Page 39: Packing List

    2.1 Packing List • Box Camera • Terminal Block • Fixed Focal or Varifocal Megapixel Lens • Six Lens Rings • One 0.125 mm Lens Ring (for GV-BX140DW only) • Video Out Wire • Camera Holder • GV-IPCAM H.264 Software CD •...

  • Page 40: Features

    Box Camera 2.2 Features • Image sensor Camera Model Image Sensor GV-BX120D 1/3’’ progressive scan low lux CMOS GV-BX1200 Series GV-BX130D Series GV-BX1300 Series GV-BX220D Series 1/2.5’’ progressive scan CMOS GV-BX320D Series GV-BX520D GV-BX5300 Series GV-BX140DW 1/3’’ progressive scan CMOS GV-BX1500 Series 1/3’’...
  • Page 41 • Frame rate: Camera Model Frame Rate GV-BX120D GV-BX130D Series GV-BX1200 Series Up to 30 fps at 1280 x 1024 GV-BX1300 Series GV-BX1500 Series GV-BX140DW Up to 30 fps at 1280 x 720 GV-BX220D Series GV-BX2400 Series Up to 30 fps at 1920 x 1080...

  • Page 42: Wide Dynamic Range Pro

    Box Camera 2.2.1 Wide Dynamic Range Pro Objects may appear as silhouettes when they are backed with intense lights. The Wide Dynamic Range Pro (WDR Pro) is designed to solve this problem using a WDR sensor. In GV-BX140DW, GV-BX2400 Series and GV-BX3400 Series, the WDR sensor is able to process the image and show details in bright and dark areas at the same time.

  • Page 43: Overview

    12 13 Figure 2-1 Note: 1. The Auto Iris connector (No. 7) is only functional in GV-BX120D, GV-BX130D-0, GV-BX220D and GV-BX320D. 2. The Light Sensor (No.11) is only available in GV-BX140DW. Keep the Light Sensor unobscured for accurate light detection.
  • Page 44 Box Camera Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. I/O Terminal For details, see 2.6 I/O Terminal Block. Block Indicates the power is supplied. For detail, see Power LED the table below.

  • Page 45: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series

    2.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series Figure 2-2 Note: The Auto Iris Connector (No. 8) is only functional for varifocal models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 3400. The Iris Screw (No.
  • Page 46 Box Camera Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. I/O Terminal Connects to I/O devices. For details, see 2.6 Block I/O Terminal Block. Indicates the power is supplied. For detail, Power LED see the table below.

  • Page 47: Connecting The Camera

    2.4 Connecting the Camera The Box Camera is designed for indoor use. Please make sure the installing site is shielded from rain and moisture. 2.4.1 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D Figure 2-3 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 48 Box Camera Connect power using one of the following methods: • plugging the power adapter to the power port. • using the Power over Ethernet (PoE) function and the power will be provided over the network cable. The status LED of the camera will be on. You are ready to access the live view, adjust the image clarity and configure the basics.

  • Page 49: Series / 2500 Series / 3400 Series / 5300 Series

    2.4.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series Figure 2-4 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera. Connect to network using one of the following methods: •...
  • Page 50 Box Camera Optionally connect to input / output devices or an infrared illuminator. For details, see 2.5.2 Infrared Illuminator and 2.6 I/O Terminal Block. Connect power using one of the following methods: • plugging the power adapter to the power port. The power adapter is an optional device.

  • Page 51: Accessory Installation

    2.5 Accessory Installation 2.5.1 C-Mount Lenses If you use a C-mount lens, it requires a certain distance from the camera’s imaging chip to focus the lens. Mount the supplied C-mount lens adapter / lens ring to the camera, and then secure the lens onto the camera body. Three types of C-mount lens rings are provided for Box Camera: •...

  • Page 52: Infrared Illuminators (Optional)

    Box Camera 2.5.2 Infrared Illuminators (Optional) If you use an infrared (IR) illuminator with I/O function, follow the steps below to install it. Connect the infrared illuminator to the terminal block on the camera. See 2.6 The I/O Terminal Block. Access the Web interface of the camera.

  • Page 53: I/O Terminal Block

    2.6 I/O Terminal Block The terminal block, located on the back panel of the Box Camera, provides the interface to one input and one output devices. The I/O terminal block can be used for applications such as motion detection, event alerts via E- Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 54: Connecting To Gv-Relay V2 (Optional)

    Box Camera 2.6.2 Connecting to GV-Relay V2 (Optional) The Box Camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 55: Chapter 3 Ultra Box Camera

    Chapter 3 Ultra Box Camera The Ultra Box Camera is a series of light-weighted cameras designed for indoor usage. Equipped with IR-cut filter and built-in IR LEDs, the Ultra Box Camera provides excellent image quality. The camera supports PoE and can be installed intuitively.

  • Page 56: Packing List

    Ultra Box Camera 3.1 Packing List • Ultra Box Camera • Supporting rack • Screw x 3 • Screw anchor x 3 • GV-IPCAM H.264 Software CD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: Power adapter can be purchased upon request.

  • Page 57: Features

    3.2 Features • 1/2.5’’ progressive scan CMOS • Dual streams from H.264 or MJPEG • Frame rate Camera Model Frame Rate GV-UBX1301 Series Up to 30 fps at 1280 x 1024 GV-UBX2301 Series Up to 30 fps at 1920 x 1080 GV-UBX3301 Series Up to 20 fps at 2048 x 1536 •...

  • Page 58: Overview

    Ultra Box Camera 3.3 Overview Figure 3-1 Name Description Audio Out Connects a speaker for audio output. Resets the camera to factory defaults. Default See 22.3 Restoring to Factory Default Settings. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds.

  • Page 59: Installation

    3.4 Installation You can stand the Ultra Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Ultra Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 60 Ultra Box Camera Connect the network and power cables to the camera. See 3.5 Connecting the Camera. Access the live view. See 18.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 61: Connecting The Camera

    3.5 Connecting the Camera Figure 3-5 Connect power using one of the following methods: • Plug the power adapter to the 5V terminal block. The power adapter is an optional device. For detail, see Options in the manual. • Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 62: Chapter 4 Target Box Camera

    Chapter 4 Target Box Camera The Target Box Camera (GV-EBX) is a series of light-weighted cameras designed for indoor usage. Equipped with IR­cut filter and built­in IR LEDs, the camera is an entry-level surveillance solution with all the essential features and excellent image quality. The camera supports PoE and can be installed intuitively.

  • Page 63: Features

    4.2 Features • 1/3” progressive scan low lux CMOS • Dual streams from H.264 or MJPEG • Up to 30 fps at 1280 x 1024 • Intelligent IR • Day and night function (with removable IR-cut filter) • Built-in microphone •...

  • Page 64: Overview

    Target Box Camera 4.3 Overview Figure 4-1 Name Description Resets the camera to factory defaults. Default See 22.3 Restoring to Factory Default Settings. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. DC 12V Terminal Block Connects to power.

  • Page 65: Installation

    4.4 Installation You can stand the Target Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Target Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 66 Target Box Camera Connect the network and power cables to the camera. See 4.5 Connecting the Camera. Access the live view. See 18.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 67: Connecting The Camera

    4.5 Connecting the Camera Figure 4-5 Connect power using one of the following methods: • Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual. • Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 68: Chapter 5 Ir Arctic Box Camera

    IR Arctic Box Camera Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 1.3 MP, H.264, GV-BX120D-E mm, F/1.4, 1/3” CS Low Lux, D/N Lens Auto Iris, f: 2.8 ~ 6 mm, GV-BX220D-E 2 MP, H.264, D/N F/1.3, 1/3’’ CS Lens Auto Iris, f: 2.8 ~ 6 mm,...

  • Page 69: Packing List

    5.1 Packing List  IR Arctic Box Camera  Screw Anchor x 4  Screw x 4  Washer x 4  Big Torx Wrench  Small Torx Wrench  Silica Gel Bag x 2  GV-IPCAM H.264 Software CD ...

  • Page 70: Features

    IR Arctic Box Camera 5.2 Features • Image sensor Camera Model Image Sensor GV-BX120D-E 1/3" progressive scan low lux CMOS GV-BX1500-E 1/3" progressive scan super low lux CMOS GV-BX220D-E GV-BX320D-E 1/3.2" progressive scan CMOS GV-BX520D-E GV-BX5300-E GV-BX2400-E 1/2.5” progressive scan CMOS GV-BX3400-E •...
  • Page 71 • Motion detection • Tampering alarm • Privacy mask • Text overlay • IP address filtering • Power supplied through PoE (IEEE 802.3at) • Megapixel lens • Support for iPhone, iPad, Android and 3GPP • 31 languages on Web interface •...

  • Page 72: Overview

    IR Arctic Box Camera 5.3 Overview Figure 5-1 Note: The Iris Screw (No. 7) is only available in GV-BX520D-E and GV-BX5300-E. Name Description Silica gel bag Desiccant that keeps the camera housing dry. IR power plug Supplies power to the built-in IR LEDs. Focus Screw Adjusts the focus of the camera.

  • Page 73: Installation

    5.4 Installation The IR Arctic Box Camera is designed for outdoor use. Mark the installation site and drill four holes for screw anchors. Insert the supplied screw anchors. Secure the camera to the wall using the supplied washers and screws. Figure 5-2 Connect the camera to the network and supply power via the PoE cable.
  • Page 74 IR Arctic Box Camera Tilt Adjustment Figure 5-4 Pan Adjustment Figure 5-5 Based on the live view, adjust the focus, zoom and iris (in GV-BX520D-E and GV-BX5300-E only) of the camera. Unscrew the cover with the supplied small torx wrench. Figure 5-6...
  • Page 75 Hold the connectors and unplug them. Figure 5-7 IMPORTANT: Unscrew and remove the cover carefully. Pulling the cover off may cause damages to the inner wiring of the camera. Adjust the focus, zoom and iris screws. Figure 5-8...
  • Page 76 IR Arctic Box Camera Replace the silica gel bag. Paste the sticker to the front side of the silica gel bag. Press the sticker several times to make sure it adheres properly. Paste the silica gel bag to the indicated place. Figure 5-9 IMPORTANT: The gel bag loses its effectiveness when the dry camera is...

  • Page 77: Connecting The Camera

    5.5 Connecting the Camera 5.5.1 Wire Definition Figure 5-10 Wire Color Definition Black (thick) Black BNC TV out Green RCA Audio Out Pink RCA Audio In Optionally connect a speaker (green) and an external microphone (pink). Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface.
  • Page 78 IR Arctic Box Camera Optionally connect the camera’s cable to the GV-PA481 PoE adapter as illustrated below. The power and network will be supplied simultaneously. POWER & DATA OUT DATA IN Rear Panel Ethernet Cable Power Hub/Router GV-BX-E Figure 5-11 The status LED of the camera will be on.

  • Page 79: Notice For Using The Ir Arctic Box Camera

    5.6 Notice for Using the IR Arctic Box Camera Ensure that you: • enable IR LED function on the Web interface after loading the default settings. • disable the status LED to reduce reflection when a green light spot appears on the live view. 5.6.1 Enabling IR LED after Loading Default Each GV-IR Arctic Box Camera is equipped with 4 IR LEDs to provide infrared illumination at night.

  • Page 80: Disabling Status Led Under Low Light Conditions

    IR Arctic Box Camera 5.6.2 Disabling Status LED under Low Light Conditions If you have a green light spot on the live view, this is likely due to insufficient light at the installation site, which causes the status LED to reflect on the camera cover.

  • Page 81: Chapter 6 Mini Fixed Dome & Mini Fixed Rugged Dome

    Chapter 6 Mini Fixed Dome & Mini Fixed Rugged Dome The Mini Fixed Dome (GV-MFD) and Mini Fixed Rugged Dome (GV-MDR) are fixed, mini-sized ceiling-mount network cameras. The GV-MDR series is designed for outdoor surveillance, conforming to IK10 and IP67 standards. The camera is adjustable in 3 axis (pan, tilt and rotate) and can be connected through PoE.
  • Page 82 Mini Fixed & Rugged Dome Mini Fixed Rugged Dome (GV-MDR) Model No. Specifications Description Fixed Iris, f: 4.05 1.3 MP, H.264, Low GV-MDR120 mm, F/1.5, 1/3’’ Lux, Color M12 Mount GV-MDR220 Fixed Iris, f: 2.54 2 MP / 3 MP / 5MP, GV-MDR320 mm, F/2.8, 1/2.5’’...
  • Page 83 Mini Fixed Dome (GV-MFD) Model No. Specifications Description Fixed Iris, f: 4 mm, 1.3 MP Low GV-MFD120 F/1.5, 1/3’’ M12 Lux, H.264, Mount Color GV-MFD130 Fixed Iris, f: 2.54 mm, 1.3 MP / 2 MP / GV-MFD220 F/2.8, 1/2.5’’ M12 3 MP / 5MP, GV-MFD320 Mount...

  • Page 84: Packing List

    Mini Fixed & Rugged Dome 6.1 Packing List • Mini Fixed Dome or Mini Fixed Rugged Dome with 3 options for its LAN connector (M12, Waterproof or Non-Waterproof) • Torx Wrench • Self Tapping Screw x 2 • Screw Anchor x 2 •...

  • Page 85: Features

    6.2 Features • Image sensor GV-MFD Camera Model Image Sensor GV-MFD120 1/3’’ progressive scan low lux CMOS GV-MFD130 GV-MFD220 1/2.5’’ progressive scan CMOS GV-MFD320 GV-MFD520 GV-MFD1501 series 1/3’’ progressive scan super low lux CMOS 1/2.8’’ progressive scan super low lux GV-MFD2501 series CMOS GV-MFD2401 series...
  • Page 86 Mini Fixed & Rugged Dome • Frame rate GV-MFD Camera Model Frame Rate GV-MFD120 GV-MFD130 Up to 30 fps at 1280 x 1024 GV-MFD1501 series GV-MFD220 GV-MFD2401 series Up to 30 fps at 1920 x 1080 GV-MFD2501 series GV-MFD320 Up to 20 fps at 2048 x 1536 GV-MFD3401 series GV-MFD520 Up to 10 fps at 2560 x 1920...
  • Page 87 • Ingress protection (IP67 for GV-MDR series only) • EN50155 compliance for rolling stock applications (for GV-MDR series only) • Endurable to low environment temperatures (-30°C ~ 50°C / -22°F ~ 122°F) (for GV-MDR series only) • 2-axis mechanism (GV-MFD series); 3-axis mechanism (GV-MDR series) Camera Type Tilt...

  • Page 88: Overview

    Mini Fixed & Rugged Dome 6.3 Overview 6.3.1 GV-MFD120 / 130 / 220 / 320 / 520 Figure 6-1 Name Description Resets the camera to factory default. See Default Button 22.3 Restoring to Factory Default Settings. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle.
  • Page 89 LED Name Description 1. Link Turns on when the network is connected. 2. ACT Turns on when data are being transmitted. 3. PWR Turns on when power is on. 4. SW RDY (Status) Turns on when the system is ready.

  • Page 90: Gv-Mfd1501 Series / 2401 Series / 2501 Series / 3401

    Mini Fixed & Rugged Dome 6.3.2 GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series Figure 6-2 Name Description Microphone Receives sound. Pan Screw Loosens the screw to pan. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle.
  • Page 91 Figure 6-3 LED Name Description 1. Link Turns on (green) when the network is connected. 2. ACT Turns on (orange) when data are being transmitted. 3. Status Turns on (red) when the system is ready. 4. Power Turns on (green) when power is on. Note: For details on limitations and requirements of the USB port, refer to Note for USB Storage and WiFi Adapter at the beginning of this manual.

  • Page 92: Gv-Mdr120 / 220 / 320 / 520

    Mini Fixed & Rugged Dome 6.3.3 GV-MDR Figure 6-4 Name Description Silica gel bag Absorbs the moisture inside the camera. Prevents water or moisture from entering Conceal paper the camera. Lens Receives image inputs. Rotation Disc Rotates the camera lens. Pan Disc Pans the camera lens.
  • Page 93 Name Description Resets the camera to factory default. See 22.3 Restoring to Factory Default Default Button Settings. Turns red when the power is on. Flashes Power and status orange light twice when the system is ready. LAN LED Turns on when the network is connected. Inserts a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store...
  • Page 94 Mini Fixed & Rugged Dome Waterproof Connector For this connector type, see 6.4.2 GV-MDR to install the supplied cable connector. Non-waterproof (Smaller) Connector...

  • Page 95: Installation

    6.4 Installation To install a Mini Fixed Dome, make sure the installing site is shielded from rain and moisture. 6.4.1 GV-MFD Series Unscrew the housing cover using the supplied torx wrench. Put the camera on the desired location and make 2 marks on the ceiling for screw anchors.
  • Page 96 Mini Fixed & Rugged Dome Insert a Micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot (No. 7, Figure 6-1). Secure the housing cover using the supplied torx wrench. 10. Optionally conceal the cable opening with the supplied cable stopper. Cable stopper Figure 6-7...

  • Page 97: Gv-Mdr Series

    6.4.2 GV-MDR Series Paste the installation sticker on the desired location. The arrow should point toward the direction that the camera faces. Drill one hole on each of the two curves for screw anchors. Drill the circle (30 mm in diameter) if you want to run the cable into the ceiling. 30 mm Drill a hole on each...
  • Page 98 Mini Fixed & Rugged Dome Install the cable connector to waterproof the cable. You should have 5 parts: Figure 6-10 Prepare an internet cable with the RJ-45 connector on one end only. Figure 6-11 Connect the internet cable to the camera cable. Paste the sticker to the camera cable and slide in all the components as shown below.
  • Page 99 Move all the components toward the RJ-45 connector, fit item 4 to item 2, secure item 3 to the camera cable and finally secure item 5 to item 2 tightly. Figure 6-13 IMPORTANT: Item 5 must be secured tightly to waterproof the cable.
  • Page 100 Mini Fixed & Rugged Dome Tilt Adjustment Figure 6-15 Rotational Adjustment Figure 6-16 Insert a Micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot (No. 11, Figure 6-2). 10. Replace the silica gel bag. IMPORTANT: The silica gel bag loses it effectiveness when the dry camera is opened.
  • Page 101 11. Secure the housing cover using the supplied torx wrench. 12. Optionally conceal the cable opening with the supplied cable stopper. Cable stopper Figure 6-17...

  • Page 102: Connecting The Camera

    Mini Fixed & Rugged Dome 6.5 Connecting the Camera Refer to the wire definition and illustrations below to connect the power and network. 6.5.1 Wire Definition GV-MFD120 / 130 / 220 / 320 / 520 The data cable provides connections for power and network access. The wires are illustrated and defined below: Figure 6-18 Wire Color...

  • Page 103: Power And Network Connection

    6.5.2 Power and Network Connection Use one of the following methods to power on and connect your camera to network: • Wired connection with PoE: Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.

  • Page 104: Vehicle Installation

    Mini Fixed & Rugged Dome 6.5.3 Vehicle Installation To install the Mini Fixed Rugged Dome on a vehicle, clip the ferrite core to the camera cable. In accordance to EN 50155, the ferrite core is used for reduction of the cable-based and radiated interferences, ensuring stable image quality.

  • Page 105: Chapter 7 Target Mini Fixed Dome

    Chapter 7 Target Mini Fixed Dome The Target Mini Fixed Dome (GV-EFD) is an indoor, fixed, mini-sized network camera equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. Adjustable in 2 axis (pan and tilt), it offers an entry-level surveillance solution with all the essential features and excellent image quality.

  • Page 106: Features

    Target Mini Fixed Dome 7.2 Features • 1/3’’ progressive scan low lux CMOS • Dual streams from H.264 or MJPEG • Up to 30 fps at 1280 x 1024 • Intelligent IR • Day and night function (with removable IR-cut filter) •...

  • Page 107: Overview

    7.3 Overview Figure 7-1 Name Description Lens Receives image inputs. Pan Screw Loosens the screw to adjust pan angle. Tilt Screw Loosens the screw to adjust tilt angle. Microphone Receives sound. Default Resets the camera to factory default. See 22.3 Button Restoring to Factory Default Settings.

  • Page 108: Installation

    Target Mini Fixed Dome 7.4 Installation The Target Mini Fixed Dome can be installed on the wall or the ceiling. Before installing the camera, make sure the installing site is shielded from rain and moisture. Open the housing cover by turning. Figure 7-2 Place the camera where you want to install it and make 2 marks on the ceiling or the wall for screw anchors.
  • Page 109 Drill the marks and insert the screw anchors. Thread the power and / or network cable(s) through the oval-shaped hole or the cable opening on the side, and connect the camera to network and power. For details, see 7.5 Connecting the Camera. Figure 7-4 Secure the Target Mini Fixed Dome to the ceiling or the wall with the supplied screws.
  • Page 110 Target Mini Fixed Dome Loosen the tile screw and pan screw, adjust the angles based on the live view as needed, and tighten the screws again. Figure 7-5 Place the housing cover back and turn to secure it.

  • Page 111: Connecting The Camera

    7.5 Connecting the Camera Figure 7-6 Connect power using one of the following methods: • Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual. • Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 112: Chapter 8 Bullet Camera

    Chapter 8 Bullet Camera The Bullet Cameras are specifically designed for outdoors and are weatherproof (IP66 or IP67). They are equipped with IR LEDs for infrared illumination in night vision applications. The WDR Pro models (see 2.2.1 Wide Dynamic Range Pro for details) enhance the image by processing contrasting intensity of light.
  • Page 113 Model No. Specifications Description 1.3 MP, H.264, Low Lux, GV-BL1210 3X Optical Zoom 1.3 MP, H.264, Super GV-BL1510 Low Lux, 3X Optical (Coming) Zoom Auto Iris, f: 3 ~ 9 2 MP, H.264, WDR Pro, Motorized GV-BL2410 mm, F/1.2, 1/2.7’’ 3X Optical Zoom Varifocal ø...

  • Page 114: Packing List

    Bullet Camera 8.1 Packing List • Bullet Camera • Lens (Megapixel and Built-In 16 IR LEDs) • Self Tapping Screw x 3 • Plastic Screw Anchor x 3 • Torx Wrench x 2 • Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) •...

  • Page 115: Features

    8.2 Features • Image sensor Camera Model Image Sensor GV-BL120D 1/3’’ progressive scan low lux CMOS GV-BL1200 / 1210 GV-BL1500 1/3’’ progressive scan super low lux CMOS GV-BL1510 GV-BL130D / 220D / 320D 1/2.5’’ progressive scan CMOS GV-BL1300 / 5310 GV-BL2400 / 2410 1/3.2’’...
  • Page 116 Bullet Camera • Ingress protection (IP66 for GV-BL120D / 130D / 220D / 320D) (IP67 for GV-BL1200 / 1300 / 1500 / 2400 / 2500 / 3400 / 1210 / 1510 / 2410 / 2510 / 3410 / 5310) • Vandal resistance (IK10 for metal casing, GV-BL1200 / 1300 / 1500 / 2400 / 2500 / 3400 / 1210 / 1510 / 2410 / 2510 / 3410 / 5310 only) •...

  • Page 117: Overview

    8.3 Overview Figure 8-1 Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10). Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default. See 22.3.

  • Page 118: Installation

    Bullet Camera 8.4 Installation These instructions describe the basic installation of the Bullet Camera. Slide the cable clamp to the camera base. Figure 8-2 Install the Bullet Camera to the wall. Figure 8-3 Remove the protection sticker from the camera’s cover Connect the power, network and other wires to the Bullet Camera.
  • Page 119 Access the live view. For details, see 18.1. Accessing the Live View. Adjust angles of the camera body based on the live view. Three shafts can be adjusted. See 8.4.2 Adjusting the Angles. Loosen the camera’s cover, adjust the focus of the camera and optionally insert a micro SD card (SD/SDHC, version 2.0, Class 10) into the SD card slot.

  • Page 120: Connecting The Camera

    Bullet Camera 8.4.1 Connecting the Camera Wire Definition The 7-Pin Data Cable provides connections for power, ground, 1 sensor input, 1 alarm output, audio input and audio output. The wires are illustrated and defined below: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange) DC 12V- / AC 24V - (Black) GND (Yellow)
  • Page 121 Note that the Audio In and Out connectors may also come as terminal blocks: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange) DC 12V- / AC 24V - (Black) GND (Yellow) Audio In (Brown) Audio Out (Green) Ethernet (PoE) Figure 8-5 Wire Color...
  • Page 122 Bullet Camera Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. • Plug the power adaptor to the terminal block as shown below.
  • Page 123 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 124: Adjusting The Angles

    Bullet Camera 8.4.2 Adjusting the Angles The Bullet Camera is designed to be adjustable in three shafts for easy and flexible installation. First Shaft You can adjust the camera body by 360 degrees to the right or the left. Unscrew the panning lock screw with the torx wrench. Panning Lock Screw Torx Wrench Figure 8-9...
  • Page 125 Second Shaft You can adjust the camera body up and down by 90, 112.5, 135, 157.5 or 180 degrees by using the gears inside the camera body and the camera base. Unscrew the tilting lock screw with the torx wrench. Tilting Lock Screw Torx Wrench Figure 8-11...

  • Page 126: Bullet Camera

    Bullet Camera Adjust the angle of camera body to 90°, 112.5°, 135°, 157.5° or 180°. Then move the camera base to the left to combine the gears. 180 ° 157.5° 135 ° 112.5° 90° Figure 8-13 Fasten the tilting lock screw. Third Shaft You can adjust the camera base by 360°.
  • Page 127 Adjust the angle of camera base, and fasten the base fixing screw. 0~360° Figure 8-15...

  • Page 128: Adjusting Lens And Inserting A Memory Card

    Bullet Camera 8.4.3 Adjusting Lens and Inserting a Memory Card To adjust the camera’s lens to produce a clear image and insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the SD card slot, follow the steps below. Loosen the camera’s cover.
  • Page 129 If you want to insert a micro SD card, follow the steps below. Loosen the fixing screw. Fixing Screw Figure 8-18 Slightly pull out the camera module. Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. Memory Card Slot Figure 8-19 Push the camera module back and fasten the fixing screw.
  • Page 130 Bullet Camera IMPORTANT: 1. The silica gel loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time when you open the camera and conceal the gel bag in the camera within two minutes of exposing to the open air.

  • Page 131: Installing The Sun-Shield Cover

    8.4.4 Installing the Sun-Shield Cover After setting up the Bullet Camera, now you can install the sun-shield cover to the camera. Fasten the hexagon screws either on top or below the camera. Hexagon Screws Figure 8-20 Put the sun-shield cover on top of hexagon screws. Make sure to aim the rear hexagon screw at the edge of the sun-shield cover’s aperture for optimal sun-shield performance.

  • Page 132: Chapter 9 Ultra Bullet Camera

    Chapter 9 Ultra Bullet Camera The Ultra Bullet Camera is a series of light-weighted cameras designed for outdoor environments. The camera adheres to the IP67 standard and has full protection against dust and jets of water. The Ultra Bullet Cameras are available in motorized varifocal lens and fixed lens at 1.3, 2 and 3 megapixels.
  • Page 133 Model No. Specifications Description Fixed Iris, f: 3 mm, GV-UBL1301-0F F/2.0, 1/3’’ M12 Lens Mount 1.3 MP, Low Lux, H.264, D/N Fixed Iris, f: 4 mm, GV-UBL1301-1F F/1.5, 1/3’’ M12 Lens Mount Fixed Iris, f: 4 / 8 mm, GV-UBL1301-2F 1.3 MP, Low F/1.6, 1/3’’...

  • Page 134: Packing List

    Ultra Bullet Camera 9.1 Packing List • Ultra Bullet Camera (with Waterproof or Non-Waterproof LAN connector) • Camera Stand • Black Rubber • Self Tapping Screw x 3 • Plastic Screw Anchor x 3 • Torx Wrench • Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) •...

  • Page 135: Features

    9.2 Features • Image sensor Camera Model Image Sensor GV-UBL1211 1/3’’ progressive scan CMOS GV-UBL1301 Series 1/2.5’’ progressive scan CMOS GV-UBL1511 1/3’’ progressive scan super low lux CMOS 1/2.8’’ progressive scan super low lux GV-UBL2511 CMOS GV-UBL2411 / 3411 GV-UBL2401 Series 1/3.2’’...
  • Page 136 Ultra Bullet Camera • Micro SD card slot (SD/SDHC) for local storage • Intelligent IR • Motion detection • Tampering alarm • Visual automation • Text overlay • Privacy mask • IP address filtering • DC 5V / PoE • Megapixel lens •...

  • Page 137: Overview

    9.3 Overview Panel Figure 9-1 Name Description Power & I/O Connects to the data cable. For details, see Connector 9.4.1 Connecting the Camera. Resets all configurations to factory default. Default Button See 22.3. Restoring to Factory Default Settings. LAN / PoE Cable Connects to a 10/100 Ethernet or PoE.
  • Page 138 Ultra Bullet Camera LAN Connector The Ultra Bullet Camera provides two connector types. Select an option based on your installation environment. • Option 1 (Waterproof) To waterproof the cable, install the supplied cable connector. See 9.4.2 Waterproofing the Cable. • Option 2 (Smaller and non-waterproof)

  • Page 139: Installation

    Put the sun-shield cover on top of the hexagon screws. For optimal sun-shield performance, make sure the rear hexagon screw is at the end of the opening. Figure 9-3 IMPORTANT: The GeoVision logo on the sun-shield cover should be closer to the front of the camera.
  • Page 140 Ultra Bullet Camera Fasten the Philips head screws with the plastic screw spacers. Philips Head Screw Plastic Screw Spacer Figure 9-4 Optionally insert a micro SD card to the camera. Unscrew and open the back panel with the supplied torx wrench. Figure 9-5 Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the card slot.
  • Page 141 Replace the silica gel bag. IMPORTANT: 1. The silica gel loses its effectiveness when the dry camera is opened. To keep the interior dry, replace the silica gel bag every time you open the camera and conceal the gel bag in the camera within two minutes of exposing to the open air.

  • Page 142: Connecting The Camera

    Ultra Bullet Camera Install the camera to the wall or ceiling using the screw anchors and self-tapping screws. You can also stand the camera on a plain surface Figure 9-8 Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 9.4.1 Connecting the Camera and 9.4.2 Waterproofing the Cable.
  • Page 143 9.4.1 Connecting the Camera Wire Definition The supplied 4-pin data cable provides connections for power, ground, 1 sensor input and 1 alarm output. The wires are defined below: Figure 9-9 Wire Color Definition DC 5V Green Digital In Blue Digital Out Black Ground...
  • Page 144 Ultra Bullet Camera Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. •...

  • Page 145: Waterproofing The Cable

    9.4.2 Waterproofing the Cable Waterproof the option 1 LAN / PoE cable (see 9.3 Overview) using the supplied cable connector. The cable connector can be dissembled into 5 parts: Figure 9-12 Prepare an internet cable with the RJ-45 connector on one end only. Figure 9-13 Connect the internet cable to the LAN / PoE connector (No.
  • Page 146 Ultra Bullet Camera Move all the components toward the LAN / PoE connector, fit item 4 to item 2, secure item 3 to the camera cable and finally secure item 5 to item 2 tightly. Figure 9-15 IMPORTANT: Item 5 must be secured tightly to waterproof the LAN / PoE connector.
  • Page 147 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 148: Chapter 10 Target Bullet Camera

    Chapter 10 Target Bullet Camera The Target Bullet Camera (GV-EBL) is a series of light-weighted cameras designed for outdoor environments. The camera adheres to the IP67 standard and has full protection against dust and jets of water. The camera offers an entry­level surveillance solution with all the essential features and excellent image quality.

  • Page 149: Features

    10.2 Features • 1/3” progressive scan low lux CMOS • Dual streams from H.264 or MJPEG • Up to 30 fps at 1280 x 1024 • Intelligent IR • Day and night function (with removable IR-cut filter) • Wide Dynamic Range (WDR) •...

  • Page 150: Overview

    Target Bullet Camera 10.3 Overview Panel Figure 10-1 Name Description Power Connects to the data cable. For details, see Connector 10.5 Connecting the Camera. Resets all configurations to factory default. Default Button See 22.3. Restoring to Factory Default Settings.
  • Page 151 IMPORTANT: 1. The silica gel loses its effectiveness when the camera cover is opened. If you open the camera to access the load default button, replace the silica gel tape by taping the new silica gel tape to the inside of the camera cover. Make sure you conceal the silica gel tape in the camera within two minutes of exposing to the open air.

  • Page 152: Installation

    Slide the sun-shield cover onto the top of the camera. Figure 10-2 Note: The GeoVision logo on the sun-shield cover should be closer to the front of the camera. Line up the screw hole on the camera with the opening on the sun- shield cover.
  • Page 153 Ceiling Mount: Secure the supporting rack to the opening on the sun-shield cover Figure 10-4 Wall Mount: Insert and tighten the supplied screw on the sun-shield cover. Secure the supporting rack to the bottom. Figure 10-5...
  • Page 154 Target Bullet Camera Install the camera to the wall or ceiling using the screw anchors and self-tapping screws. You can also stand the camera on a plain surface. Figure 10-6 Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 10.5 Connecting the Camera.

  • Page 155: Connecting The Camera

    10.5 Connecting the Camera Wire Definition The data cable provides connections for power, ground and network access. The wires are defined below: Figure 10-7 Wire Color Definition DC 12V Black Ground Black (thick) PoE, Ethernet...
  • Page 156 Target Bullet Camera Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. •...

  • Page 157: Chapter 11 Ptz Camera

    Chapter 11 PTZ Camera The GV-PTZ010D camera is a ceiling-mount device that provides panning, tilting and zooming functions. The camera is designed to monitor a wide area and also to focus on a specific part on the live view when suspicious events occur.

  • Page 158: Packing List

    PTZ Camera 11.1 Packing List • GV-PTZ010D • Mounting Base • Mounting Cover • Wall Mount Bracket • Screw Anchor x 3 • Long Screw x 3 • Short Screw x 3 • Round Screw x 3 • GV-PTZ010D Software CD •...

  • Page 159: Features

    11.2 Features • 1/4" CCD image sensor • Dual streams from H.264, MPEG4 or MJPEG • Up to 30 fps at 704 x 480 / Up to 25 fps at 704 x 576 • Day and night function (electronic) • 10x optical zoom lens •...

  • Page 160: Overview

    PTZ Camera 11.3 Overview Figure 11-1 Name Description DC 12V / AC 24V Connects to a DV 12V or AC 24V Power Terminal Block Adapter. LAN/PoE Connects to a 10/100 Ethernet or PoE. I/O Terminal Block For details, see 11.7 I/O Terminal Block. Inserts a micro SD card (SD/SDHC, version Memory Card Slot 2.0 only, Class 10) to store recording data.
  • Page 161 Name Description Turns green when the power is on and Power LED turns off when the power is off. Microphone Records the sounds. Resets to system default settings. For Default details, see 22.3 Restoring to Factory Default Settings.

  • Page 162: Installation

    PTZ Camera 11.4 Installation The GV-PTZ010D / GV-PT series is designed for indoor usage. Make sure that the installing location is shielded from rain and moisture. There are two ways to mount the PTZ / PT Camera: Ceiling Mount and L-Shaped Wall Mount.
  • Page 163 Fix the mounting base (now with the PTZ / PT Camera attached) to the wall with 3 long screws. Figure 11-4 Put on the mounting cover. To fit the installation environment, you can cut the parts indicated by arrows to make an opening for wires and cables.

  • Page 164: L-Shaped Wall Mount

    PTZ Camera 11.4.2 L-Shaped Wall Mount You may wall-mount the GV-PTZ010D / GV-PT series with or without the mounting cover. Take the wall mount bracket and make 2 marks on the wall for screw anchors. wall Figure 11-6 Drill the marks and insert 2 screw anchors. Insert the long screws and leave enough distance (approximately 2 mm) to hang the wall mount bracket later.
  • Page 165 Hang the wall mount bracket on the screws and push the wall mount bracket downward. Make sure the long screws are tightened. Figure 11-8 Without Mounting Cover Attach the wall mount bracket with the PTZ / PT Camera using 3 washers and 3 round screws.
  • Page 166 PTZ Camera With Mounting Cover To install the mounting cover, attach the mounting base to the camera and then put on the mounting cover. See steps 3 and 5 in the Ceiling Mount section. Attach the wall mount bracket with the PTZ / PT Camera using 3 round screws.

  • Page 167: Connecting The Camera

    11.5 Connecting the Camera Figure 11-11 Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Connect power using one of the following methods: • plugging the power adapter to the power port. The power adapter is an optional device.

  • Page 168: Focus Adjustment

    PTZ Camera 11.6 Focus Adjustment On initial installation, it is advised that you adjust the focus for image clarity. Print out the diagram of radiating lines included on Software DVD and hang up the diagram at the surveillance area. Use the Zoom In / Out and Focus In / Out buttons on the PTZ control panel from the Web interface (No.4 and 5, Figure 11-15) and adjust the PTZ Camera until it displays clear radiating lines as shown in picture on the left.

  • Page 169: I/O Terminal Block

    11.7 I/O Terminal Block The 3-pin terminal block, located on the back panel of the PTZ Camera, provides the interface to one digital input and one digital output. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 170: Voltage Load Expansion (Optional)

    PTZ Camera 11.7.2 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 171: Ptz Control

    11.8 PTZ Control After you have installed the PTZ Camera on network and accessed the camera’s Web interface you are ready to configure the PTZ Camera. To see how to install the PTZ Camera on network, see Getting Started, Chapter 18. To see how to access to live image, see 18.1 Accessing Your Surveillance Images.
  • Page 172 PTZ Camera Buttons on the PTZ control panel: Name Description Exit Closes the PTZ control panel. Moves the PTZ Camera to 8 directions: Pan / Tilt Control up, down, left, right, left up, left down, right up and right down. Brings the camera view back to the home Home point where the camera faces front at a 90...

  • Page 173: Automatic Focus

    11.8.2 Automatic Focus When the camera view is fuzzy, you may use the auto focus feature to obtain a sharper view. On the PTZ control panel, click the Option button (No. 6, Figure 11-15) and select AF for automatic focus. 11.8.3 PTZ Camera Settings Accessing the PTZ Camera Settings To access PTZ camera settings, click the Option button (No.
  • Page 174 PTZ Camera PT Speed: Determines the panning (horizontal movement) and tilting (vertical movement) speed when using the Pan / Tilt Control buttons on the PTZ control panel. The drop-down list contains 5 speed settings: 1 is the slowest and 5 the fastest. Zoom Speed: Determines the zooming speed.

  • Page 175: Image Settings

    11.8.4 Image Settings Image Setting provides features on iris control, white balance, image orientation and other image processing tools to generate clearer images. To access these features, open the VISCA OSD Configuration dialog box and select Image Setting . [Iris] adjusts the amount of exposure. ALC: Automatic Light Control (ALC) is used to adjust light levels.
  • Page 176 PTZ Camera AWB: Automatic White Balance (AWB) automatically compensates for colors under different light levels. AWB is ideal for scenes with a fixed light source. Use the slider to select from 0 to 8. A higher value produces a brighter image and a lower value produces a dimmer image.
  • Page 177 Freeze: Instantly freezes the live view image when On is selected. AGC: Automatic Gain Control (AGC) utilizes an electronic circuit which amplifies video signal when the signal strength falls below a given value due to lack of the light on the camera. Adjust camera sensitivity to provide clear images.

  • Page 178: Preset Settings

    PTZ Camera 11.8.5 Preset Settings For PTZ Camera to automatically move toward a point in live view, establish a Preset. A Preset is a point in live view that can be configured and saved for future use. The PTZ Camera allows up to 256 Preset points. For details on the maximum number of Preset points, see 11.8.3 PTZ Camera Settings.
  • Page 179 Renaming a Preset Point To rename a Preset point: Click the Option button (No. 6, Figure 11-15), select Preset Set and select Naming . The dialog box appears. Figure 11-18 Click the Preset point you wish to rename and type the new name in the blank at the top.
  • Page 180 PTZ Camera Starting and Stopping a Preset Point To start a Preset movement, click the Option button (No. 6, Figure 11-15), select Preset Go , and select a Preset number which has been set previously. Alternatively, you may use the number pad on the PTZ control panel to enable a Preset movement: Click the Show Preset button (No.

  • Page 181: Sequence Settings

    11.8.6 Sequence Settings For PTZ Camera to automatically perform a series of movements, you can configure a Sequence. A Sequence links up more than two Preset points to form a sequence of movements. Up to 8 Sequences can be created. Configuring a Sequence After you have configured the Preset points you wish the camera to follow (for details, see 11.8.5 Preset Settings), you are ready to...
  • Page 182 PTZ Camera Use the Preset drop-down list to select the Preset points for the Sequence. Use the Dwell Time drop-down list to select the staying time that the camera stays at the Preset point. The dwell time ranges from 0 to 127 seconds at an interval of 0.5 second.

  • Page 183: Auto Pan Settings

    11.8.7 Auto Pan Settings For the PTZ Camera to survey a horizontal view, establish an Auto Pan. Up to 4 sets of Auto Pan can be created. Configuring an Auto Pan To configure a horizontal movement: Adjust the angle of the camera view using the Up and Down Control buttons since any vertical movements of the camera will not be recorded by Auto Pan.
  • Page 184 PTZ Camera Configuring the Speed of Auto Pan You can configure the speed for each set of Auto Pan differently: Open the VISCA OSD Configuration dialog box and select Advance. Figure 11-20 Select the Auto Pan number you wish to configure and select the Speed .

  • Page 185: Rebooting The Camera

    Starting and Stopping Autopan To start an Auto Pan, click the Option button (No. 6, Figure 11-15), select Auto and select a desired Auto Pan number. The PTZ Camera will first return to the starting position of the selected Auto Pan and proceeds with the selected Auto Pan movement.

  • Page 186: System Configuration

    PTZ Camera 11.8.8 System Configuration To configure lens settings, open the VISCA OSD Configuration dialog box and select System Configure . Figure 11-21 Zoom + AF: Automatically focuses after zooming. It is advised to use this feature with a zooming distance of at least 1 meter. Digital Zoom: Allows up to 10x Digital Zoom.

  • Page 187: Chapter 12 Pt Camera

    Chapter 12 PT Camera The GV-PT camera is a series of indoor pan and tilt camera that is designed to monitor a wide surveillance area. The camera support remote pan and tilt control and is capable of storing pre-established panning/tilting movements and points on live view for immediate monitoring.
  • Page 188 PT Camera • Short Screw x 3 • Round Screw x 3 • Terminal Block • Washer x 3 • GV-IPCAM H.264 Software CD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Quick Start Guide • GV-NVR Software DVD Note: Power adapter can be purchased upon request.

  • Page 189: Features

    12.2 Features • 1/2.5’’ progressive scan CMOS • Dual streams from H.264 and MJPEG • Frame rate Camera Model Frame Rate GV-PT130D 30 fps at 1280 x 1024 GV-PT220D 30 fps at 1920 x 1080 GV-PT320D 20 fps at 2048 x 1536 •...

  • Page 190: Overview

    PT Camera 12.3 Overview 6 7 8 Figure 12-1 Name Description DC 12V / AC 24V Connects to a DV 12V or AC 24V Power Terminal Block Adapter. LAN / PoE Connects to a 10/100 Ethernet or PoE. I/O Terminal Block For details, see 12.7 I/O Terminal Block.
  • Page 191 Name Description Turns green when the system operates Status LED normally and turns off when system error occurs. Turns green when the power is on and turns Power LED off when the power is off. Manually rotates this ring left or right to Focus Ring adjust focus.

  • Page 192: Installation

    PT Camera 12.4 Installation For installation procedures of the GV-PT Camera, see 11.4 Installation. 12.5 Connecting the Camera For procedures of connecting the GV-PT Camera, see 11.5 Connecting the Camera. 12.6 Focus Adjustment After you have followed 11.5 Connecting the Camera and connected all the necessary cables and wires, follow the steps below to adjust image clarity.

  • Page 193: I/O Terminal Block

    12.7 I/O Terminal Block The 3-pin terminal block, located on the back panel of the PT Camera, provides the interface to one digital input and one digital output. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 194: Pt Control

    PT Camera 12.8 PT Control The GV-PT Camera shares similar user interfaces and features with the GV-PTZ010D camera. See below for the supported functions and reference. Supported Function Description PT Control Panel The PT camera supports the following buttons on the control panel: Exit, Pan / Tilt Control, Home, Option and Show Preset.
  • Page 195 Supported Function Description Sequence A Sequence consists of a series of Preset points. Configure a Sequence to direct the camera to perform s series of movements. For details, see 11.8.6 Sequence Settings. Auto Pan The camera can be configured to monitor the surveillance area in a horizontal movement.

  • Page 196: Chapter 13 Vandal Proof Ip Dome (Part I)

    Chapter 13 Vandal Proof IP Dome (Part I) The Vandal Proof IP Dome is a series of outdoor camera designed for vandal protection. They are equipped with automatic infrared cut filters and IR LED for day and night surveillance. The WDR Pro models can produce clear image for scenes containing contrasting intensity of lights (see 2.2.1 Wide Dynamic Range Pro for details).The super low lux models can display color live view in near darkness.
  • Page 197 Model No. Specification Description GV-VD220D (IK10+, Transparent Cover) GV-VD221D 2 MP, H.264, (IK10+, Smoked Cover) Vandal Proof IP GV-VD222D Dome (IK7, Transparent Cover) GV-VD223D Auto Iris, f:3 ~ 9 Varifocal (IK7, Smoked Cover) mm, F/1.3, 1/2.7” ø 14 mm lens Lens GV-VD320D mount...

  • Page 198: Packing List

    Vandal Proof IP Dome (Part I) 13.1 Packing List • Vandal Proof IP Dome • Silica Gel Bag x 2 • Screw Anchor x 4 • Torx Wrench • Ceiling Screw x 4 • Blue Screw x 3 • T-Cap Screw x 3 •...

  • Page 199: Features

    13.2 Features • Image sensor Camera Model Image Sensor GV-VD120D / 121D / 122D / 1/3" progressive scan low lux 123D CMOS 1/3’’ progressive scan super low GV-VD1500 lux CMOS 1/2.8’’ progressive scan super GV-VD2500 low lux CMOS GV-VD2400 / 3400 1/3.2"...
  • Page 200 Vandal Proof IP Dome (Part I) • 3-axis mechanism (pan / tilt / roll) • Micro SD card slot (SD/SDHC) for local storage • Two-way audio • One sensor input and alarm output • TV-out support • Motion detection • Tampering alarm •...

  • Page 201: Overview

    13.3 Overview Figure 13-1 Name Description Turns on (green) when the power is on and Power LED turns off when there is no power supply. Turns on (green) when the system operates Status LED normally and turns off when system error occurs.
  • Page 202 Vandal Proof IP Dome (Part I) Name Description Rotational Screw Loosens to adjust the camera angle. Zoom Screw Adjusts the zoom of the camera. Focus Screw Adjusts the focus of the camera. Silica Gel Bag Absorbs moisture in the camera body.

  • Page 203: Installation

    13.4 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, there are two ways to install the Vandal Proof IP Dome: hard- ceiling mount and in-ceiling mount . Note: The standard package allows you to install the camera to the power box of 4"...
  • Page 204 Vandal Proof IP Dome (Part I) Unscrew thread lock Unscrew the inner housing Take out the camera body...
  • Page 205 Mark the position of four screw holes on the desired installation location, and drill holes in the marked locations. Drill the ellipse part if you wish to put the wires through it. Figure 13-3 Insert the screw anchors to the 4 holes on the ceiling. Secure the back cover to the ceiling with 4 ceiling screws.
  • Page 206 Vandal Proof IP Dome (Part I) Connect the network, power and other cables to the camera. See 13.5 Connecting the Camera. Access the live view. See 18.1 Accessing the Live View. Based on the live view, adjust the camera to a desired angle as illustrated below.
  • Page 207 Rotational Adjustment Figure 13-7 10. Adjust image clarity using the GV-IP Device Utility program. For details, see 18.2 Adjusting Image Clarity. 11. Screw on the thread lock as shown in step 1. 12. Replace the silica gel bag on the camera body within 2 minutes of opening the silica gel bag package.

  • Page 208: In-Ceiling Mount

    Vandal Proof IP Dome (Part I) 13.4.2 In-Ceiling Mount Figure 13-8 Follow step 1 in 13.4.1 Hard-Ceiling Mount section to remove the housing cover, thread lock and back cover, and take out the camera body. Cut out a circle with a diameter of 142 mm on the ceiling. Insert a blue screw to the indicated holes on the camera body.
  • Page 209 Screw in a plastic clip to the blue screw, hold it with one hand and use a screw driver to rotate the blue screw until the plastic clip moves half way down. Plastic Clip Figure 13-10 Secure a T-cap on top of the blue screw with a small screw cap and a T-cap screw.
  • Page 210 Vandal Proof IP Dome (Part I) Insert the camera to the ceiling with the plastic screws moved inward. Figure 13-12 Move the blue screws out and rotate the blue screw with a screw driver until the plastic clip and the bottom of the camera body clamps the ceiling tightly.

  • Page 211: Connecting The Camera

    13.5 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other cables needed. 13.5.1 Wire Definition The cables of Vandal Proof IP Dome are illustrated and defined below. Shielding ground DC 12V- / AC 24V+ DC 12V+ / AC 24V- Digital in (oragne) Digital out (brown) Ground (yellow)

  • Page 212: Power Connection

    Vandal Proof IP Dome (Part I) 13.5.2 Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. •...

  • Page 213: Voltage Load Expansion (Optional)

    13.5.3 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC . To expand the maximum voltage load to 10A 250V AC , 10A 125V AC or 5A 100V DC , connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 214: Chapter 14 Vandal Proof Ip Dome (Part Ii)

    Chapter 14 Vandal Proof IP Dome (Part II) This chapter describes the features, physical overview and installation of GV-VD1530 / 2430 / 2530 / 3430, GV-VD1540 / 2440 / 2540 / 3440 / 5340 and GV-VD2540-E / 5340-E. These Vandal Proof IP Domes are outdoor cameras designed with IK10+ vandal resistance and IP67 ingress protection.
  • Page 215 Model No. Specification Description 1.3 MP Super Low GV-VD1530 Lux / 2 MP WDR GV-VD2430 Pro / 2 MP Super Varifocal GV-VD2530 Low Lux / 3 MP lens WDR Pro, H.264, GV-VD3430 Vandal Proof IP (Coming) Dome 1.3 MP Super Low Auto Iris, Lux / 2 MP WDR GV-VD1540...

  • Page 216: Packing List

    Vandal Proof IP Dome (Part II) 14.1 Packing List • Vandal Proof IP Dome • Torx Wrench • 3-Pin Terminal Block • Audio wires • Power Adapter • TV out wire • RJ-45 Connector x 2 • Back Plate...
  • Page 217 • Installation sticker • Screw Anchor x 4 Ceiling mount template • Long Screw x 4 • Flat Screw • Short Screw x 2 • Silica Gel Bag x 2 • Sticker (for Silica Gel Bag) • Ruler • Conduit Converter •...
  • Page 218 Vandal Proof IP Dome (Part II) Note: Power adapter can be purchased upon request. You can choose to run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter with a self-prepared PG21 conduit connector and conduit pipe (of 1/2’’, 3/4’’...

  • Page 219: Features

    14.2 Features • Image sensor Camera Model Image Sensor GV-VD1530 / 1540 1/3" progressive scan super low lux CMOS GV-VD2430 / 2440 1/3.2" progressive scan CMOS GV-VD3430 / 3440 GV-VD2530 / 2540 1/2.8’’ progressive scan super low lux CMOS GV-VD2540-E GV-VD5340 1/2.5’’...
  • Page 220 Vandal Proof IP Dome (Part II) • Ingress protection (IP67 rating) • Wide temperature tolerance: -40°C ~ 50°C / -40°F ~ 122°F (for GV-VD2540-E / 5340-E) • 3-axis mechanism (pan / tilt / roll) • Micro SD card slot (SD/SDHC) for local storage •...

  • Page 221: Overview

    14.3 Overview Figure 14-1...
  • Page 222 Vandal Proof IP Dome (Part II) Name Description The power LED (top) turns on (green) when the power is on and turns off when there is no power supply. The status LED (bottom) LED Indicators turns on (green) when the system operates normally and turns off when system error occurs.

  • Page 223: Installation

    14.4 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Note: The standard package allows you to install the camera to the power box of 4" square and double gang. You may also install the camera to ceilings, wall surfaces, wall corners (concave or convex), and poles with optional mounting kits.
  • Page 224 Vandal Proof IP Dome (Part II) B. Unplug the conduit connector inside the housing and disintegrate the connector. You should have 4 parts: Figure 14-3 C. Remove the terminal block from the power adapter. D. Thread the audio wires (optional), TV out wire (optional), adapter wires and I/O wires (optional) through the conduit entry and then through part 1, 2, 3 and 4 of the conduit connector.
  • Page 225 For part 2, there are 8 holes each labeled with its diameter. Remove the plugs and push the wires to the corresponding hole listed below: Plug Figure 14-4 Hole Diameter Applied to 2.6 mm Audio in and audio out TV out wire 2 mm Adapter wires 1.8 mm...
  • Page 226 Vandal Proof IP Dome (Part II) Connect the wires to the camera. Install the terminal blocks to the power adapter and I/O devices. See 14.5.1 Power Connection and 14.5.2 I/O Device Connections. Install the supplied RJ-45 connector to the Internet cable. Plug all the connectors to the camera panel.
  • Page 227 Sort out the wires at the back. You can have the wires come out from position A, B or both. The instructions here describe sorting wires for position A. Figure 14-7 From the back of the camera housing, unscrew and rotate the plate to one side, sort out the wires and secure the plate back.
  • Page 228 Vandal Proof IP Dome (Part II) Secure the back plate to the ceiling. A. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces. Ceiling mount template Figure 14-9 B. Drill 3 holes for screws. The recommended ones are indicated as ‘1’.
  • Page 229 Secure the camera to the ceiling. Secure the safety lock to the camera using a short screw. Use flat screw for number 1 and small screw for number 2. Figure 14-10 Thread all the wires into the ceiling and connect them. Note: To use the TV out function, connect the black BNC connector to a monitor and select your signal format (NTSC or PAL) at the TV Out field on the Web interface.
  • Page 230 Vandal Proof IP Dome (Part II) Secure the camera using the torx wrench Figure 14-11 Access the live view. See 18.1 Accessing the Live View. Adjust the camera’s angle, focus and zoom of the camera. Pan Adjustment Figure 14-12...
  • Page 231 Tilt Adjustment Figure 14-13 Rotational Adjustment Figure 14-14...
  • Page 232 Vandal Proof IP Dome (Part II) Replace the silica gel bag and secure the camera cover using the torx wrench. IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag within 2 minutes of exposing to open air.

  • Page 233: Connecting The Camera

    14.5 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other wires needed. 14.5.1 Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.

  • Page 234: Voltage Load Expansion (Optional)

    Vandal Proof IP Dome (Part II) 14.5.3 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC . To expand the maximum voltage load to 10A 250V AC , 10A 125V AC or 5A 100V DC , connect the camera to a GV-Relay V2 module (optional product).

  • Page 235: Chapter 15 Fixed Ip Dome

    Chapter 15 Fixed IP Dome The Fixed IP Dome is a series of indoor camera designed with 3-axis mechanism for easy and flexible installation. The Fixed IP Dome features IR LED for infrared illumination for night surveillance. The WDR Pro models can produce clear image for scenes containing contrasting intensity of lights (see 2.2.1 Wide Dynamic Range Pro for details).
  • Page 236 Fixed IP Dome Model No. Specification Description 1.3 MP Low Lux, H.264, D/N, 3x GV-FD1210 Optical Zoom, Fixed IP Dome 1.3 MP / 2 MP Super Motorized Auto Iris, f: 3 ~ 9 Low Lux, H.264, GV-FD1510 mm, F/1.2, 1/2.7’’ ø D/N, 3x Optical varifocal GV-FD2510...

  • Page 237: Packing List

    15.1 Packing List 15.1.1 Packing List for Hard-Ceiling Mount • Fixed IP Dome • Torx Wrench • Mounting Plate • Short Screw Anchor x 3 • Ceiling Screw x 3 • Plate Screw x 3 • TV-out Wire • Sticker •...

  • Page 238: Packing List For In-Ceiling Mount

    Fixed IP Dome 15.1.2 Packing List for In-Ceiling Mount • In-Ceiling Housing Cover • Mounting Plate • Mounting Bracket x 3 • Copper Pillar x 3 • Copper Pillar Screw x 6 • Bracket Screw x 3 • Thread Lock Screw •...

  • Page 239: Features

    15.2 Features • Image sensor Camera Model Image Sensor GV-FD120D 1/3’’ progressive scan low lux CMOS GV-FD1200 / 1210 GV-FD1500 / 1510 1/3’’ progressive scan super low lux CMOS 1/2.8’’ progressive scan super low lux GV-FD2500 / 2510 CMOS GV-FD2400 / 2410 1/3.2’’...
  • Page 240 Fixed IP Dome • 3-axis mechanism (pan / tilt / roll) • Built-in IR LED • Micro SD card slot (SD/SDHC) for local storage • Two-way audio • One sensor input and alarm output • TV-out support • Motion detection •...

  • Page 241: Overview

    15.3 Overview 10 11 12 13 14 15 Figure 15-1 Name Description Focus Screw Adjusts the focus of the camera. Zoom Screw Adjusts the zoom of the camera. Rotational Screw Loosens to adjust the camera angle. Tilt Screw Loosens the screw to tilt the camera. Pan Disc Loosens to pan the camera.
  • Page 242 Fixed IP Dome Name Description Audio In Connects a microphone for audio input. Audio Out Connects a speaker for audio output. LAN / PoE Connects to a 10/100 Ethernet or PoE. Connects I/O devices. For details, see I/O Terminal Block 12.6 I/O Terminal Block.

  • Page 243: Installation

    15.4 Installation The Fixed IP Dome is designed for indoors. With the standard packing, there are three ways to install the Fixed IP Dome: hard-ceiling mount, in- ceiling mount and wall-surface mount. Note: You may also install the camera to ceilings, wall corners (concave or convex), and poles with optional mounting kits.
  • Page 244 Fixed IP Dome Unpack the camera package and take out the camera body. Use the torx wrench to loosen the housing cover at the front and the back. Figure 15-3 Take out the camera body Figure 15-4 Secure the camera body to the mounting plate with three ceiling screws.
  • Page 245 Connect the network, power and other cables to the camera. See 15.5 Connecting the Camera. Access the live view. See 18.1 Accessing the Live View. Based on the live view, adjust the camera to a desired angle as illustrated below. Tip: The 3-axis mechanism offers flexible and easy ceiling / wall installation.
  • Page 246 Fixed IP Dome Rotational Adjustment Figure 15-8 Adjust image clarity using the GV-IP Device Utility program. For details, see 18.2 Adjusting Image Clarity. Secure the housing cover as shown in step 2. Remove the indicated part when necessary. Figure 15-9 Note: Adjust the black mask inside the housing cover to make sure the camera view is not obscured.

  • Page 247: In-Ceiling Mount

    15.4.2 In-Ceiling Mount Figure 15-10 Follow step 2 in the 15.4.1 Hard-Ceiling Mount to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the ceiling and cut a circle on the ceiling along the edge of the sticker. On the mounting plate, locate the 3 holes labeled as 1 and insert the 3 copper pillars from the back side.
  • Page 248 Fixed IP Dome From the side with the numbering, secure the copper pillars with 3 copper pillar screws. Figure 15-12 Place the 3 mounting brackets at the indent next to the copper pillars (labeled as 2 on the mounting plate) and secure them using the 3 bracket screws.
  • Page 249 Place the mounting plate on the camera body with the copper pillars inserted in the locations indicated below. The arrow on the mounting plate should be pointing toward the front of the camera. Figure 15-14 From the bottom of the camera, secure the copper pillars using the 3 copper pillars screws.
  • Page 250 14. Use the housing cover thread and the thread lock screw to attach the housing cover to the camera body. Figure 15-16 15. Place the housing cover on the camera body with the GeoVision logo pointing toward the front of the camera. Figure 15-17...

  • Page 251: Wall-Surface Mount

    15.4.3 Wall-Surface Mount Figure 15-18 Follow step 2 in 15.4.1 Hard-Ceiling Mount section to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the wall. Drill the three red dots, and the ellipse mark only if you wish to run the wires into the wall.
  • Page 252 Fixed IP Dome Access the live view. See 18.1 Accessing the Live View. Follow steps 6 and 7 in 15.4.1 Hard-Ceiling Mount section to adjust the angle, focus and zoom of the camera. Follow step 8 in 15.4.1 Hard-Ceiling Mount section to secure the housing cover.

  • Page 253: Connecting The Camera

    15.5 Connecting the Camera Figure 15-20 Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface.

  • Page 254: I/O Terminal Block

    Fixed IP Dome 15.6 I/O Terminal Block The terminal block, located on the back panel of the Fixed IP Dome, provides the interface to one input and one output devices. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 255: Voltage Load Expansion (Optional)

    15.6.2 Voltage Load Expansion (Optional) The camera on its own can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC / 10A 125V AC / 5A 100V DC), connect the camera to a GV-Relay V2 module (optional product).

  • Page 256: Chapter 16 Cube Camera

    Chapter 16 Cube Camera The Cube Camera is a light weighted wired / wireless network camera designed for indoor usage. Its simple design allows for fast and easy installation and fixed-spot surveillance once installed. Four models are available: Model No. Specification Description 1.3 MP, H.264, Cube...

  • Page 257: Packing List

    16.1 Packing List • Cube Camera • Supporting Rack • Screw x 3 • Screw Anchor x 3 • GV-IPCAM H.264 Quick • GV-IPCAM H.264 Software Start Guide • GV-NVR Quick Start Guide • GV-NVR Software DVD Note: Power adapter can be purchased upon request.

  • Page 258: Features

    Cube Camera 16.2 Features • 1/2.5’’ progressive scan CMOS • Dual streams from H.264 or MJPEG • Frame rate Camera Model Frame Rate GV-CB120 / CBW120 Series 30 fps at 1280 x 1024 GV-CB220 / CBW220 Series 30 fps at 1920 x 1080 •...

  • Page 259: Overview

    16.3 Overview Figure 16-1 Name Description Microphone Receives sounds. Speaker Plays sounds. Connects to a 10/100 Ethernet. Turns red when the system powers on. Status LED Turns orange when the system is ready. Turns green when the camera is connected to the Internet through wires.

  • Page 260: Installation

    Cube Camera 16.4 Installation Follow the steps below to install, connect to and adjust your Cube Camera and Wireless Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Figure 16-2 Drill the marks and insert the screw anchors. Secure the supporting rack onto the wall using the supplied screws.
  • Page 261 Connect the network and power cables to the camera. See 16.5 Connecting the Camera. Access the live view. See 18.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw. Figure 16-4 For GV-CBW120/220, to connect to the Internet through wireless service, follow the steps in 18.1.3 Configuring the Wireless Connection.

  • Page 262: Connecting The Camera

    For detail, see Options in the manual. The status LED of the camera will be orange. IMPORTANT: Be sure to use the GeoVision power adapter to power up the camera. To use your own power cable, make sure you look up the...

  • Page 263: Chapter 17 Advanced Cube Camera

    Chapter 17 Advanced Cube Camera The Advanced Cube Camera integrates the passive infrared (PIR) sensor and the alarm LED to illuminate the scene automatically when the motion is detected. It also offers wireless connection to the network for flexible installation. It is small, light, and easy-to-use for indoor security. We provide four models: Model No.

  • Page 264: Packing List

    Advanced Cube Camera 17.1 Packing List • Advanced Cube Camera • Supporting Rack • Screw x 3 • Screw Anchor x 3 • GV-IPCAM H.264 Quick • GV-IPCAM H.264 Software Start Guide • GV-NVR Quick Start Guide • GV-NVR Software DVD Note: Power adapter can be purchased upon request.

  • Page 265: Features

    17.2 Features • 1/2.5’’ progressive scan CMOS • Dual streams from H.264 or MJPEG • Frame rate Camera Model Frame Rate GV-CA120 / CAW120 30 fps at 1280 x 1024 GV-CA220 / CAW220 30 fps at 1920 x 1080 • Micro SD card slot (SD/SDHC) for local storage •...

  • Page 266: Overview

    Advanced Cube Camera 17.3 Overview 2 3 4 5 6 7 Figure 17-1 Name Description Plays sounds for tampering and motion alarm, and listens to the audio around the Speaker camera. To set up alarm sound, see 20.3.9 Speaker. PIR sensor Passive infrared sensor.
  • Page 267 Name Description Reflects system status of the camera. See Ready LED the below table. Reflects LAN status of the camera. See the LAN LED below table. Inserts a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store recording data.

  • Page 268: Installation

    Advanced Cube Camera 17.4 Installation Follow the steps below to install, connect to and adjust your Advanced Cube Camera and Wireless Advanced Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Figure 17-2 Drill the marks and insert the screw anchors.
  • Page 269 Connect the network and power cables to the camera. See 17.5 Connecting the Camera. Access the live view. See 18.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw. Figure 17-4 For GV-CAW120/220, to connect to the Internet through wireless service, follow the steps in 18.1.3 Configuring the Wireless Connection.

  • Page 270: Connecting The Camera

    Advanced Cube Camera 17.5 Connecting the Camera Figure 17-5 Use a standard network cable to connect the camera to your network. Connect power using one of the following methods: • plugging the power adapter to the power port. The power adapter is an optional device.

  • Page 271: Chapter 18 Getting Started

    Chapter 18 Getting Started This section provides the initial and basic configurations of the GV-IPCAM H.264. 18.1 Accessing the Live View Access or configure your camera according to the camera type and its firmware version: Camera Type & Default Connection Type Firmware Version •...
  • Page 272 • GV-PTZ010D camera is connected to the network. To avoid IP conflict with other GeoVision IP devices, it is advisable to re-assign a different IP address. See 18.1.2 Configuring the IP Address for more detail.

  • Page 273: Checking The Dynamic Ip Address

    18.1.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Install the GV-IP Device Utility program included on the GV-IPCAM H.264 Software CD. Note: The PC installed with GV-IP Device Utility must be under the same LAN with the GV-IPCAM H.264 you wish to configure.
  • Page 274 Getting Started Find the camera with its Mac Address, click on its IP address and select Web Page. Figure 18-2 The login page appears. Figure 18-3 Type the default ID and password admin and click Apply to log in.

  • Page 275: Configuring The Ip Address

    18.1.2 Configuring the IP Address Follow the steps below to configure the IP address. Open your web browser, and type the default IP address http://192.168.0.10. In both Login and Password fields, type the default value admin. Click Apply. In the left menu, select Network and then LAN to begin the network settings.
  • Page 276 Getting Started IMPORTANT: If Dynamic IP Address or PPPoE is enabled, you need to know which IP address the camera will get from DHCP server or ISP to log in. If your camera is installed in the LAN, use the GV-IP Device Utility to look up its current dynamic IP address.

  • Page 277: Configuring The Wireless Connection

    18.1.3 Configuring the Wireless Connection You may create wireless connection to the Internet for: • Box Camera: GV-BX1200 series / 1300 series / 1500 series / 2400 series / 2500 series / 3400 series / 5300 series • Wireless Cube Camera: GV-CBW120 / 220 •...
  • Page 278 Getting Started B. Type the Network Name (SSID) or click the Access Point Survey button to search and select for the available Access Points/wireless stations. C. Select Ad-Hoc or Infrastructure for the Network type. D. Select the Authentication Type using the drop-down list. You can also obtain this information by clicking the Access Point Survey button.
  • Page 279 Enable wireless LAN. A. On the Web interface, select Network and LAN. This page appears. Figure 18-6 B. Select Wireless for Optional Network Type. C. To use a dynamic IP address assigned by the DHCP server, select Dynamic IP address. To use a fixed IP address, select Static IP address and type the IP address information.
  • Page 280 Getting Started Click Apply. The Camera will start creating a wireless connection to the access point. Note: For GV-CBW120/220 and GV-CAW120/220, the LAN LED (No. 5, Figure 16-1; No.11, Figure 17-1) turns blue when the connection is established. Unplug the Ethernet cable.

  • Page 281: Adjusting Image Clarity

    18.2 Adjusting Image Clarity Note the procedures described in this section only apply to Box Camera, IR Arctic Box Camera, Bullet Camera, PT Camera, Vandal Proof IP Dome, Mini Fixed Dome, Mini Fixed Rugged Dome and Fixed IP Dome. To adjust focus of a PTZ camera, refer to 11.6 Focus Adjustment; for Cube Camera and Advanced Cube Camera, refer to Camera Adjustment in 19.2.2 The Control Panel on the Live View Window.
  • Page 282 Getting Started On the GV-IP Utility window, click the button to search for the IP devices connected in the same LAN. Click the IP Address of the camera you desire. A drop-down list appears. Figure 18-7 Select Focus Value. The Login dialog box appears. Figure 18-8...
  • Page 283 Type the user name and password of the camera selected. The default is admin for both user name and password. This window appears. Figure 18-9 For GV-VD120D / 121D / 220D / 221D / 320D / 321D / 1500 / 2400 / 2500 / 3400, hold the supplied Focus Adjustment Cap over the camera view.

  • Page 284: Using Focus Adjustment Cap

    Getting Started 18.2.1 Using Focus Adjustment Cap The Focus Adjustment Cap is only supplied for IK10+ models (GV-VD120D / 121D / 220D / 221D / 320D / 321D / 1500 / 2400 / 2500 / 3400). Hold the Focus Adjustment Cap on top of the camera view and keep it close to the camera.

  • Page 285: Locations Of Adjustment Screws

    18.2.2 Locations of Adjustment Screws Models Adjustment Screws Zoom Screw Focus Screw Box Camera Zoom Screw Focus Screw Bullet Camera Focus Screw Zoom Screw Vandal Proof IP Dome Focus Screw Zoom Screw Fixed IP Dome...
  • Page 286 Getting Started Models Adjustment Screws Mini Fixed Dome Mini Fixed Rugged Dome Note: The adjustment screws of Box Camera may vary for different models. To focus GV-MFD and GV-MDR, loosen the lens screw first and slowly adjust the focus ring. Some models may need a T6 screw driver to loosen the camera lens.

  • Page 287: Configuring The Basics

    18.3 Configuring the Basics Once the camera is properly installed, the following important features can be configured using the browser-based configuration page and are discussed in the following sections in this manual: • Date and time adjustment: see 20.8.1 Date & Time Settings. •...

  • Page 288: Chapter 19 Accessing The Camera

    Chapter 19 Accessing the Camera Two types of users are allowed to log on to the GV-IPCAM H.264: Administrator and Guest. The Administrator has full access to all system configurations, while the Guest can only access the live view (except the Camera Adjustment settings) and network status.

  • Page 289: Accessing Your Surveillance Images

    Click Apply. A video image, similar to the example on Figure 19-2, is now displayed in your browser. Note: To enable the updating of images in Internet Explorer, you must set your browser to allow ActiveX Controls and perform a once-only installation of GeoVision’s ActiveX component onto your computer.

  • Page 290: Functions Featured On The Main Page

    Accessing the Camera 19.2 Functions Featured on the Main Page This section introduces the features of the Live View window and Network Status on the main page. The two features are accessible by both Administrator and Guest. Main Page of Guest Mode ▼...

  • Page 291: The Live View Window

    19.2.1 The Live View Window Internet Explorer When accessing the live view using Internet Explorer, the following window appears. Figure 19-3A...
  • Page 292 Accessing the Camera Figure 19-3B No. Name Function 1 Play Plays live video. 2 Stop Stops playing video. Broadcasts to the surveillance site from a remote 3 Microphone PC. Note this function is not available for Ultra Bullet Camera and Target Series .
  • Page 293 No. Name Function Transfers sounds of the surveillance site to a remote PC. Note this function is not available for 4 Speaker GV-MFD120D / 130D / 220D / 320D / 520D , Mini Fixed Rugged Dome , Ultra Bullet Camera , and Target Bullet Camera .
  • Page 294 Accessing the Camera No. Name Function Enables the I/O Control Panel or the Visual Automation. --- See 19.2.13 I/O Control. 10 I/O Control Note this function is only supported by cameras with I/O function. Click to turn the Alarm LED on and/or adjust the brightness sensitivity.
  • Page 295 Non-IE Browsers When accessing the live view using Google Chrome, Firefox or Safari, this window appears. Note the following functions are not supported on non-IE browsers: Motion Detection, Tampering Alarm, Visual Automation, Text Overlay, Two-Way Audio and GPS Settings. Figure 19-4...

  • Page 296: The Control Panel Of The Live View Window

    Accessing the Camera 19.2.2 The Control Panel of the Live View Window To open the control panel of the Live View window, click the arrow button on top of the window. You can access the following functions by using the right and left arrow buttons on the control panel.
  • Page 297 [Information] Displays the version of the camera, time of the local computer, time of the camera (host time), the number of users logging in the camera and the OCX registration path. [Video] Displays the current video codec, resolution and data rate. [Audio] Displays the audio data rates when the microphone and speaker devices are enabled.
  • Page 298 Accessing the Camera Image Orientation: Changes the image orientation on the Live View window. Slowest Shutter Speed : Shutter speed controls the amount of the lights enters the image sensor and directly impacts the quality of image presentation. A slow shutter speed allows higher light exposure that creates a brighter overall image by blurring moving objects and bringing out background details, and a faster shutter speed lowers color and image clarity in order to capture motions.
  • Page 299 Focus Change: Click the Focus In and Focus Out buttons to adjust the focus. To focus automatically, click the Auto Focus button. Focus Mode: Select Normal Scan , Regional Scan or Full Scan and then click the Start button to automatically adjust the camera focus. The Normal Scan mode focuses the camera the fastest.
  • Page 300 Accessing the Camera Figure 19-6B Figure 19-6C Figure 19-6A...
  • Page 301 Note: GV-PTZ010D only contains the Gamma feature. Saturation is not available for GV-PTZ010D. Slowest Shutter Speed and Defog is not available for GV- BX140DW . D/N , Slowest Shutter Speed and Defog are not available for GV- PTZ010D. D/N sensitivity adjustment is not available for GV-BX140DW which automatically detects light with its built-in light sensor.

  • Page 302: Snapshot Of Live Video

    Accessing the Camera 19.2.3 Snapshot of Live Video To take a snapshot of live video, follow these steps: Click the Snapshot button (No. 5, Figure 19-3). The Save As dialog box appears. Specify Save in , type the File name , and select JPEG or BMP as Save as Type .

  • Page 303: Picture-In-Picture And Picture-And-Picture View

    19.2.5 Picture-in-Picture and Picture-and-Picture View The full screen mode provides two types of close-up views: Picture-in- Picture (PIP) and Picture-and Picture (PAP) . The two views are useful to provide clear and detailed images of the surveillance area. Picture-in-Picture View With the Picture in Picture (PIP) view, you can crop the video to get a close-up view or zoom in on the video.
  • Page 304 Accessing the Camera Picture-and-Picture View With the Picture and Picture (PAP) view, you can create a split video effect with multiple close-up views on the image. A total of 7 close-up views can be defined. Figure 19-8 Right-click the live view and select PAP . A row of three inset windows appears at the bottom.
  • Page 305 To delete a navigation box, right-click the desired box, select Focus Area of PAP Mode and click Delete . To exit the PAP view, right-click the image and click PAP again.

  • Page 306: Alarm Notification

    Accessing the Camera 19.2.6 Alarm Notification After input triggers and motion detection, you can be alerted by a pop-up live video and view up to four captured images. Pop-up live Captured video images video Figure 19-9 To configure this function, click the Show System Menu button (No. 8, Figure 19-3), and select Alarm Notify .
  • Page 307 I/O Alarm Notify: Once the input device is triggered, the captured images are displayed on the control panel of the Live View window. For this function to work, the Administrator needs to install the input device properly. See 20.2.1 Input Setting. Alert Sound: Activates the computer alarm on motion and input- triggered detection.

  • Page 308: Video And Audio Configuration

    Accessing the Camera 19.2.7 Video and Audio Configuration You can enable the microphone and speaker for two-way audio communication and adjust the audio volume. To change audio configuration, click the Show System Menu button (No. 8, Figure 19-3), and select Video and Audio Configuration . Camera: Sets the number of frames to keep in live view buffer.
  • Page 309 Audio Configure: You can enable the microphone and speaker, and adjust the audio volume Figure 19-12...

  • Page 310: Remote Configuration

    Accessing the Camera 19.2.8 Remote Configuration You can upgrade firmware over the network. Click the Show System Menu button (No. 8, Figure 19-3), and select Remote Config . The Remote Config dialog box will appear. [Firmware Upgrade] In this tab, you can upgrade the firmware over the Internet.

  • Page 311: Visual Ptz

    19.2.11 Visual PTZ Note this feature is only available in PTZ Camera and PT Camera . The Visual PTZ provides two types of PTZ control panels on live images for easy and direct PTZ operation. Activating Visual PTZ Click the PTZ Control button (No.
  • Page 312 Accessing the Camera Figure 19-15 The Visual PTZ Panel provides the following features: Name Description Shortens the apparent distance between the Zoom In camera and the view. Lengthens the apparent distance between the Zoom Out camera and the view. Focus In Adjusts the sharpness of the camera view.
  • Page 313 Setting Visual PTZ Panel Click the .button on the top left corner and select Visual PTZ, the following options will appear. PTZ Control Type: Two types of visual PTZ control panels are available. Type 1: Appears only when a movement of the cursor is detected and disappears when it is static.

  • Page 314: Digital Ptz

    Accessing the Camera 19.2.12 Digital PTZ Note this function is only supported by firmware V2.06 . This function allows non-PTZ cameras to simulate PTZ movements on live view. Right-click the live view and select Digital PTZ . The live view is labeled with “DPTZ”...
  • Page 315 To pan and tilt the view, zoom the image first and then click and hold the arrow on the image. The arrow appears when you place the cursor in one of the eight directions, i.e. up, down, left, right, left up, left down, right up and right down.

  • Page 316: I/O Control

    Accessing the Camera 19.2.13 I/O Control Note this function is only supported by cameras with I/O function. The I/O Control window provides a real-time graphic display of camera status, I/O status, and alarm events. Additionally, you can remotely force output to be triggered. Figure 19-19 •...

  • Page 317: Visual Automation

    19.2.14 Visual Automation Note this function is only supported by cameras with I/O function. The Visual Automation allows you to change the current state of the electronic device by simply clicking on its image, e.g. turning the light ON. This feature is only available when the Visual Automation is set ahead by the Administrator.

  • Page 318: Network Status

    Accessing the Camera 19.2.15 Network Status To view the network status, in the left menu, click Network and select Status . Figure 19-21...

  • Page 319: Chapter 20 Administrator Mode

    Chapter 20 Administrator Mode The Administrator can access the system configuration through the network. Eight categories of configurations are involved in the system configuration: Video and Motion , I/O Control or Digital I/O and PTZ , Events and Alerts , Monitoring , Recording Schedule , Remote ViewLog , Network and Management .
  • Page 320 Administrator Mode List of Menu Options Find the topic of interest by referring to the section number prefixed to each option. The available options vary among camera models. 20.1.1 Video Settings 20.1.1 Motion Detection 20.1.3 Privacy Mask 20.1 Video and Motion 20.1.4 Text Overlay 20.1.5 Tampering Alarm 20.1.6 Visual Automation...
  • Page 321 20.8.1 Date and Time Settings 20.8.2 Storage Settings 20.8.3 User Account 20.8 Management 20.8.4 Log Information 20.8.5 System Log 20.8.6 Tools 20.8.7 Language...

  • Page 322: Video And Motion

    Administrator Mode 20.1 Video and Motion The GV-IPCAM H.264 can simultaneously process one video source in two different codec and resolutions. The dual-stream design benefits for lower bandwidth environment, allowing Streaming 2 to be set with lower resolution and codec for live streaming, and Streaming 1 set with highest resolution and codec H.264 for best recording quality.

  • Page 323: Video Settings

    20.1.1 Video Settings Figure 20-2A...
  • Page 324 Administrator Mode Figure 20-2B...
  • Page 325 [Name] Rename the video stream. To display the name of video stream on the Live View window, see 19.2.9 Camera Name Display. [Connection Template] Select the type of your network connection. Unless you select Customized , this option will automatically bring up the recommended video resolution, frame rate, bandwidth and GOP size.
  • Page 326 Administrator Mode Camera Type Default Max. Bitrate for VBR Stream 1 6 Mbit 1.3 MP Stream 2 4 Mbit Stream 1 8 Mbit 2 MP Stream 2 4 Mbit Stream 1 12 Mbit 3 MP Stream 2 4 Mbit 4 MP Stream 1 16 Mbit Stream 1...
  • Page 327 Select Enable and click ROI Setting to configure: On the popup window, use your mouse and draw directly on the live view to specify a region. Figure 20-3 To define clarity to the region, select ROI and select High , Medium or Low using the drop-down list.
  • Page 328 Administrator Mode  Pre-alarm recording time: Activates video recording before an event occurs. Set the recording time to 1 or 2 seconds. The recording is saved in the buffer of the camera.  Post-alarm recording time: Activates video recording onto the inserted memory card after an event occurs.
  • Page 329 [Watermark Setting] Note this function is not supported for Target Series . Enable this option to watermark all recordings. The watermark allows you to verify whether the video has been tampered while it was recorded. See 22.4 Verifying Watermark. [Audio In Source] Note this function is only available in GV-PTZ010D which contain a built-in microphone and also allow you to install an external microphone.
  • Page 330 Administrator Mode Auto: Select Auto for the white illumination LED to illuminate the scene automatically when the PIR sensor detects any motion within 5 meters. Sensitivity: Set the sensitivity for low light detection. The higher the value, the easier the white illumination LED is to be triggered. The default value is 5 .
  • Page 331 Trigger by Input / Trigger IR by D/N: Select this option for the infrared illuminator to turn on under low light and turn off under sufficient light. Note: The D/N settings are not available for GV-BX140DW. If an infrared illuminator is installed for outdoor surveillance, it is suggested to use the Trigger by Input or the Trigger IR by D/N function to avoid incorrect judgment of lighting and hence the action of the IR cut filter.

  • Page 332: Motion Detection

    Administrator Mode 20.1.2 Motion Detection Note for firmware V1.07 or later and the Target Series (except GV- PTZ010D), motion detection is disabled by default; for GV-PTZ010D, motion detection is enabled by default. Motion detection is used to generate an alarm whenever movement occurs in the video image.
  • Page 333 Select the desired sensitivity by moving the slider. There are ten values. The higher the value, the more sensitive the camera is to motion. Drag an area on the image. Click Add when you are prompted to confirm the setting. To create several areas with different sensitivity values, repeat steps 1 and 2.

  • Page 334: Privacy Mask

    20.1.3 Privacy Mask The Privacy Mask function is used to block out sensitive areas on live view and recorded clips for cameras connecting to GeoVision software. This feature is ideal for locations with displays, keyboard sequences (e.g. passwords), and for anywhere else you don’t want sensitive information visible.

  • Page 335: Text Overlay

    20.1.4 Text Overlay The Text Overlay allows you to overlay any text in any place on the camera view. Up to 16 text messages can be created on one camera view. The overlaid text will be saved in the recordings. Figure 20-6 Select the font, font style and font size in a pop-up window.
  • Page 336 Administrator Mode Click Set Font to modify the font settings. Click Save to apply the settings, or click Load (Undo) to revert to the last saved setting. Click Preview to see how the text will appear on the image. Click Close to end the preview.

  • Page 337: Tampering Alarm

    20.1.5 Tampering Alarm Note this function is not available for PTZ Camera and PT Camera . The Tampering Alarm is used to detect whether a camera is being physically tampered. An alarm can be generated when the camera is moved, covered up, or out of focus. The alarm approaches include the triggered output device and e-mail alert.
  • Page 338 Administrator Mode To configure the tampering alarm: Select the Enable option. If you want the camera to ignore any movement or scene change in certain areas, click the button to drag areas on the camera view. Select the desired detection sensitivity by moving the slider. The higher the value, the more sensitive the camera is to scene changes.

  • Page 339: Visual Automation

    20.1.6 Visual Automation Note this function is only supported by cameras with I/O function. This intuitive feature helps you automate any electronic device by triggering the connected output device. When you click on the image of the electronic device, you can simply change its current state, e.g. light ON. Figure 20-9 Select the Enable option.
  • Page 340 Administrator Mode Assign the connected module and output device. In the Note field, type a note to help you manage the device. Click OK to save the settings. To change the frame color of the set area, click the Set Color button. To emboss the set area, select Float Up ;...

  • Page 341: I/O Settings

    20.2 I/O Settings Note the I/O settings are only available for Box Camera , Bullet Camera, Ultra Bullet Camera , PTZ Camera , PT Camera , Vandal Proof IP Dome and Fixed IP Dome . After installing the I/O device, you need to enable the I/O settings on the camera.

  • Page 342: Input Settings

    Administrator Mode 20.2.1 Input Settings To activate the sensor input, select Enable . Figure 20-11 Normal State: You can set the input state to trigger actions by selecting Open Circuit (N/O) or Grounded Circuit (N/C) . Latch Mode: Enable this option to have a momentary output alarm. Trigger digital output relay: When this option is enabled, the output will be triggered once the input is activated.
  • Page 343 PTZ Settings: Note this function is only available for PTZ Camera and PT Camera . Input On: Select a preset point to which the camera turns when an input is triggered. Input Off: Select a preset point to which the camera returns when the input triggering is off.

  • Page 344: Output Settings

    Administrator Mode 20.2.2 Output Settings Select Enable to start the output device. Choose the output signal that mostly suits the device you are using: N/O (Open Circuit), N/C (Grounded Circuit), N/O Toggle, N/C Toggle, N/O Pulse or N/C Pulse. For Toggle output type, the output continues to be triggered until a new input trigger ends the output.

  • Page 345: Ptz Settings

    20.2.3 PTZ Settings Note this function is only available in PTZ Camera and PT Camera . You can change the image settings, configure sequences, and access settings including autopan speed, motor reset, digital zoom and system default loading. For details, see Accessing the VISCA OSD Configuration in 8.7.3 PTZ Camera Settings.

  • Page 346: Events And Alerts

    Administrator Mode 20.3 Events and Alerts For the events of motion detection or I/O trigger, the Administrator can set up two trigger actions: 1. Send a captured still image by E-mail or FTP. 2. Notify Center Monitoring Station, Center V2 or VSM, by video or text alerts.

  • Page 347: E-Mail

    20.3.1 E-mail After a trigger event, the camera can send the e-mail to a remote user containing a captured still image. Figure 20-14 [Enable] Select to enable the e-mail function. Sever URL/IP Address: Type the URL address or IP address of the SMTP Server.
  • Page 348 Administrator Mode Alerts Interval Time: Specify the interval between e-mail alerts. The interval is between 0 and 60 minutes. The option is useful for the frequent event occurrence, by which any event triggers during the interval period will be ignored. [Need authentication to login] If the SMTP Server needs authentication, enable this option and type a valid username and password to log in the SMTP server.

  • Page 349: Ftp

    20.3.2 FTP You can also send the captured still image to a remote FTP server for alerts. Figure 20-15 [Upload to an FTP Server] Enable: Select to enable the FTP function. Server URL/IP Address: Type the URL address or IP address of the FTP Server.
  • Page 350 Administrator Mode Password: Type a valid password to log into the FTP Server. Remote Directory: Type the name of the storage folder on the FTP Server. Alerts Interval time in minute: Specify the interval between FTP alerts. The interval can be between 0 and 60 minutes. The option is useful for the frequent event occurrence by which any event triggers during the interval period will be ignored.
  • Page 351 To access the internal FTP server through a web browser, enter the IP address or the domain name of the camera in your browser like this: ftp://192.168.0.10 When you are prompted for Username and Password, enter the default value username ftpuser and password 123456 . Then you should find the AVI files recorded after trigger events.

  • Page 352: Center V2

    Administrator Mode 20.3.3 Center V2 After a motion or an I/O triggered event, the central monitoring station Center V2 can be notified by live videos and text alerts. For the live monitoring through Center V2, you must already have a subscriber account on Center V2.
  • Page 353 To enable the Center V2 connection: Activate Link: Enable the monitoring through Center V2. Host Name or IP Address: Type the host name or IP address of Center V2. Port Number : match the port to the Port 2 value on Center V2 or keep the default value 5551 .

  • Page 354: Vsm

    Administrator Mode 20.3.4 VSM After a motion or an I/O triggered event, the central monitoring station VSM can get notified by text alerts. For the monitoring through VSM, you must already have a subscriber account on VSM. A camera can connect up to 2 VSM simultaneously.
  • Page 355 To enable the VSM connection: Activate Link: Enable the monitoring through VSM. Host Name or IP Address: Type the host name or IP address of VSM. Port Number: Match the port to the Port 2 value on VSM. Or keep the default value 5609.

  • Page 356: Backup Center

    Administrator Mode 20.3.5 Backup Center For the supported version of different models, see Appendix D. Note that Backup Center is not supported for Target Series . The connection to the GV-Backup Center allows you to back up another copy of recordings and system log to the GV-Backup Center on an offsite location while the camera is saving these data to the memory card.
  • Page 357 To enable connection to GV-Backup Center: Activate Link : Enable the connection to the GV-Backup Center. Host Name or IP Address : Type the host name or IP address of the GV-Backup Center. Port Number : Match the communication port on the GV-Backup Center or keep the default value 30000 .
  • Page 358 Administrator Mode Host Name or IP Address : Type the host name or IP address of the failover GV-Backup Center. Port Number : Match the communication port on the failover GV- Backup Center or keep the default value 30000 . User Name : Type a valid user name to log into the failover GV- Backup Center.

  • Page 359: Video Gateway / Recording Server

    20.3.6 Video Gateway / Recording Server For the supported version of different models, see Appendix D. The GV-Video Gateway / GV-Recording Server is a video streaming server designed for large-scale video surveillance deployments. The GV-Video Gateway / GV-Recording Server (with recording capability) can receive up to 128 channels from various IP video devices, and distribute up to 300 channels to its clients.
  • Page 360 Administrator Mode The supported GV-IPCAM H.264 can connect up to two GV-Video Gateway / GV-Recording Server. To send the video images to the GV- Video Gateway or GV-Recording Server, follow the steps below. Activate Link : Enable the connection to the GV-Video Gateway / GV- Recording Server.

  • Page 361: Viewlog Server

    20.3.7 ViewLog Server Note that ViewLog Server is not supported for Target Series . The ViewLog Server is designed for remote playback function. This server allows you to remotely access the recorded files saved at the GV-IPCAM H.264 and play back video with the ViewLog player. This function is enabled by default using port 5552 .

  • Page 362: Rtsp

    Administrator Mode 20.3.8 RTSP The RTSP enables video and audio streaming to your 3G-enabled mobile phone. The RTSP streaming is enabled by default. Figure 20-21 Activate Link: Enable the RTSP service. RTSP/TCP Port: Keep the default value 8554, or modify it if necessary.

  • Page 363: Speaker

    20.3.9 Speaker Note this function is only available for Advanced Cube Camera . The Advanced Cube camera is equipped with an alarm. With the Speaker settings, your camera can sound the speaker (No. 1, Figure 17-1) when it is being tampered or when motions are detected. This function is disabled by default.

  • Page 364: Monitoring

    Administrator Mode 20.4 Monitoring Recording function is not supported in Target Series . Refer to 20.4.1 Monitoring Settings for Target Series for the corresponding page. You can start monitoring manually, by schedule or by input trigger. Note: See Note for Connecting to GV-System at the beginning of the manual.

  • Page 365: Monitoring Settings For Target Series

    Input: Note this function is only supported by cameras with I/O function. Manually starts I/O monitoring. When the sensor input is triggered, its associated camera and output will be activated for recording and alerting. For this setting, see 20.2.1 Input Setting. [Schedule] The system starts motion detection and I/O monitoring according to the schedule you have set.

  • Page 366: Recording Schedule

    Administrator Mode 20.5 Recording Schedule Note this function is not available for Target Series . The schedule is provided to activate recording and I/O monitoring on a specific time each day. 20.5.1 Recording Schedule Settings You can set the schedule for recording. Figure 20-25 Span 1- Span 3: Set a different recording mode for each time frame during the day.

  • Page 367: I/O Monitoring Settings

    20.5.2 I/O Monitoring Settings Note this function is only supported by cameras with I/O function. You can set the schedule for I/O monitoring to start. Figure 20-26 Span 1- Span 3: Set different time frames during the day to enable I/O monitoring.

  • Page 368: Remote Viewlog

    Administrator Mode 20.6 Remote ViewLog Note this function is not available for Target Series . With the Remote ViewLog player, you can play back the files recorded at the GV-IPCAM H.264 over TCP/IP network. For the first-time user, you need to install the Remote ViewLog program from the Software CD.

  • Page 369: Network

    20.7 Network The Network section includes some basic but important network configurations that enable the camera to be connected to a TCP/IP network. 20.7.1 LAN Configuration According to your network environment, select among Static IP, DHCP and PPPoE. Figure 20-27...
  • Page 370 Administrator Mode [Optional Network Type] Note the Wireless Settings are only available in GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series , GV-CBW120 / 220 , GV-CAW120 / 220 and GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series .

  • Page 371: Wireless Client Mode

    20.7.2 Wireless Client Mode Note this function is only supported in GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 , GV- CBW120 / 220 , GV-CAW120 / 220 and GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series and when GV-WiFi Adapter is installed.
  • Page 372 Administrator Mode Network name (SSID): The SSID (Service Set Identify) is a unique name that identifies a particular wi reless network. Type SSID of the Wireless LAN group or Access Point you are going to connect to. Access Point Survey: Click this button to search all the availab Access Points (Infrastructure mode) and wireless stations (AD-Ho mode) within the LAN.

  • Page 373: Advanced Tcp/Ip

    20.7.3 Advanced TCP/IP This section provides the advanced TCP/IP settings, including DDNS Server, HTTP port, HTTPS, streaming port, UPnP, QoS and network connection check. Figure 20-29A...
  • Page 374 DHCP Server or ISP (in xDSL connection) has changed. Before enabling the following DDNS function, the Administrator should have applied for a Host Name from the DDNS service provider’s website. There are 2 providers listed in the camera: GeoVision DDNS Server and DynDNS.org. To enable the DDNS function: Enable: Enable the DDNS function.
  • Page 375 Host Name: Type the host name used to link to the camera. For the users f GeoVision DDNS Server, it is unnecessary to fill the field because the host name will be detected and brought up automatically. User Name: Type the username used to enable the service from the DDNS.
  • Page 376 Administrator Mode [QoS Settings] The Quality of Service (QoS) is a bandwidth control mechanism that guarantees delay-sensitive data flows such as voice an video streams, obtain a certain amount of bandwidth to keep the streaming smooth. To apply QoS to GV-IPCAM H.264, all network routers must support QoS and QoS must be enabled on these devices.

  • Page 377: Ip Filter Settings

    20.7.4 IP Filter Settings The Administrator can set IP filtering to restrict access to the camera. Figure 20-30 To enable the IP Filter function: Enable IP Filtering: Enable the IP Filter function. Filtered IP: Type one IP address or a range of IP addresses you want to restrict the access.

  • Page 378: Snmp Settings

    Administrator Mode 20.7.5 SNMP Settings The Simple Network Management Protocol (SNMP) allows you to monitor the st atus of the camera through SNMP network management softw are. Figure 20-31...
  • Page 379 Select Enable SNMPv1 SNMPv2c to enable the function. To enable access to Read/Write community , type a community string. This will serve as a password to allow read and write access t the camera from the SNMP software. To enable Read only community , type a community string to allow read-only access to the camera from the SNMP software.

  • Page 380: Management

    Administrator Mode 20.8 Management The Management section includes the settings of data and time and us account. You can also view the firmware version and execute certain system operations. 20.8.1 Date & Time Settings The date and time settings are used for date and time stamps on the image.
  • Page 381 [Date & Time on GV-IP Camera] Displays the current date and time on the camera. [Time Zone] Sets the time zone for local settings. Select Enable Day light Saving Time to aut omatically adjust the camera for daylight saving time. ype the Start Time and End Time to enable the daylight saving function.

  • Page 382: Storage Settings

    Administrator Mode 20.8.2 Storage Settings e this funct ion is not available for Target Series . Based on Linux file system, the GV-IPCAM H.264 supports memory cards for video and audio recordings. You need to format the storage device by using the following Storage Settings.
  • Page 383 [Storage Settings] Enable recycling: If Enable recycling is selected, when the space of the storage device is lower than the specified space, the system will overwrite the oldest recorded files. If Enable recycling is not selected the system will stop recording when the specified space is reached. Keep days (1-255): Specify the number of days to keep the files fro 1 day to 255 days.
  • Page 384 Administrator Mode To remove a storage device: Click the Remove button. When you are prompted to ensure the action, click Yes . The page will be refreshed and the partition information will be cleaned. Remove the storage device from the camera. The storage device status is indicated in the status column: Status Description...
  • Page 385 Note: 1. If Enable Recycle is selected, the available space of the storage device must be higher than the space you specified at the Stop recording or recycle disk when free space o f disk is smaller than x option. Otherwise no video will be recoded. 2.

  • Page 386: User Account

    Administrator Mode 20.8.3 User Account ou can c hange the login name and password of Administrator and Guest. The default Administrator login name and password are admin ; the def ault Guest login name and password are guest . To allow a Guest user log i without entering name and password, select Disable authentication for guest account .

  • Page 387: Log Information

    20.8.4 Log Information The log information contains dump data that is used by service personnel for analyzing problems. The logs available may vary depending on the camera model. Figure 20-36-1...
  • Page 388 Administrator Mode Figure 20-36-2...

  • Page 389: System Log

    20.8.5 System Log Note this function is not available for Target Series . For the supported versions, see Appendix F. The System Log records the events in the four types of logs: System Event , Monitoring Event , I/O Event and Login/Logout Event . With the System Log, you can search and obtain the detailed information of an event.
  • Page 390 Administrator Mode Click Query . The filtering results may look like the figure below. Figure 20-38...

  • Page 391: Tools

    20.8.6 Tools You can execute certain system operations and view the firmware version. Figure 20-39...
  • Page 392 Administrator Mode [Host Settings] Enter a descriptive name for the camera. [Auto Reboot Setup] Select Enable to activate automatic reboot and specify the time for reboot in the sub fields. Day Interval: Type the day interval between each reboot. Reboot Time: Use the drop-down lists to specify the time for automatic reboot.

  • Page 393: Language

    20.8.7 Language Note this function is not available in GV-PTZ010D . You can select the language for the Web interface. Figure 20-40 Use the Language drop-down list to select a language for the Web interface. By default, the language on the Web interface will be the same ith the one used for the operating system.

  • Page 394: Chapter 21 Recording And Playback

    Chapter 21 Recording and Playback ote that Recording and Playback function is not available for Target Series . The GV-IPCAM H.264 can record video and audio directly to the memory card. You can play back the recorded files on the GV-System or over the TCP/IP network.

  • Page 395: Playback

    21.2 Playback These methods are available to play back the video files recorded at the GV-IPCAM H.264: • Playback from the memory card by connecting it directly to the GV- System through a card reader • Playback by using the Remote ViewLog function over the TCP/IP network •...
  • Page 396 Recording and Playback Install the Ext2Fsd from the Software CD. Note: If you are using Windows 8 or Windows Server 2012 , change its compatibility before installing the Ext2Fsd program: Right -click the Ext2Fsd program and select Properties . This dialog box appears.
  • Page 397 On Your desktop, click Start , select Programs , locate the Ext2Fsd folder and select Ext2 Volume Manager . All the connected drives are show Figure 21-2...
  • Page 398 Recording and Playback For the first-installation, execute the Ext2Fsd Service. A. From the Ext2 Volume Manager window, select Tools and select Service Management . This dialog box appears. Figure 21-3 B. Click Apply .
  • Page 399 Mount the storage drive to your computer. A. From the Ext2Fsd Volume Manager window, right-click the storage drive and select Ext2 Management . This dialog box appears. Figure 21-4 B. Under the Mount point & driver letter section, select Automatically m ount via Ext2 Mgr , specify a disk drive using the drop-down list...
  • Page 400 Recording and Playback C. On the Ext2 Volume Manager window, the storage drive is successfully mounted to your computer when it is indicated w the disk drive you specified. Figure 21-5 Access the recording files from the specified drive of your computer.

  • Page 401: Playback Over Network

    21.2.2 Playback over Network With the Remote ViewLog function, you can play back the files recorded at the GV-IPCAM H.264 over TCP/IP net work. The camera needs to allow the remote access with ViewLog Server activated. See 20.3.7 ViewLog Server. For the first-time user, run the Remote ViewLog program from the Software CD.

  • Page 402: Access To The Recorded Files Through Ftp Server

    Media Player. For details to download files, see [Act as FTP Server], 20.3.2 FTP. Note: To play back videos, ensure you have installed Geovision codec on the computer. The codec is available on the Software CD. If you have installed the Remote Playback player on the computer, it is not required to install the codec.
  • Page 403 To remotely connect to the camera from GV-System, click the To button and select Remote ViewLog Service . The Connect to Remote ViewLo g Service dialog box appears. Enter the connection information of the camera, and click Connect . Once the connection is established, the video events will be displayed on the Video Event list.

  • Page 404: Chapter 22 Advanced Applications

    This chapter introduces more advanced applications. 22.1 Upgrading System Firmware GeoVision periodically releases updated firmware on the website. Simply download the new firmware into the GV-IPCAM H.264 using the Web interface or IP Device Utility included in the Software CD.
  • Page 405 In this case, please contact your sales representative and send your device back to GeoVision for repair. Do not turn the power off within 10 minutes after the firmware is updated.

  • Page 406: Using The Web Configuration Interface

    Advanced Applications 22.1.1 Using the Web Configuration Interface In the Live View window, click the Show System Menu button (No. 8, Figure 19-3) and select Remote Config. This dialog box appears. Figure 22-2 Click the Browse button to locate the firmware file (.img) saved at your local computer.

  • Page 407: Using The Ip Device Utility

    GV-IPCAM H.264. Note the computer used to upgrade firmware must be under the same network of the camera. Insert the Software CD, select GeoVision IP Device Utility, and follow the onscreen instructions to install the program. Double-click the IP Device Utility icon created on your desktop. This dialog box appears.
  • Page 408 Advanced Applications Double-click one camera in the list. This dialog box appears. Figure 22-4 Click the Firmware Upgrade tab. This dialog box appears. Figure 22-5 Click the Browse button to locate the firmware file (.img) saved at your local computer. If you like to upgrade all the cameras in the list, select Upgrade all devices.

  • Page 409: Backing Up And Restoring Settings

    22.2 Backing Up and Restoring Settings With the IP Device Utility included in the Software CD, you can back up the configurations in the GV-IPCAM H.264, and restore the backup data to the current camera or import it to another camera. To back up the settings: Run IP Device Utility and locate the desired camera.
  • Page 410 Advanced Applications To restore the settings: In Figure 22-4, click the Import Settings tab. This dialog box appears. Figure 22-7 Click the Browse button to locate the backup file (.dat). Select Upgrade all devices to import the settings into the same type of device in the same LAN.

  • Page 411: Restoring To Factory Default Settings

    22.3 Restoring to Factory Default Settings Please refer to the corresponding section of your camera type and follow the steps to restore factory default settings. Box Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera.
  • Page 412 Advanced Applications Ultra Box Camera and Target Box Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Figure 22-10 Release the default button when the status LED blinks. This shall take about 8 seconds.
  • Page 413 Mini Fixed Dome Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button. Default button Status LED Figure 22-12 (GV-MFD120 / 130 / 220 / 320 / 520) Figure 22-13 (GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series) Release the default button when the status LED blinks.
  • Page 414 Advanced Applications Mini Fixed Rugged Dome Keep the PoE cable connected to the camera. Press and hold the default button. Status LED Default button Figure 22-14 Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.
  • Page 415 Release the default button when the status LED blinks. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. Bullet Camera Keep the power and network cables connected to the camera. Loosen the camera’s cover and remove the Silica Gel Bag. Press and hold the default button for 8 seconds.
  • Page 416 Advanced Applications Press and hold the default button. Figure 22-17 Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. Target Bullet Camera Keep the power and network cables (or PoE) connected to the camera.
  • Page 417 Release the default button. When the process of loading default settings is completed, the camera reboots automatically. Replace the Silica Gel Tape inside the camera cover and fasten the camera’s cover immediately. PTZ Camera There are two types of default settings: camera default settings and system default settings.
  • Page 418 Advanced Applications To load system default settings: Unplug the power cable and the network cable (or the PoE cable). Press and hold the default button (No. 10, Figure 11-1). Power on the camera using the power cable or the PoE cable. Hold the default button until the two network LEDs fade.
  • Page 419 Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED turns orange, the process of loading default settings is completed and the camera is ready for use. Vandal Proof IP Dome Keep the power and network cables (or PoE) connected to the camera.
  • Page 420 Advanced Applications Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. Fixed IP Dome Keep the power and network cables (or PoE) connected to the camera.
  • Page 421 Cube Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the panel. Default button Status LED Figure 22-24 elease the def ault button when the status LED blinks. This shall take about 8 seconds.
  • Page 422 Advanced Applications elease the de fault button when the status LED blinks. This shall take about 8 seconds. When the status LED turns green, the process of loading default settings is completed and t he camera is ready for use.

  • Page 423: Verifying Watermark

    22.4 Verifying Watermark The watermark is an encrypted and digital signature embedded in the video stream during the compression stage, protecting the video from the moment of creation. Watermarking ensures that an image is not edited or damaged after it is recorded. To enable the watermark function, see [Watermark Setting], 20.1.1 Video Settings.

  • Page 424: Running Watermark Proof

    Advanced Applications 22.4.2 Running Watermark Proof Install Watermark Proof from the Software CD. After installation, a WMProof icon is created on your desktop. Double-click the created icon. The Water Mark Proof window appears. Click File from the menu bar, select Open and locate the recording (.avi).

  • Page 425: The Watermark Proof Window

    22.4.3 The Watermark Proof Window Figure 22-26 The controls in the window: No. Name Description Open File Opens the recording. First Frame Goes to the first frame of the file. Play Plays the file. Previous Frame Goes to the previous frame of the file. Next Frame Goes to the next frame of the file.

  • Page 426: Downloading Videos From The Micro Sd Card

    Advanced Applications 22.5 Downloading Videos from the Micro SD Card When connections of GV-IP Cameras to the GV-System are lost, recordings are automatically saved to the memory cards inserted in the GV-IP Cameras. To automatically synchronize and download recordings from the micro SD cards to a local folder, install and execute the GV-SDCardSync Utility program.

  • Page 427: Installing The Gv-Sdcardsync Utility

    22.5.1 Installing the GV-SDCardSync Utility Download the GV-SD Card Sync Utility program from http://ftp.geovision.tw/FTP/neo/Utility/GvSDCardSync_Setup.zip Note: The GV-SD Card Sync Utility must be installed on the computer installed with GV-System V8.5.4 or later. Execute the GV-SDCard Sync Utility program. The main window and the Setting window appear.
  • Page 428 Advanced Applications To configure synchronization, network and startup settings, see the steps below. Figure 22-28 [Synchronization] Synchronize automatically at an interval: Automatically synchronize videos from micro SD cards to a local folder at the specified interval. Synchronize automatically at: Automatically synchronize videos from micro SD cards to a local folder at the specified time.
  • Page 429 [Network] Max. download speed of each device (Kb/sec): To make sure the bandwidth is not completely taken up while downloading files from the memory card, specify a maximum download speed. If you do not want to set a bandwidth limit, type 0. [General] Start up automatically at Windows login: GV-SDSync Utility launches automatically when Windows starts up.
  • Page 430 Advanced Applications [Recycle] Recycle when the storage space is less than (GB): Specify a minimum free space of your local storage for file recycling. Keep the downloaded files for (Days): Specify the number of days to keep the download files at the local hard drive. [Storage Location] To configure the storage path, click the button next to the location field and specify a storage location.

  • Page 431: The Gv-Sdcardsync Utility Window

    22.5.2 The GV-SDCardSync Utility Window After you have installed the GV-SDCardSync Utility, point to Start, select Programs, select GV-SDCardSync and select to launch the program. This window appears. Figure 22-30 No. Name Description Plays downloaded recordings of the selected GV-IP Cameras using the ViewLog player.
  • Page 432 Advanced Applications No. Name Description Displays up to 100 event entries of the GV- Log Tab SDCardSync Utility. Once the entries are full, recycling will start from the oldest file. Shows the storage space of the designated hard Storage Space drive.

  • Page 433: Chapter 23 Dvr Configurations

    Chapter 23 DVR Configurations The GV-System provides hybrid solution, integrating the digital videos from IP cameras with other analog videos. For the digital videos, the GV-System provides the complete video management, such as video viewing, recording, playback, alert settings and almost every feature of the system. Following is the integration specifications: TCP/ IP IP Camera...
  • Page 434 DVR Configurations • The compatible version of GV-System for each camera model: Compatible version Camera Models of GV-System GV-BX120D GV-BX220D Series V8.4 or later GV-BX320D Series GV-BX130D Series GV-BX140DW V8.5 or later GV-BX520D GV-BX1200-0F ~ 2F GV-BX1200-3V GV-BX1300-0F ~ 2F...
  • Page 435 Compatible version Camera Models of GV-System GV-BX120D-E GV-BX220D-E V8.4 or later GV-BX320D-E GV-BX520D-E IR Arctic Camera GV-BX1500-E V8.5.8 or later GV-BX2400-E GV-BX3400-E V8.5.7 or later GV-BX5300-E GV-MFD120 GV-MFD130 GV-MFD220 V8.5 or later GV-MFD320 GV-MFD520 Mini Fixed GV-MFD1501 Series V8.5.7 or later...
  • Page 436 DVR Configurations Compatible version Camera Models of GV-System GV-BL120D V8.4 (with patch GV-BL220D files) or later GV-BL320D GV-BL130D V8.5 or later GV-BL1200 GV-BL1300 GV-BL2400 GV-BL3400 V8.5.6 or later Bullet Camera GV-BL1210 GV-BL2410 GV-BL3410 GV-BL5310 V8.5.7 (with patch GV-BL1500 files) or later GV-BL1510 V8.5.8 GV-BL2500...
  • Page 437 Compatible version Camera Models of GV-System PTZ Camera GV-PTZ010D V8.4 or later GV-PT130D PT Camera V8.5.7 or later GV-PT220D GV-PT320D GV-VD120D Series V8.4 (with patch files) GV-VD220D Series or later GV-VD320D Series GV-VD1500 V8.5.8 or later GV-VD2400 V8.5.6 or later GV-VD3400 Vandal Proof IP GV-VD1530/1540...
  • Page 438 DVR Configurations Compatible version Camera Models of GV-System GV-FD1210 GV-FD2410 V8.5.7 or later GV-FD3410 Fixed IP Dome GV-FD1500 V8.5.8 or later GV-FD1510 GV-FD2500 V8.5.9 or later GV-FD2510 GV-CB120 V8.4.3 (with patch GV-CB220 files) or later Cube Camera GV-CBW120 V8.5 or later GV-CBW220 GV-CA120 GV-CA220...
  • Page 439 • The maximum number of streams which the GV-IPCAM H.264 allows varies according to its resolution: Camera Models Max. No. of Streams GV-PTZ010D 1.3 M models except GV-PTZ010D 2 M models 3 M models 5 M models • When a GV-IPCAM H.264 is connected to IE browser or any other applications, it takes up 1 stream;...

  • Page 440: Setting Up An Ip Camera

    DVR Configurations 23.1 Setting up an IP Camera To set up the GV-IPCAM H.264 on the GV-System, follow these steps: On the main screen, click the Configure button, select System Configure, select Camera Install and click IP Camera Install. This dialog box appears.
  • Page 441 Click Add Camera. The dialog box appears. Figure 23-3 Type the IP address, username and password of the IP camera. Select the camera brand and device from the drop-down lists. This dialog box appears. Figure 23-4 The GV-System will automatically query for the IP camera, and the status will be indicated as “Standby”.
  • Page 442 DVR Configurations The options in the setup dialog box may vary depending on the camera model. Dual Stream: Click this button to set the codec type to H.264 in the main stream and to MJPEG in the sub stream, and each stream with a different resolution.

  • Page 443: Customizing Ip Camera Settings

    23.1.1 Customizing IP Camera Settings After the IP camera is connected and assigned with a display position, you can configure the camera’s settings such as frame rate, codec type and resolution. Right-click the desired camera to see the following list of options: Figure 23-6 Change Resolution: Changes the display ratio, live view resolution and record resolution...
  • Page 444 Recording Codec Format: Specifies whether to record in standard or GeoVision type of JPEG or H.264 codec. GIS Setting: Records the video with the GPS data. To record the GPS data, remember to also enable the GIS function of the GV- System (Configure button <...

  • Page 445: Remote Monitoring With Multi View

    23.2 Remote Monitoring with Multi View You can use the Multi View to monitor and manage the GV-IPCAM H.264. 23.2.1 Connecting to the IP Camera On the Multi View window, click the Edit Host button. The Edit Host window appears. To create a host, click the New button.

  • Page 446: Remote Monitoring With E-Map

    DVR Configurations 23.3 Remote Monitoring with E-Map You can use the Remote E-Map to monitor and manage the GV-IPCAM H.264. 23.3.1 Creating an E-Map for the IP Camera With the E-Map Editor, you can create an E-Map for the GV-IPCAM H.264. The E-Map Editor is available in the two applications: Main System and E- Map Server.
  • Page 447 Click OK to save the settings. Expand the created host folder. Drag and drop the icons of camera and I/O devices onto the imported E-Map. Close the E-Map Editor. Click Yes when you are promoted to save the file. For details on creating an E-Map file on the E-Map Server, see “E-Map Server”, E-Map Application, DVR User’s Manual on the Surveillance System Software DVD.

  • Page 448: Connecting To The Ip Camera

    DVR Configurations 23.3.2 Connecting to the IP Camera Depending on where you save the created E-Map file (DVR, E-Map Server or Control Center), the steps to open the Remote E-Map window for monitoring may vary slightly. The following is the connection example when you store the E-Map file on the DVR.

  • Page 449: Chapter 24 Cms Configurations

    Chapter 24 CMS Configurations This section introduces the related settings to enable connecting to the GV- IPCAM H.264 in the central monitoring stations Center V2, VSM and Dispatch Server. 24.1 Center V2 The Center V2 can monitor and manage the camera and I/O devices connected to the GV-IPCAM H.264.
  • Page 450 CMS Configurations • To set the appropriate port for IP camera connection, click the Preference Settings button, select System Configure, click the Network tab, and select Accept connections from GV-Compact DVR, Video Server & IP Cam. Keep default port 5551, or modify it to match the Center V2 port on the IP camera.
  • Page 451 Manual close channel: Closes the triggered camera view manually. Close the camera view when motion stopped: Closes the triggered camera view automatically when motion stops. Post Motion: Specify the duration of the camera view remaining on the monitoring window after a motion stops. Camera send by I/O trigger will monitor: Specify the duration of the camera view remaining on the monitoring window when an I/O device is triggered.

  • Page 452: Vsm

    CMS Configurations 24.2 VSM The VSM is designed to monitor and manage the camera and I/O devices connected to the GV-IPCAM H.264 under low bandwidth network. Figure 24-4 • To set the appropriate port connecting to the IP camera, click Configure on the window menu, and select System Configure to display this dialog box.

  • Page 453: Dispatch Server

    24.3 Dispatch Server The Dispatch Server minimizes overloading of Center V2 Servers by re- distributing GV-IPCAM H.264 subscribers to the least busy Center V2 Server. Figure 24-6...
  • Page 454 CMS Configurations • To set the appropriate port connecting to the IP camera, click the Server Setting button on the toolbar, and select Allow GV IP devices to login as subscriber from port. Keep the default port as 5551, or modify it to match the Center V2 port on the IP camera. Figure 24-7 For further information on how to mange the video received from the IP camera, see GV-CMS Series User’s Manual.

  • Page 455: Chapter 25 Smart Device Connection

    GV-Eye for iPhone and iPod Touch For details on system requirements, installation and setup, visit our website: http://www.geovision.com.tw/english/5_4_iview.asp Note: To receive the live video from the camera, enter the TCP/IP port on your mobile phone. To play video back, enable ViewLog Server on...

  • Page 456: Appendix

    Appendix Appendix A. Settings for Internet Explorer 8 If you use Internet Explorer 8, it is required to complete the following setting. Set the Security to Medium-high (default). Enable Allow previously unused ActiveX controls to run without prompt. Disable Only allow approved domains to use ActiveX without prompt.

  • Page 457: Supported Lenses For Box Camera

    B. Supported Lenses for Box Camera Provider Model No. RV0409D.IR Fujian Forecam Optics RV0515D.IR RV0820D.IR EVD03618F-IR EVD04218F-IR EVD06018F-IR EVETAR EVD08018F-IR EVD12018F-IR EVD16018F-IR Pentax TS3VP213ED-M...

  • Page 458: Resolution And Frame Rate

    GV-BL120D 1280 x 960 GV-BL130D GV-BL1200 Main 16:9 1280 x 720 GV-BL1300 1280 x 1024 GV-BL1210 GV-BL1500 GV-BL1510 GV-BX120D 640 x 480 GV-BX130D Series 320 x 240 GV-BX1200 Series GV-BX1300 Series GV-BX1500 Series GV-BX120D-E GV-BX1500-E 30 fps GV-CA120 GV-CAW120 640 x 360...
  • Page 459 Max. Frame GV-IP Camera Stream Ratio Resolution Rate 1280 x 960 GV-UBL1301 Series GV-UBL1511 16:9 1280 x 720 Main GV-UBX1301 Series 1280 x 1024 GV-VD120D GV-VD121D 640 x 480 30 fps GV-VD122D 320 x 240 GV-VD123D 640 x 360 16:9 GV-VD1500 448 x 252 GV-VD1530...
  • Page 460 Appendix Max. Frame GV-IP Camera Stream Ratio Resolution Rate GV-BL220D 1600 x 1200 GV-BL2400 1280 x 960 GV-BL2410 Main 1920 x 1080 16:9 GV-BL2500 1280 x 720 GV-BL2510 1280 x 1024 GV-BX220D Series 640 x 480 GV-BX2400 Series 320 x 240 GV-BX2500 Series 640 x 360 GV-BX220D-E...
  • Page 461 Max. Frame GV-IP Camera Stream Ratio Resolution Rate GV-FD2510 1600 x 1200 GV-MDR220 1280 x 960 GV-MDR2400 Series 1920 x 1080 Main 16:9 GV-MDR2500 Series 1280 x 720 GV-MFD220 1280 x 1024 GV-MFD2401 Series GV-MFD2501 Series 640 x 480 GV-PT220D 320 x 240 GV-UBL2411 640 x 360...
  • Page 462 Appendix Max. Frame GV-IP Camera Stream Ratio Resolution Rate GV-BL320D 2048 x 1536 20 fps GV-BL3400 1600 x 1200 GV-BL3410 Main 1280 x 960 GV-BX320D Series 1920 x 1080 GV-BX3400 Series 16:9 1280 x 720 GV-BX320D-E 1280 x 1024 GV-BX3400-E GV-FD320D 640 x 480 GV-FD3400...
  • Page 463 Max. Frame GV-IP Camera Stream Ratio Resolution Rate 2560 x 1920 10 fps GV-BL5310 2048 x 1536 20 fps GV-BX520D 1600 x 1200 GV-BX5300 Series Main 1280 x 960 GV-BX520D-E 1920 x 1080 GV-BX5300-E 16:9 1280 x 720 GV-FD5300 1280 x 1024 GV-MDR520 30 fps 640 x 480...

  • Page 464: Support Lists

    Appendix D. Support Lists  Support List for GV-Backup Center, GV-Video Gateway and GV- Recording Server GV-IP Camera Model Supported Version GV-BX120D V1.03 or later GV-BX220D Series GV-BX320D Series GV-BX130D Series V1.04 or later GV-BX520D V1.05 or later Box Camera...
  • Page 465 GV-IP Camera Model Supported Version GV-BL120D V1.03 or later GV-BL220D Bullet Camera GV-BL320D GV-BL130D V1.04 or later PTZ Camera GV-PTZ010D V1.08 or later GV-VD120D Series GV-VD220D Series Vandal Proof IP Dome V1.03 or later GV-VD320D Series GV-FD120D GV-FD220D Fixed IP Dome V1.03 or later GV-FD320D GV-CB120...
  • Page 466 Appendix  Support List for Transmit Audio GV-IP Camera Model Supported Version GV-BX120D GV-BX220D Series V1.05 or later GV-BX320D Series GV-BX130D Series V1.04 or later GV-BX520D V1.05 or later Box Camera GV-BX1200 Series GV-BX1300 Series V1.15 or later GV-BX2400 Series...
  • Page 467 GV-IP Camera Model Supported Version GV-BL120D GV-BL220D V1.05 or later Bullet Camera GV-BL320D GV-BL130D V1.04 or later PTZ Camera GV-PTZ010D V1.08 or later GV-VD120D Series Vandal Proof IP Dome GV-VD220D Series V1.05 or later GV-VD320D Series GV-FD120D GV-FD220D Fixed IP Dome V1.05 or later GV-FD320D GV-CB120...
  • Page 468 Appendix  Support List for System Log GV-IP Camera Model Supported Version GV-BX120D GV-BX220D Series GV-BX320D Series V1.11 or later GV-BX130D Series GV-BX520D Box Camera GV-BX1200 Series GV-BX1300 Series GV-BX2400 Series V1.15 or later GV-BX3400 Series GV-BX5300 Series GV-BX120D-E GV-BX220D-E V1.11 or later...
  • Page 469 GV-IP Camera Model Supported Version GV-BL120D GV-BL130D Bullet Camera V1.11 or later GV-BL220D GV-BL320D PTZ Camera GV-PTZ010D V1.08 or later GV-VD120D Series Vandal Proof IP Dome GV-VD220D Series V1.11 or later GV-VD320D Series GV-FD120D GV-FD220D Fixed IP Dome V1.11 or later GV-FD320D GV-CB120 GV-CB220...

  • Page 470: Rtsp Protocol Command

    Appendix E. RTSP Protocol Command The GV-IPCAM H.264 can support RTSP protocol for both audio and video streaming.  If you use the QuickTime player, enter: rtsp://<IP of the GV-IPCAM H.264:8554/<CH No.>.sdp For example, rtsp://192.168.3.111:8554/CH001.sdp  If you use the VLC, and if authentication is required, enter: rtsp://username:password@<IP of the GV-IPCAM H.264:8554/<CH No.>.sdp For example, rtsp://admin:admin@192.168.3.111:8554/CH001.sdp...

  • Page 471: The Cgi Command

    Please note the supported version of the CGI command in different models: GV-IP Camera Supported Version GV-PTZ010D V1.07 or later GV-BX120D V1.00 or later GV-BX220D-2 / 223D-3 GV-BX320D-0 / 320D-1 GV-BL120D / 220D / 320D GV-VD120D / 121D / 122D / 123D V1.02 or later...
  • Page 472 Appendix GV-IP Camera Supported Version GV-BX1200 Series GV-BX1300 Series GV-BX2400 Series V1.15 or later GV-BX3400 Series GV-BX5300 Series GV-CA120 / 220 GV-CAW120 / 220 You can use the CGI command to obtain a snapshot of the live view or access the User Account Web interface. For a GV-IPCAM H.264 with the following details: IP address: 192.168.2.11 Username: admin...

  • Page 473: Dual Stream Support List

    GV-System. Resolution Supported GV-IP Camera Firmware Main Stream Sub Stream Version (H.264) (MJPEG) GV-BX120D V1.00 or later GV-BX1200 Series V1.15 or later GV-MFD120 V1.05 or later GV-BX120D-E GV-CBW120 V1.07 or later GV-MDR120...
  • Page 474 Appendix Resolution Supported Firmware GV-IP Camera Main Stream Sub Stream Version (H.264) (MJPEG) GV-BL130D V1.04 or later GV-BX130D Series 1280 x 1024 320 x 256 GV-MFD130 GV-BX1300 Series V1.15 or later GV-BX140DW V1.10 or later 1280 x 720 640 x 360 GV-BX220D Series V1.00 or later GV-BX2400 Series...
  • Page 475 Resolution Supported Firmware GV-IP Camera Main Stream Sub Stream Version (H.264) (MJPEG) GV-BX320D Series V1.00 or later GV-BX3400 Series V1.15 or later GV-MFD320 V1.05 or later GV-BX320D-E V1.07 or later GV-MDR320 2048 x 1536 320 x 240 GV-BL320D GV-VD320D V1.02 or later GV-VD321D GV-VD322D GV-VD323D...

  • Page 476: Power Supply Support List

    Appendix H. Power Supply Support List The supported power type is indicated with a tick () and the unsupported power type with a cross (). GV-IP Camera DC Power AC Power    Box Camera    Ultra Box Camera ...

  • Page 477: Supported Firmware For Flash Memory

    I. Supported Firmware for Flash Memory The 128 MB flash memory is supported in V1.09 or later in all models of GV-IPCam H.264 Series except GV-PTZ010D. To look up if the camera contains a 128 MB type flash memory, access the web interface or the GV IP Device Utility: ...

  • Page 478: Specifications

    Specifications: Box Camera (Part 1) Specifications: Box Camera (Part 1) This section details the specifications on GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D. Camera 1/3" progressive scan low lux GV-BX120D CMOS GV-BX140DW 1/3" progressive scan CMOS...
  • Page 479 Illumination Color 0.15 lux GV-BX220D Series GV-BX320D Series 0.10 Lux GV-BX520D IR On 0 Lux GV-BX140DW Automatic GV-BX120D Shutter GV-BX130D Series Automatic, Manual (1/5 ~ 1/8000 Speed GV-BX220D Series sec) GV-BX320D Series GV-BX520D Automatic, Manual (2800K ~ White Balance 8500K)
  • Page 480 Zoom Fixed Iris Fixed Max. Torque 0.049 N.m (Focus Screw) Varifocal Lens Megapixel Day/Night Yes (with removable IR-cut filter) GV-BX120D GV-BX130D-0 2.8 ~ 12 mm GV-BX140DW GV-BX220D-3 Focal Length GV-BX320D-0 3.1 ~ 8 mm GV-BX220D-2 2.8 ~ 6 mm GV-BX320D-1 GV-BX520D 4.5 ~ 10 mm...
  • Page 481 GV-BX120D GV-BX130D-0 F/1.4 GV-BX140DW GV-BX220D-3 Maximum Aperture GV-BX320D-0 F/1.2 GV-BX220D-2 F/1.3 GV-BX320D-1 GV-BX520D F/1.6 Mount GV-BX120D GV-BX130D-0 GV-BX140DW GV-BX220D-2 1/3” Image Format GV-BX220D-3 GV-BX320D-0 GV-BX320D-1 GV-BX520D 1/2’’ Focus Manual (w/lock) Zoom Manual (w/lock) GV-BX120D GV-BX130D-0 Operation DC drive GV-BX220D Series...
  • Page 482 Specifications: Box Camera (Part 1) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-BX120D 30 fps at 1280 x 1024 GV-BX130D Series GV-BX140DW 30 fps at 1280 x 720 Frame GV-BX220D Series 30 fps at 1920 x 1080...

  • Page 483: Video Resolution

    1280 x 960, 640 x 480, 320 x 240 Main 16:9 1280 x 720, 640 x 360, 448 x 252 Stream 1280 x 1024, 640 x 512, 320 x 256 GV-BX120D GV-BX130D Series 640 x 480, 320 x 240 Stream 16:9 640 x 360, 448 x 252...
  • Page 484 Specifications: Box Camera (Part 1) 2560 x 1920, 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 16:9 640 x 360, 448 x 252 GV-BX520D 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 485 GV-BX130D-1 GV-BX140DW Not functional GV-BX520D Auto Iris GV-BX120D GV-BX130D-0 GV-BX220D Series Connectors GV-BX320D Series Micro SD card slot Local Storage (SD/SDHC, version 2.0 only, Class 10) TV-Out BNC connector (640 x 480 resolution) Digital I/O 3-pin terminal block, pitch 2.5 mm / 0.1”...

  • Page 486: Power Over Ethernet

    Specifications: Box Camera (Part 1) Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet / PD PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Note: An STP cable can only work with a one-port PoE adapter. Web Interface Installation Management Web-based configuration...
  • Page 487 Application GV-NVR, GV-System, GV-Backup Center, Network Storage GV-Recording Server GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, and iPod Touch; GV-Eye HD for iPad Live Viewing IE, mobile phone CMS Server support GV-Control Center, GV-Center V2, GV-VSM All specifications are subject to change without notice...

  • Page 488: Specifications: Box Camera (Part 2)

    Specifications: Box Camera (Part 2) Specifications: Box Camera (Part 2) This section details the specifications on GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series. Camera 1/3" progressive scan low lux GV-BX1200 Series CMOS 1/3’’...
  • Page 489 Color 0.15 Lux GV-BX1300 Series 0.10 Lux GV-BX5300 Series IR ON 0 Lux Color 0.01 Lux GV-BX1500 Series IR ON 0 Lux Minimum Illumination Color 0.02 Lux GV-BX2500 Series 0.02 Lux IR On 0 Lux Color 0.08 Lux GV-BX2400 Series 0.05 Lux GV-BX3400 Series IR On...
  • Page 490 Specifications: Box Camera (Part 2) Fixed Focal Lens (GV-BX1200-0F~2F / BX1300-0F~2F / BX1500-0F~2F / BX2400-0F~2F / BX2500-0F~2F / BX3400-0F~2F / BX1500-8F / BX2400-8F / BX2500-8F / BX3400-8F / BX5300-8F) Megapixel Day/Night Yes (with removable IR-cut filter) GV-BX1200-0F GV-BX1300-0F GV-BX1500-0F 4 mm GV-BX2400-0F GV-BX2500-0F GV-BX3400-0F...
  • Page 491 GV-BX1200-0F GV-BX1300-0F GV-BX1500-0F F/1.5 GV-BX2400-0F GV-BX2500-0F GV-BX3400-0F GV-BX1200-1F GV-BX1200-2F GV-BX1300-1F GV-BX1300-2F GV-BX1500-1F Maximum Aperture GV-BX1500-2F F/1.6 GV-BX2400-1F GV-BX2400-2F GV-BX2500-1F GV-BX2500-2F GV-BX3400-1F GV-BX3400-2F GV-BX1500-8F GV-BX2400-8F GV-BX2500-8F F/1.8 GV-BX3400-8F GV-BX5300-8F Mount...
  • Page 492 Specifications: Box Camera (Part 2) GV-BX1200-0F GV-BX1300-0F GV-BX1500-0F 1/3” GV-BX2400-0F GV-BX2500-0F GV-BX3400-0F GV-BX1200-1F GV-BX1200-2F GV-BX1300-1F GV-BX1300-2F GV-BX1500-1F Image Format GV-BX1500-2F GV-BX2400-1F GV-BX2400-2F GV-BX2500-1F 1/2.5” GV-BX2500-2F GV-BX3400-1F GV-BX3400-2F GV-BX1500-8F GV-BX2400-8F GV-BX2500-8F GV-BX3400-8F GV-BX5300-8F...
  • Page 493 GV-BX1200-0F 63° GV-BX1300-0F 49° GV-BX1500-0F 63° GV-BX2400-0F 58° GV-BX2500-0F 72° GV-BX3400-0F 61° GV-BX1200-1F 36° GV-BX1300-1F 26° GV-BX1500-1F 36° GV-BX2400-1F 32° GV-BX2500-1F 40° Horizontal FOV GV-BX3400-1F 35° GV-BX1200-2F 23° GV-BX1300-2F 17° GV-BX1500-2F 23° GV-BX2400-2F 21° GV-BX2500-2F 25° GV-BX3400-2F 23° GV-BX1500-8F 90° GV-BX2400-8F 83°...
  • Page 494 Specifications: Box Camera (Part 2) Varifocal Lens (GV-BX1200-3V / BX1300-3V / BX1500-3V / BX2400-3V / BX2400-4V / BX2500-3V / BX3400-4V / BX3400-5V / BX5300-6V) Megapixel Day/Night Yes (with removable IR-cut filter) GV-BX1200-3V GV-BX1300-3V GV-BX1500-3V 2.8 ~ 12 mm GV-BX2400-3V GV-BX2500-3V Focal Length GV-BX2400-4V 3 ~ 10.5 mm...
  • Page 495 GV-BX1200-3V GV-BX1300-3V GV-BX1500-3V 1/2.7’’ GV-BX2400-3V GV-BX2500-3V Image Format GV-BX2400-4V GV-BX3400-4V GV-BX3400-5V 1/3’’ GV-BX5300-6V 1/2’’ GV-BX1200-3V 87° ~ 31° GV-BX1300-3V 64° ~ 23° GV-BX1500-3V 86° ~ 31° GV-BX2400-3V 77° ~ 28° Horizontal FOV GV-BX2500-3V 105° ~ 36° GV-BX2400-4V 73° ~ 27° GV-BX3400-4V 78°...
  • Page 496 Specifications: Box Camera (Part 2) Torque 0.049 N.m (Focus / Zoom screws) Operation H.264, MJPEG Video Compression Dual streams from H. 264 or MJPEG Video Stream GV-BX1200 Series 30 fps at 1280 x 1024 GV-BX1300 Series GV-BX1500 Series GV-BX2400 Series Frame 30 fps at 1920 x 1080 Rate...
  • Page 497 Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main 16:9 1280 x 720, 640 x 360, 448 x 252 Stream GV-BX1200 Series 1280 x 1024, 640 x 512, 320 x 256 GV-BX1300 Series 640 x 480, 320 x 240 GV-BX1500 Series 16:9 640 x 360, 448 x 252...
  • Page 498 Specifications: Box Camera (Part 2) 2560 x 1920, 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 16:9 640 x 360, 448 x 252 GV-BX5300 Series 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9...
  • Page 499 1 In (Using the built-in microphone or externally connecting a microphone) Audio 1 Out (Stereo phone jack, 3.5 mm / 0.14”) GV-BX1200 Series GV-BX1300 Series GV-BX1500 Series Auto Iris Yes (with varifocal lens) GV-BX2400 Series GV-BX2500 Series Connectors GV-BX3400 Series GV-BX5300 Series Not functional Local...
  • Page 500 Specifications: Box Camera (Part 2) General Environment Temperature 0°C ~ 50°C (32°F ~ 122°F) Humidity 10% to 90% (no condensation) Power Source 12V DC / PoE GV-BX1200 Series GV-BX1300 Series GV-BX1500 Series 9.5 W Max. Power GV-BX2400 Series Consumption GV-BX3400 Series GV-BX5300 Series GV-BX2500 Series 7.99 W (Without lens) 75.5 x 75 x 54 mm...
  • Page 501 Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Picture Access from Web Browser in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch...

  • Page 502: Specifications: Ultra Box Camera

    Specifications: Ultra Box Camera Specifications: Ultra Box Camera Camera 1/2.5’’ progressive scan Image Sensor CMOS GV-UBX1301 Series 1280 (H) x 1024 (V) Picture GV-UBX2301 Series 1920 (H) x 1080 (V) Elements GV-UBX3301 Series 2048 (H) x 1536 (V) Color 0.15 Lux Minimum 0.10 Lux Illumination...
  • Page 503 GV-UBX1301-1F GV-UBX2301-1F 4 mm GV-UBX3301-1F Focal Length GV-UBX1301-2F GV-UBX2301-2F 8 mm GV-UBX3301-2F GV-UBX1301-0F GV-UBX2301-0F GV-UBX3301-0F GV-UBX1301-1F Maximum F/1.6 GV-UBX2301-1F Aperture GV-UBX3301-1F GV-UBX1301-2F GV-UBX2301-2F GV-UBX3301-2F Mount M12, Pitch 0.5 mm Image Format 1/3” GV-UBX1301-0F 66° 49° GV-UBX1301-1F 25° GV-UBX1301-2F 80° GV-UBX2301-0F Horizontal 58°...
  • Page 504 Specifications: Ultra Box Camera Operation Video Compression H.264, MJPEG Video Stream Dual streams from H. 264 or MJPEG GV-UBX1301 Series 30 fps at 1280 x 1024 Frame Rate GV-UBX2301 Series 30 fps at 1920 x 1080 GV-UBX3301 Series 20 fps at 2048 x 1536 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation,...
  • Page 505 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 640 x Stream 16:9 360, 448 x 252 GV-UBX2301 Series 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252 Stream...
  • Page 506 Specifications: Ultra Box Camera Mechanical Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Using the built-in microphone) Connectors Audio 1 Out (Stereo phone jack, 3.5 mm / 0.14”) Micro SD card slot Local Storage (SD/SDHC, version 2.0 only, Class 10) LED Indicator 2 LEDs: Power, Status...
  • Page 507 Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance or Utility Camera live view, video recording, change video quality, bandwidth control, image Access from Web Browser snapshot, audio, Picture in Picture, Picture and Picture, Privacy Mask, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German /...

  • Page 508: Specifications: Target Box Camera

    Specifications: Target Box Camera Specifications: Target Box Camera Camera Image Sensor 1/3’’ progressive scan low lux CMOS Picture Elements 1280 (H) x 1024 (V) Color 0.05 Lux Minimum 0.03 Lux Illumination IR ON 0 Lux Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control...
  • Page 509 Max. IR Distance 15 m (50 ft) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H. 264 or MJPEG Frame Rate 30 fps at 1280 x 1024 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Image Setting Orientation, Shutter Speed, D/N Sensitivity, Backlight Compensation, WDR, Defog Audio Compression...
  • Page 510 Specifications: Target Box Camera Mechanical Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable Connectors Audio 1 In (built-in microphone) LED Indicator 2 LEDs: Power, Status General Environment Temperature 0°C ~ 50°C (32°F ~ 122°F) Humidity 10% to 90% (no condensation) Power Source 12V DC / PoE Max.
  • Page 511 Web Interface Installation Web-based configuration Management Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change video quality, bandwidth control, image Access from Web snapshot, audio, Picture in Picture, Picture and Browser Picture, Privacy Mask, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek /...

  • Page 512: Specifications: Ir Arctic Box Camera

    Specifications: IR Arctic Box Camera Specifications: IR Arctic Box Camera Camera GV-BX120D-E 1/3" progressive scan low lux CMOS GV-BX1500-E 1/3" progressive scan super low lux CMOS GV-BX2400-E 1/3.2" progressive scan CMOS Image GV-BX3400-E Sensor GV-BX220D-E GV-BX320D-E 1/2.5” progressive scan CMOS...
  • Page 513 GV-BX520D-E IR ON 0 Lux GV-BX5300-E Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic GV-BX120D-E 50 dB GV-BX1500-E 55 dB GV-BX2400-E 47 dB GV-BX3400-E S/N Ratio GV-BX220D-E GV-BX320D-E 45 dB...
  • Page 514 Specifications: IR Arctic Box Camera GV-BX220D-E 2.8 ~ 6 mm GV-BX320D-E GV-BX1500-E Focal GV-BX2400-E 3 ~ 10.5 mm Length GV-BX3400-E GV-BX520D-E 4.5 ~ 10 mm GV-BX5300-E GV-BX120D-E GV-BX1500-E F/1.4 GV-BX2400-E GV-BX3400-E Maximum Aperture GV-BX220D-E F/1.3 GV-BX320D-E GV-BX520D-E F/1.6 GV-BX5300-E Mount...
  • Page 515 GV-BX120D-E GV-BX1500-E GV-BX220D-E DC drive GV-BX2400-E Operation Iris GV-BX320D-E GV-BX3400-E GV-BX520D-E Manual (w/lock) GV-BX5300-E IR Quantity Max. IR Distance 15 m (50 ft) Max. Torque 0.049 N.m (Focus/Zoom screws) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG...
  • Page 516 Main 16:9 1280 x 720, 640 x 360, 448 x 252 Stream 1280 x 1024, 640 x 512, 320 x 256 GV-BX120D-E 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252 Stream 640 x 512, 320 x 256...
  • Page 517 640 x 480, 320 x 240 GV-BX320D-E 16:9 640 x 360, 448 x 252 Stream 640 x 512, 320 x 256 2560 x 1920, 2048 x 1536, 4 : 3 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 640 x...
  • Page 518 Specifications: IR Arctic Box Camera 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 640 x 16:9 Stream 360, 448 x 252 GV-BX3400-E 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 519 Tilt 0° ~ 90° Temperature Detector Power Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (externally connecting a microphone) Audio 1 Out (Stereo phone jack, 3.5 mm / 0.14”) GV-BX120D-E GV-BX1500-E Connectors GV-BX220D-E DC Drive GV-BX2400-E Auto Iris GV-BX320D-E GV-BX3400-E...
  • Page 520 Specifications: IR Arctic Box Camera GV-BX120D-E GV-BX220D-E 24 W GV-BX320D-E GV-BX520D-E Max. Power Consumption GV-BX1500-E 20 W GV-BX2400-E 23 W GV-BX3400-E GV-BX5300-E 21.6 W 100.5 x 100.5 x 317.5 mm Dimensions (3.96’’ x 3.96’’ x 12.5’’) Weight 3.2 kg (7.11 lb)
  • Page 521 Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change video quality, bandwidth control, image Access from Web Browser snapshot, audio, Picture in Picture, Picture and Picture, Privacy Mask, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek...
  • Page 522 Specifications: IR Arctic Box Camera Specifications: GV-PA481 PoE Standard IEEE 802.3at Power over Ethernet / PD PoE Power Output DC 48V, 1A (48W Max.) (10/100 Out) Max 100 m / 328 ft from GV-PA481 to IP Ethernet Cable Length device, CAT5 Power Input AC 100V ~ 240V, 2A Operating Temperature...

  • Page 523: Specifications: Mini Fixed Dome (Part 1)

    Specifications: Mini Fixed Dome (Part 1) This section details the specifications on GV-MFD120 / 130 / 220 / 320 / 520. Camera GV-MFD120 1/3" progressive scan low lux CMOS GV-MFD130 Image GV-MFD220 Sensor 1/2.5’’ progressive scan CMOS GV-MFD320 GV-MFD520 GV-MFD120 1280 (H) x 1024 (V) GV-MFD130 Picture...
  • Page 524 Specifications: Mini Fixed Dome (Part 1) GV-MFD120 50 dB GV-MFD130 S/N Ratio GV-MFD220 45 dB GV-MFD320 GV-MFD520 Lens Megapixel Day/Night Yes (electronic) Lens Type Fixed GV-MFD120 4.05 mm GV-MFD130 Focal GV-MFD220 Length 2.54 mm GV-MFD320 GV-MFD520 F/1.5 GV-MFD120 GV-MFD130 Maximum GV-MFD220 Aperture F/2.8...
  • Page 525 GV-MFD120 67° GV-MFD130 85° Horizontal GV-MFD220 101° GV-MFD320 110° 138° GV-MFD520 Operation Fixed (Focus / Zoom / Iris) Note: For GV-MFD, the day/night function is only supported by V1.07 or later. Operation H.264, MJPEG Video Compression Video Stream Dual streams from H.264 or MJPEG GV-MFD120 30 fps at 1280 x 1024 GV-MFD130...
  • Page 526 Specifications: Mini Fixed Dome (Part 1) Video Resolution 1280 x 960, 640 x 480, 320 x 240 GV-MFD120 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 GV-MFD130 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 GV-MFD120 Sub Stream...
  • Page 527 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF (Profile Protocol S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical Camera -45° ~ 45° Angle 0° ~ 90° Tilt Adjustment Temperature Detector GV-MFD120 GV-MFD130 PoE, 2-pin terminal block Power GV-MFD220 GV-MFD320...
  • Page 528 Specifications: Mini Fixed Dome (Part 1) General Environment Temperature 0°C ~ 50°C (32°F ~ 122°F) Humidity 10% - 90% (no condensation) GV-MFD120 GV-MFD130 Power PoE, DC 12V Source GV-MFD220 GV-MFD320 GV-MFD120 4.5 W GV-MFD130 Max. Power GV-MFD220 5.5 W Consumption GV-MFD320 GV-MFD520 Camera Body...
  • Page 529 Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance or Utility Camera live view, video recording, change video quality, bandwidth control, Access from Web Browser image snapshot, audio, Picture in Picture, Picture and Picture, Privacy Mask, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French /...

  • Page 530: Specifications: Mini Fixed Dome (Part 2)

    Specifications: Mini Fixed Dome (Part 2) Specifications: Mini Fixed Dome (Part 2) This section details the specifications on GV-MFD1501 series / 2401 series / 2501 series / 3401 series / 5301 series. Camera 1/3’’ progressive scan super low GV-MFD1501 Series lux CMOS 1/2.8’’...
  • Page 531 Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic GV-MFD1501 Series GV-MFD2401 Series 55 dB GV-MFD3401 Series Ratio GV-MFD5301 Series GV-MFD2501 Series 52 dB GV-MFD2401 Series GV-MFD3401 Series Lens Megapixel Day/Night Yes (electronic) Lens Type Fixed...
  • Page 532 Specifications: Mini Fixed Dome (Part 2) GV-MFD1501-2F GV-MFD2401-2F 8 mm GV-MFD2501-2F GV-MFD3401-2F GV-MFD5301-2F GV-MFD1501-3F GV-MFD2401-3F Focal Length 12 mm GV-MFD2501-3F GV-MFD3401-3F GV-MFD5301-3F GV-MFD1501-4F GV-MFD2401-4F 2.1 mm GV-MFD2501-4F GV-MFD3401-4F GV-MFD1501-0F GV-MFD2401-0F F/2.0 GV-MFD2501-0F GV-MFD3401-0F GV-MFD5301-0F Maximum Aperture GV-MFD1501-1F GV-MFD2401-1F GV-MFD2501-1F F/1.5 GV-MFD3401-1F GV-MFD5301-1F...
  • Page 533 GV-MFD1501-2F GV-MFD1501-3F GV-MFD2401-2F GV-MFD2401-3F GV-MFD2501-2F F/1.6 GV-MFD2501-3F GV-MFD3401-2F Maximum Aperture GV-MFD3401-3F GV-MFD5301-2F GV-MFD5301-3F GV-MFD1501-4F GV-MFD2401-4F F/1.8 GV-MFD2501-4F GV-MFD3401-4F M12, Pitch 0.5 mm Mount Image Format 1/3’’ GV-MFD1501-0F 87° GV-MFD2401-0F 79° GV-MFD2501-0F 99° GV-MFD3401-0F 80° GV-MFD5301-0F 103° GV-MFD1501-1F 67° Horizontal GV-MFD2401-1F 58°...
  • Page 534 Specifications: Mini Fixed Dome (Part 2) GV-MFD2501-2F 38° GV-MFD3401-2F 33° GV-MFD5301-2F 41° GV-MFD1501-3F 22° GV-MFD2401-3F 20° GV-MFD2501-3F 25° Horizontal GV-MFD3401-3F 21° GV-MFD5301-3F 26° GV-MFD1501-4F 124° GV-MFD2401-4F 112° GV-MFD2501-4F 150° GV-MFD3401-4F 120° Operation Fixed (Focus / Zoom / Iris) Note: The day/night function is only supported by V1.07 or later. Operation Video Compression H.264, MJPEG...
  • Page 535 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less 50/60 Hz, Image Image Setting Orientation, Shutter Speed, Backlight Compensation, D/N sensitivity, WDR, Defog, Super Low Lux Audio Compression G.711, AAC (Optional) Audio Support Two-Way Audio Sensor Input Alarm Output Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes).
  • Page 536 Specifications: Mini Fixed Dome (Part 2) 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 1920 x 1080, 1280 x 720, Main Stream 16:9 640 x 360, 448 x 252 GV-MFD3401 1280 x 1024, 640 x 512, Series 320 x 256 640 x 480, 320 x 240...
  • Page 537 Temperature Detector Power PoE, 2-pin terminal block Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Built-in microphone) Audio 1 Out (RCA female for speaker) Connectors GV-WiFi adapter or USB hard drive Local Micro SD card slot (SD/SDHC, version Storage 2.0 only, Class 10) LED Indicator 4 LEDs: Link, ACT, Power, Status Note:...
  • Page 538 Specifications: Mini Fixed Dome (Part 2) Power over Ethernet IEEE 802.3af Power over Ethernet / PD PoE Standard End-Span PoE Power Supply Type Per Port 48V DC, 350 mA. Max. 15.4 watts PoE Power Output Web Interface Installation Web-based configuration Management Firmware upgrade through Web Browser or Maintenance...

  • Page 539: Specifications: Mini Fixed Rugged Dome

    Specifications: Mini Fixed Rugged Dome Camera GV-MDR120 1/3" progressive scan low lux CMOS 1/3" progressive scan super low lux GV-MDR1500 Series CMOS GV-MDR220 GV-MDR320 Image 1/2.5’’ progressive scan CMOS GV-MDR520 Sensor GV-MDR5300 Series GV-MDR2400 Series 1/3.2’’ progressive scan CMOS GV-MDR3400 Series 1/2.8"...
  • Page 540 Specifications: Mini Fixed Rugged Dome Color 0.05 Lux GV-MDR120 0.03 Lux GV-MDR220 Color 0.15 Lux GV-MDR320 0.10 Lux GV-MDR520 Color GV-MDR1500 Series 0.01 Lux Minimum Illumination Color 0.08 Lux GV-MDR2400 Series GV-MDR3400 Series 0.05 Lux Color GV-MDR2500 Series 0.02 Lux Color 0.15 Lux GV-MDR5300 Series...
  • Page 541 Lens Megapixel Day/Night Yes (electronic) Lens Type Fixed GV-MDR120 4 mm GV-MDR220 2.54 mm GV-MDR320 GV-MDR520 GV-MDR1500-0F GV-MDR2400-0F 2.1 mm GV-MDR2500-0F GV-MDR3400-0F GV-MDR1500-1F GV-MDR2400-1F 2.8 mm GV-MDR2500-1F Focal Length GV-MDR3400-1F GV-MDR5300-1F GV-MDR1500-2F GV-MDR2400-2F GV-MDR2500-2F 3.8 mm GV-MDR3400-2F GV-MDR5300-2F GV-MDR1500-3F GV-MDR2400-3F 8 mm GV-MDR2500-3F GV-MDR3400-3F...
  • Page 542 Specifications: Mini Fixed Rugged Dome GV-MDR1500-4F GV-MDR2400-4F 12 mm Focal Length GV-MDR2500-4F GV-MDR3400-4F GV-MDR5300-4F F/1.5 GV-MDR120 GV-MDR220 F/2.8 GV-MDR320 GV-MDR520 GV-MDR1500-0F GV-MDR2400-0F GV-MDR2500-0F GV-MDR3400-0F Maximum F/1.8 GV-MDR1500-2F Aperture GV-MDR2400-2F GV-MDR2500-2F GV-MDR3400-2F GV-MDR5300-2F GV-MDR1500-1F GV-MDR2400-1F F/2.0 GV-MDR2500-1F GV-MDR3400-1F GV-MDR5300-1F...
  • Page 543 GV-MDR1500-3F GV-MDR2400-3F GV-MDR2500-3F GV-MDR3400-3F GV-MDR5300-3F Maximum F/1.6 Aperture GV-MDR1500-4F GV-MDR2400-4F GV-MDR2500-4F GV-MDR3400-4F GV-MDR5300-4F M12, Pitch 0.5 mm Mount GV-MDR120 GV-MDR1500 Series GV-MDR2400 Series 1/3’’ GV-MDR2500 Series GV-MDR3400 Series Image Format GV-MDR5300 Series GV-MDR220 GV-MDR320 1/2.5’’ GV-MDR520 GV-MDR120 70° 101° GV-MDR220 GV-MDR320 110°...
  • Page 544 Specifications: Mini Fixed Rugged Dome 80° 60° GV-MDR2400 30° 20° 135° 98° GV-MDR2500 72° 38° 25° Horizontal 121° 85° GV-MDR3400 63° 32° 21° 104° 76° GV-MDR5300 41° 27° Operation (Focus / Zoom / Iris) Fixed Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-MDR120...
  • Page 545 GV-MDR320 20 fps at 2048 x 1536 GV-MDR3400 Series Frame Rate GV-MDR520 10 fps at 2560 x 1920 GV-MDR5300 Series Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less 50/60 Hz, Image Orientation, Image Setting Shutter Speed, Backlight Compensation, D/N sensitivity, WDR, Defog, Super Low Audio Compression G.711, AAC (Optional) Audio Support...
  • Page 546 Specifications: Mini Fixed Rugged Dome 640 x 480, 320 x 240 GV-MDR220 GV-MDR2400 Series Sub Stream 16:9 640 x 360, 448 x 252 GV-MDR2500 Series 640 x 512, 320 x 256 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 640 x 360,...
  • Page 547 0° ~ 90° Tilt Camera Angle GV-MDR Adjustment 0° ~ 360° Rotate Temperature Detector Power Ethernet (10/100 Base-T), RJ-45 cable Ethernet Connectors Audio 1 In (Built-in microphone) Local Micro SD card slot Storage (SD/SDHC, version 2.0 only, Class 10) LED Indicator 3 LEDs: Link, Power, Status Note: SDXC and UHS-I card types are not supported.
  • Page 548 Specifications: Mini Fixed Rugged Dome ø14.7 mm (0.58’’) Connector ø27 mm (1.06’’) Waterproof Diameter Non-waterproof 16.8 x 13.8 mm (0.66’’ x 0.54’’) (Smaller) Weight 568 g (1.3 lb) IP67 Ingress Protection Vandal Resistance IK10 for metal casing GV-MDR120 GV-MDR220 CE, FCC, C-Tick, EN50155, RoHS Regulatory compliant GV-MDR320...
  • Page 549 Web Interface Installation Management Web-based configuration Maintenance Firmware upgrade through Web Browser or Utility Camera live view, video recording, change video quality, bandwidth control, image snapshot, audio, Access from Web Browser Picture in Picture, Picture and Picture, Privacy Mask, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Language...

  • Page 550: Specifications: Target Mini Fixed Dome

    Specifications: Target Mini Fixed Dome Specifications: Target Mini Fixed Dome Camera 1/3’’ progressive scan low lux CMOS Image Sensor Picture Elements 1280 (H) x 1024 (V) Color 0.05 Lux Minimum 0.03 Lux Illumination IR ON 0 Lux Automatic, Manual (1/5 ~ 1/8000 Shutter Speed sec) White Balance...
  • Page 551 93° GV-EFD1100-0F Horizontal 64° GV-EFD1100-1F Fixed Operation (Focus / Zoom / Iris) 12 IR LEDs IR LED Quantity 15 m (50 ft) Max. IR Distance Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG Frame Rate 30 fps at 1280 x 1024 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image...
  • Page 552 Specifications: Target Mini Fixed Dome Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF Protocol (Profile S), QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical -45° ~ 45° Camera Angle Adjustment Tilt 0° ~ 55° Power 2-pin terminal block, PoE Connectors Ethernet...
  • Page 553 Per Port 48V DC, 350 mA. Max. 15.4 watts PoE Power Output Web Interface Installation Web-based configuration Management Firmware upgrade through Web Browser or Maintenance Utility Camera Live View, Video Recording, Change Video Quality, Bandwidth Control, Access from Web Image Snapshot, Audio, Picture in Picture, Browser Picture and Picture, Privacy Mask, Text Overlay, Digital PTZ...

  • Page 554: Specifications: Bullet Camera (Part 1)

    Specifications: Bullet Camera (Part 1) Specifications: Bullet Camera (Part 1) This section details the specifications on GV-BL120D / 130D / 220D / 320D and GV-BL1200 / 1300 / 1500 / 2400 / 2500 / 3400. Camera GV-BL120D 1/3" progressive scan low lux CMOS GV-BL1200 GV-BL130D GV-BL220D...
  • Page 555 GV-BL320D Picture 2048 (H) x 1536 (V) Elements GV-BL3400 Color 0.05 Lux GV-BL120D 0.03 Lux GV-BL1200 IR ON 0 Lux GV-BL130D Color 0.15 Lux GV-BL220D 0.10 Lux GV-BL320D IR On 0 Lux GV-BL1300 Color 0.01 Lux Minimum Illumination GV-BL1500 0.01 Lux IR On 0 Lux Color...
  • Page 556 Specifications: Bullet Camera (Part 1) GV-BL130D GV-BL220D 45 dB GV-BL320D GV-BL1300 S/N Ratio GV-BL1500 55 dB GV-BL2500 52 dB GV-BL2400 47 dB GV-BL3400 GV-BL2400 WDR Pro Yes (with WDR sensor) GV-BL3400 Lens Megapixel Day / Night Yes (with removable IR-cut filter) Lens Type Varifocal Focal Length...
  • Page 557 Zoom Manual (w/lock) Operation Iris DC drive IR LED Quantity 16 IR LEDs GV-BL120D GV-BL220D 15 m (50 ft) GV-BL320D GV-BL1200 40m (131 ft) Max. IR GV-BL1300 Distance GV-BL1500 70m (230 ft) GV-BL2400 GV-BL2500 50 m (164 ft) GV-BL3400 Max. Torque (Zoom/Focus 0.049 N.m Screws) Operation...
  • Page 558 Specifications: Bullet Camera (Part 1) GV-BL320D Frame Rate 20 fps at 2048 x 1536 GV-BL3400 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Shutter Image Setting Speed, D/N Sensitivity, Backlight Compensation, WDR, Defog, Super Low Audio Compression G.711, AAC (Optional) Audio Support Two-Way Audio Sensor Input...
  • Page 559 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 16:9 GV-BL220D 640 x 360, 448 x 252 GV-BL2400 1280 x 1024, 640 x 512, 320 x 256 GV-BL2500 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252 640 x 512, 320 x 256...
  • Page 560 Specifications: Bullet Camera (Part 1) Mechanical 0° ~ 360° Camera Angle Tilt 90° ~ 180° Adjustment Rotate 0° ~ 360° Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Brown terminal block or RCA female Audio for microphone);...
  • Page 561 Humidity 10% to 90% (no condensation) Power Source 12V DC / 24V AC / PoE GV-BL120D GV-BL130D 12 W GV-BL220D GV-BL320D GV-BL1200 Max. Power 6.72 W GV-BL1300 Consumption GV-BL1500 7.68 W GV-BL2500 GV-BL2400 7.2 W GV-BL3400 277.5 x 87.75 x 148.95 mm Camera Body (10.9’’...
  • Page 562 Specifications: Bullet Camera (Part 1) GV-BL120D GV-BL130D IP66 GV-BL220D GV-BL320D Ingress GV-BL1200 Protection GV-BL1300 GV-BL1500 IP67 GV-BL2400 GV-BL2500 GV-BL3400 GV-BL1200 GV-BL1300 GV-BL1500 Vandal IK10 for metal casing Resistance GV-BL2400 GV-BL2500 GV-BL3400 GV-BL120D GV-BL130D GV-BL220D GV-BL320D CE, FCC, C-Tick, RoHS GV-BL1200 compliant GV-BL1300 Regulatory...
  • Page 563 Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet / PD PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance or Utility Camera live view, video recording, change video quality, bandwidth control,...
  • Page 564 Specifications: Bullet Camera (Part 1) Application GV-NVR, GV-System, GV-Backup Network Storage Center, GV-Recording Server GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, and iPod Touch; GV-Eye HD for iPad Live Viewing IE, mobile phone GV-Control Center, GV-Center V2, CMS Server support GV-VSM All specifications are subject to change without prior notice.

  • Page 565: Specifications: Bullet Camera (Part 2)

    Specifications: Bullet Camera (Part 2) This section details the specifications on GV-BL1210 / 1510 / 2410 / 2510 / 3410 / 5310. Camera GV-BL1210 1/3" progressive scan low lux CMOS GV-BL1510 1/3" progressive scan super low lux CMOS Image 1/2.8" progressive scan super low lux GV-BL2510 Sensor CMOS...
  • Page 566 Specifications: Bullet Camera (Part 2) Color 0.01 Lux GV-BL1510 0.01 Lux IR ON 0 Lux Color 0.02 Lux GV-BL2510 0.02 Lux IR ON 0 Lux Minimum Illumination Color 0.08 Lux GV-BL2410 0.05 Lux GV-BL3410 IR ON 0 Lux Color 0.15 Lux GV-BL5310 0.10 Lux IR ON...
  • Page 567 Day / Night Yes (with removable IR-cut filter) Lens Type Motorized varifocal lens GV-BL1210 GV-BL1510 GV-BL2410 3 ~ 9 mm Focal Length GV-BL2510 GV-BL3410 GV-BL5310 4.5 ~ 9 mm Maximum Aperture F/1.2 Mount ø 14 mm Image Format 1/2.7’’ GV-BL1210 86°...
  • Page 568 Specifications: Bullet Camera (Part 2) GV-BL1210 40 m (131 ft) GV-BL5310 GV-BL1510 70 m (230 ft) Max. IR Distance GV-BL2410 GV-BL2510 50 m (164 ft) GV-BL3410 Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-BL1210 30 fps at 1280 x 1024 GV-BL1510 GV-BL2410...
  • Page 569 Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). The Super Low Lux adjustment (Image Settings) is only available for GV-BL1510/2510. Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 1280 x 1024, 640 x 512, 320 x 256...
  • Page 570 Specifications: Bullet Camera (Part 2) 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 16:9 640 x 360, 448 x 252 GV-BL3410 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252...
  • Page 571 Mechanical 0° ~ 360° Camera Angle Tilt 90° ~ 180° Adjustment Rotate 0° ~ 360° Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Brown terminal block or RCA female Audio for microphone); 1 Out (Green terminal Connectors block RCA female for speaker) Digital I/O...
  • Page 572 Specifications: Bullet Camera (Part 2) 289.02 x 87.75 x 148.95 mm Camera Body (11.4” x 3.45” x 5.86’’) Cable 1 m (3.28 ft) Length Dimensions Max. Cable ø7.1 mm (0.28”) Diameter Max. Connector ø25.2 mm (0.99”) Diameter Weight 1.4 Kg (3.08 lb) Ingress Protection IP67 Vandal Resistance...
  • Page 573 Camera live view, video recording, change video quality, bandwidth control, image Access from Web snapshot, digital I/O control, audio, Picture Browser in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian /...

  • Page 574: Specifications: Ultra Bullet Camera

    Specifications: Ultra Bullet Camera Camera GV-UBL1211 1/3" progressive scan low lux CMOS GV-UBL1301 Series 1/2.5’’ progressive scan CMOS 1/3" progressive scan super low lux GV-UBL1511 CMOS Image 1/2.8" progressive scan super low lux Sensor GV-UBL2511 CMOS GV-UBL2411 GV-UBL3411 1/3.2’’ progressive scan CMOS GV-UBL2401 Series GV-UBL3401 Series GV-UBL1211...
  • Page 575 Color 0.01 Lux GV-UBL1511 0.01 Lux IR ON 0 Lux Color 0.02 Lux GV-UBL2511 0.02 Lux IR ON 0 Lux Color 0.08 Lux Minimum GV-UBL2411 0.05 Lux Illumination GV-UBL3411 IR ON 0 Lux Color 0.15 Lux GV-UBL1301 Series 0.10 Lux IR ON 0 Lux Color...
  • Page 576 Specifications: Ultra Bullet Camera Lens Megapixel Day / Night Yes (with removable IR-cut filter) GV-UBL1211 GV-UBL1511 GV-UBL2411 Motorized varifocal Lens GV-UBL2511 Lens Type GV-UBL3411 GV-UBL1301 Series GV-UBL2401 Series Fixed Lens GV-UBL3401 Series GV-UBL1211 GV-UBL1511 GV-UBL2411 3 ~ 9 mm GV-UBL2511 GV-UBL3411 GV-UBL1301-0F GV-UBL2401-0F...
  • Page 577 GV-UBL1211 GV-UBL1511 GV-UBL2411 F/1.2 GV-UBL2511 GV-UBL3411 GV-UBL1301-0F GV-UBL2401-0F F/2.0 GV-UBL3401-0F Maximum GV-UBL1301-1F Aperture GV-UBL2401-1F F/1.5 GV-UBL3401-1F GV-UBL1301-2F GV-UBL2401-2F GV-UBL3401-2F F/1.6 GV-UBL1301-3F GV-UBL2401-3F GV-UBL3401-3F GV-UBL1211 GV-UBL1511 GV-UBL2411 ø 14 mm GV-UBL2511 Mount GV-UBL3411 GV-UBL1301 Series GV-UBL2401 Series GV-UBL3401 Series...
  • Page 578 Specifications: Ultra Bullet Camera GV-UBL1211 GV-UBL1511 GV-UBL2411 1/2.7” GV-UBL2511 Image Format GV-UBL3411 GV-UBL1301 Series GV-UBL2401 Series 1/3” GV-UBL3401 Series GV-UBL1211 86° ~ 32° GV-UBL1511 90° ~ 32° GV-UBL2411 82° ~ 30° GV-UBL2511 103° ~ 36° GV-UBL3411 86° ~ 31° 66° GV-UBL1301-0F 80°...
  • Page 579 Focus GV-UBL1301 Series Operation GV-UBL2401 Series Zoom Fixed GV-UBL3401 Series Iris IR LED Quantity 4 IR LEDs Max. IR Distance 10 m (32.81 ft) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-UBL1211 GV-UBL1301 Series 30 fps at 1280 x 1024 GV-UBL1511 Frame...
  • Page 580 Specifications: Ultra Bullet Camera Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main 1280 x 720, 640 x 360, 16:9 Stream 448 x 252 GV-UBL1211 1280 x 1024, 640 x 512, GV-UBL1301 Series 320 x 256 GV-UBL1511 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252 Stream...
  • Page 581 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF Protocol (Profile S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical Temperature Detector Power 2-pin terminal block, PoE Ethernet (10/100 Base-T), RJ-45 cable Ethernet Two types of models for selection: Waterproof or Non-Waterproof with Connectors smaller size...
  • Page 582 Specifications: Ultra Bullet Camera -20°C ~ 45°C Start-up (-4°F ~ 113°F) Environment GV-UBL1301 Series Temperature -30°C ~ 45°C Operation (-22°F ~ 113°F) 10% to 90% (no condensation) Humidity 5V DC / PoE Power Source GV-UBL1211 6.94 W GV-UBL2411 GV-UBL3411 GV-UBL1511 9.65 W Max.
  • Page 583 GV-UBL1301 Series GV-UBL2401 Series 730 g (1.6 lb) Weight GV-UBL3401 Series Ingress Protection IP67 Vandal Resistance IK10 for metal casing GV-UBL1211 GV-UBL2411 GV-UBL3411 CE, FCC, C-Tick, RoHS compliant GV-UBL1301 Series Regulatory GV-UBL2401 Series GV-UBL3401 Series GV-UBL1511 CE, FCC, RCM, RoHS compliant GV-UBL2511 Power over Ethernet IEEE 802.3af Power over Ethernet /...
  • Page 584 Specifications: Ultra Bullet Camera Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O Access from Web Browser control, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian...

  • Page 585: Specifications: Target Bullet Camera

    Specifications: Target Bullet Camera Camera Image Sensor 1/3" progressive scan low lux CMOS Picture Elements 1280 (H) x 1024 (V) Color 0.05 Lux Minimum Illumination 0.03 Lux IR ON 0 Lux Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic...
  • Page 586 Specifications: Target Bullet Camera Operation (Focus / Zoom / Iris) Fixed IR LED Quantity 24 IR LEDs Max. IR Distance 30 m (98.4 ft) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG Frame Rate 30 fps at 1280 x 1024 Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker-less, Image Image Setting...
  • Page 587 DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF Protocol (Profile S), QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical Power 2-pin terminal block, PoE Connectors Ethernet Ethernet (10/100 Base-T), RJ-45 cable General Start-up -20°C ~ 50°C (-4°F ~ 122°F) Environment Temperature Operation...
  • Page 588 Specifications: Target Bullet Camera Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance or Utility Camera live view, video recording, change video quality, bandwidth control, image snapshot, Picture in Picture, Access from Web Browser Picture and Picture, Privacy Mask, Tampering Alarm, Text Overlay, Digital Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French /...

  • Page 589: Specifications: Ptz Camera

    Specifications: PTZ Camera Camera Model Name GV-PTZ010D-N GV-PTZ010D-P Image Sensor 1/4" CCD image sensor Picture Elements 704 (H) x 480 (V) 704 (H) x 576 (V) Color 2.5 Lux at F/1.8 Minimum Illumination 0.07 Lux at F/1.8 Automatic, Automatic, Shutter Speed Manual (1/60 ~ Manual (1/50 ~ 1/120,000 sec)
  • Page 590 Specifications: PTZ Camera Operation Model Name GV-PTZ010D-N GV-PTZ010D-P Video Format NTSC Video Compression H.264, MPEG4, MJPEG Dual Streams from two of H.264, MPEG4 or Video Stream MJPEG 704 x 480 704 x 576 Main Stream 704 x 240 704 x 288 Video 352 x 240 352 x 288...
  • Page 591 Mechanical -175° ~ 175° Camera Angle Adjustment Tilt -45° ~ 90° Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Using a built-in or an externally connected microphone) Audio 1 Out (Stereo phone jack, 3.5 mm / Connectors 0.14”) 3-pin terminal block...
  • Page 592 Specifications: PTZ Camera Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet / PD PoE Power Supply Type End-Span Per Port 48V DC, 350mA. Max. 15.4 PoE Power Output watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Maintenance Browser or Utility Camera live view, video recording,...
  • Page 593 Application GV-NVR, GV-System, GV-Backup Network Storage Center, GV-Recording Server GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, and iPod Touch; GV-Eye HD for iPad Live Viewing IE, mobile phone GV-Center V2, GV-VSM, GV-Control CMS Server support Center Note: GV-Backup Center and GV-Recording Server are only supported in V1.08 or later.

  • Page 594: Specifications: Pt Camera

    Specifications: PT Camera Specifications: PT Camera Camera Image Sensor 1/2.5" progressive scan CMOS GV-PT130D 1280 (H) x 1024 (V) Picture GV-PT220D 1920 (H) x 1080 (V) Elements GV-PT320D 2048 (H) x 1536 (V) Color 0.15 Lux Minimum 0.10 Lux Illumination IR ON 0 Lux Shutter Speed...
  • Page 595 Image Format 1/2.5’’ GV-PT130D 49° Horizontal GV-PT220D 58° GV-PT320D 62° Focus Manual (w/lock) Zoom Fixed Operation Iris Fixed IR LED Quantity 10 IR LEDs Max. IR Distance 15 m (50 ft) Operation Video Compression H.264, MJPEG Video Stream Dual streams 1280 x 960, 640 x 480, 320 x 240 Main...
  • Page 596 Specifications: PT Camera 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 16:9 Stream 640 x 360, 448 x 252 1280 x 1024, 640 x 512, GV-PT220D 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252 Stream...
  • Page 597 Sensor Input 1 Input (Dry Contact) Alarm Output 1 Output (200mA 5V DC) Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, Protocol ONVIF (Profile S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA...
  • Page 598 Specifications: PT Camera General 0°C ~ 50°C (32°F ~ 122°F) Environment Temperature 10% to 90% (no condensation) Humidity 12V DC / 24V AC / PoE Power Source 12.5 W (max. 1.25A at 12V DC) Max. Power Consumption 167.75 x 166.78 x 135.2 mm With mounting base and cover (6.6”...
  • Page 599 Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance or Utility Camera live view, video recording, change video quality, bandwidth control, Access from Web Browser image snapshot, audio, Picture in Picture, Picture and Picture, Text Overlay Bulgarian / Czech / Danish / Dutch / English / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian /...

  • Page 600: Specifications: Vandal Proof Ip Dome (Part 1)

    Specifications: Vandal Proof IP Dome (Part 1) Specifications: Vandal Proof IP Dome (Part 1) This section details the specifications on GV-VD120D / 121D / 122D / 123D, GV-VD220D / 221D / 222D / 223D, GV-VD320D / 321D / 322D / 323D and GV-VD1500 / 2400 / 2500 / 3400.
  • Page 601 GV-VD120D GV-VD121D GV-VD122D 1280 (H) x 1024 (V) GV-VD123D GV-VD1500 GV-VD220D GV-VD221D Picture GV-VD222D 1920 (H) x 1080 (V) Elements GV-VD223D GV-VD2400 GV-VD2500 GV-VD320D GV-VD321D GV-VD322D 2048 (H) x 1536 (V) GV-VD323D GV-VD3400 GV-VD120D Color 0.05 Lux GV-VD121D 0.03 Lux GV-VD122D IR ON 0 Lux...
  • Page 602 Specifications: Vandal Proof IP Dome (Part 1) GV-VD220D Color 0.15 Lux GV-VD221D 0.10 Lux GV-VD222D GV-VD223D GV-VD320D IR ON 0 Lux Minimum GV-VD321D Illumination GV-VD322D GV-VD323D Color 0.08 Lux GV-VD2400 0.05 Lux GV-VD3400 IR ON 0 Lux Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control...
  • Page 603 GV-VD2400 S/N Ratio 47 dB GV-VD3400 GV-VD2400 WDR Pro GV-VD3400 Lens Megapixel Day/Night Yes (with removable IR-cut filter) Lens Type Varifocal Focal Length 3 ~ 9 mm GV-VD120D GV-VD121D GV-VD122D GV-VD123D GV-VD220D GV-VD221D F/1.3 GV-VD222D GV-VD223D Maximum GV-VD320D Aperture GV-VD321D GV-VD322D GV-VD323D GV-VD1500...
  • Page 604 Specifications: Vandal Proof IP Dome (Part 1) Mount ø 14 mm GV-VD120D GV-VD121D GV-VD122D GV-VD123D GV-VD1500 GV-VD220D GV-VD221D 1/3’’ GV-VD222D Image Format GV-VD223D GV-VD320D GV-VD321D GV-VD322D GV-VD323D GV-VD2400 GV-VD2500 1/2.7’’ GV-VD3400 GV-VD120D 86° ~ 32° GV-VD220D 82° ~ 30° GV-VD320D 86°...
  • Page 605 GV-VD120D GV-VD121D GV-VD122D GV-VD123D GV-VD220D GV-VD221D GV-VD222D GV-VD223D 15 m (50 ft) GV-VD320D Max. IR GV-VD321D Distance GV-VD322D GV-VD323D GV-VD1500 GV-VD2400 GV-VD3400 GV-VD1500 GV-VD2400 30 m (98.4 ft) GV-VD2500 GV-VD3400 Max. Torque 0.049 N.m (Focus / Zoom Screws) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG...
  • Page 606 Specifications: Vandal Proof IP Dome (Part 1) GV-VD120D GV-VD121D GV-VD122D 30 fps at 1280 x 1024 GV-VD123D GV-VD1500 GV-VD220D GV-VD221D GV-VD222D Frame 30 fps at 1920 x 1080 Rate GV-VD223D GV-VD2400 GV-VD2500 GV-VD320D GV-VD321D GV-VD322D 20 fps at 2048 x 1536 GV-VD323D GV-VD3400 Brightness, Contrast, Saturation,...
  • Page 607 Video Resolution 1280 x 960, 640 x 480, 320 x 240 16:9 1280 x 720, 640 x 360, 448 x 252 GV-VD120D Main Stream 1280 x 1024, 640 x 512, GV-VD121D 320 x 256 GV-VD122D GV-VD123D 640 x 480, 320 x 240 GV-VD1500 Sub Stream 16:9...
  • Page 608 Specifications: Vandal Proof IP Dome (Part 1) Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF (Profile S), PSIA, QoS Protocol (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical 0° ~ 350° Camera Angle Tilt 10° ~ 90° Adjustment Rotate 0°...
  • Page 609 General Environment Temperature -30°C ~ 50°C (-22°F ~ 122°F) Humidity 10% to 90% (no condensation) Power Source 12V DC / 24V AC / PoE Max. Power Consumption 12 W Camera Body ø165 x 125 mm (6.49” x 4.92’’) Cable Length 1 m (3.28 ft) Dimensions Cable Diameter...
  • Page 610 Specifications: Vandal Proof IP Dome (Part 1) Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet / PD PoE Power Supply Type End-Span Per Port 48V DC, 350mA. Max. 15.4 PoE Power Output watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Maintenance Browser or Utility...
  • Page 611 Application GV-NVR, GV-System, GV-Backup Network Storage Center, GV-Recording Server GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, and iPod Touch; GV-Eye HD for iPad Live Viewing IE, mobile phone GV-Control Center, GV-Center V2, CMS Server support GV-VSM Note: GV-Backup Center, GV-Video Gateway and GV-Recording Server are only supported for V1.03 or later.

  • Page 612: Specifications: Vandal Proof Ip Dome (Part 2)

    Specifications: Vandal Proof IP Dome (Part 2) Specifications: Vandal Proof IP Dome (Part 2) This section details the specifications on GV-VD1530 / 1540 / 1540-E / 2430 / 2440 / 2440-E / 2530 / 2540 / 2540-E / 3430 / 3440 / 3440-E / 5340 / 5340-E.
  • Page 613 GV-VD2430 GV-VD2440 GV-VD2530 1920 (H) x 1080 (V) GV-VD2540 GV-VD2540-E Picture Elements GV-VD3430 2048 (H) x 1536 (V) GV-VD3440 GV-VD5340 2560 (H) x 1920 (V) GV-VD5340-E Color 0.01 Lux GV-VD1530 0.01 Lux GV-VD1540 IR ON 0 Lux Color 0.08 Lux GV-VD2430 0.05 Lux GV-VD2440...
  • Page 614 Specifications: Vandal Proof IP Dome (Part 2) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic GV-VD1530 55 dB GV-VD1540 GV-VD2430 GV-VD2440 47 dB GV-VD3430 GV-VD3440 S/N Ratio GV-VD2530 GV-VD2540 52 dB GV-VD2540-E GV-VD5340 45 dB GV-VD5340-E GV-VD2430 GV-VD2440 WDR Pro Yes (with WDR sensor) GV-VD3430...
  • Page 615 GV-VD1530 GV-VD2430 Varifocal lens GV-VD2530 GV-VD3430 GV-VD1540 Lens Type GV-VD2440 GV-VD2540 GV-VD2540-E Motorized varifocal lens GV-VD3440 GV-VD5340 GV-VD5340-E GV-VD1530 GV-VD2430 GV-VD2530 GV-VD3430 GV-VD1540 3 ~ 9 mm GV-VD2440 Focal Length GV-VD2540 GV-VD2540-E GV-VD3440 GV-VD5340 3.3 ~ 9 mm GV-VD5340-E Maximum Aperture F/1.2 Mount ø...
  • Page 616 Specifications: Vandal Proof IP Dome (Part 2) GV-VD1530 90° ~ 32° GV-VD1540 GV-VD2430 82° ~ 30° GV-VD2440 GV-VD2530 Horizontal FOV GV-VD2540 103° ~ 36° GV-VD2540-E GV-VD3430 86° ~ 31° GV-VD3440 GV-VD5340 100° ~ 39° GV-VD5340-E GV-VD1530 Focus Manual (w/lock) GV-VD2430 Zoom Manual (w/lock) GV-VD2530...
  • Page 617 GV-VD2430 GV-VD2440 GV-VD3430 20 m (65.6 ft) GV-VD3440 GV-VD5340 Max. IR Distance GV-VD5340-E GV-VD2530 GV-VD2540 25 m (82.0 ft) GV-VD2540-E GV-VD1530 Max. Torque GV-VD2430 0.049 N.m (Focus / Zoom GV-VD2530 Screws) GV-VD3430 Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-VD1530 30 fps at 1280 x 1024 GV-VD1540...
  • Page 618 Specifications: Vandal Proof IP Dome (Part 2) GV-VD5340-E Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Backlight Image Setting Compensation, D/N Sensitivity, Shutter Speed, WDR, Defog, Super Low Lux, Zoom, Focus Change Audio Compression G.711, AAC (Optional) Audio Support Two-Way Audio Sensor Input 1 Input (Dry Contact)
  • Page 619 Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 1280 x 1024, 640 x 512, 320 x 256 GV-VD1530 GV-VD1540 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252...
  • Page 620 Specifications: Vandal Proof IP Dome (Part 2) 640 x 480, 320 x 240 GV-VD5340 Sub Stream 16:9 640 x 360, 448 x 252 GV-VD5340-E 640 x 512, 320 x 256 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF Protocol (Profile S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA...
  • Page 621 Note: SDXC and UHS-I card types are not supported. The TV-Out function only works in 640 x 480 resolution. For TV-Out to work properly, you must set the video resolution to 1280 x 1024 or lower. If both streams are enabled, the Sub Stream must be set to 640 x 480.
  • Page 622 Specifications: Vandal Proof IP Dome (Part 2) GV-VD2540-E Constantly on GV-VD5340-E Humidity 10% to 90% (no condensation) Power Source 12V DC / 24V AC / PoE GV-VD1530 GV-VD2430 15.4 W GV-VD2530 GV-VD3430 GV-VD1540 Max. Power Consumption GV-VD2440 GV-VD2540 22.48 W GV-VD3440 GV-VD5340 GV-VD5340-E...
  • Page 623 GV-VD1530 GV-VD2430 1.76 kg (3.88 lb) GV-VD2530 GV-VD3430 GV-VD1540 Weight GV-VD2440 GV-VD2540 1.83 kg (4.03 lb) GV-VD3440 GV-VD5340 GV-VD5340-E Ingress Protection IP67 IK10+ Vandal Resistance CE, FCC, RCM, RoHS compliant Regulatory Power over Ethernet PoE Standard IEEE 802.3at Power over Ethernet / PD PoE Power Supply Type End-Span PoE Power Output...
  • Page 624 Specifications: Vandal Proof IP Dome (Part 2) Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Picture Access from Web Browser in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian /...

  • Page 625: Specifications: Fixed Ip Dome (Part 1)

    Specifications: Fixed IP Dome (Part 1) This section details the specifications on GV-FD120D / 220D / 320D. Camera GV-FD120D 1/3" progressive scan low lux CMOS Image GV-FD220D Sensor 1/2.5’’ progressive scan CMOS GV-FD320D GV-FD120D 1280 (H) x 1024 (V) Picture GV-FD220D 1920 (H) x 1080 (V) Elements...
  • Page 626 Specifications: Fixed IP Dome (Part 1) Lens Megapixel Day/Night Yes (with removable IR-cut filter) Lens Type Varifocal Focal Length 3 ~ 9 mm F/1.3 ± 5% Maximum Aperture Mount ø 14 mm Image Format 1/3’’ GV-FD120D 86° ~ 32° Horizontal GV-FD220D 82°...
  • Page 627 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Image Setting Orientation, Shutter Speed, Backlight Compensation, D/N Sensitivity, WDR, Defog Audio Compression G.711, AAC (Optional) Audio Support Two-Way Audio Sensor Input 1 Input (Dry Contact) Alarm Output 1 Output (200mA 5V DC) Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes).
  • Page 628 Specifications: Fixed IP Dome (Part 1) 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 640 x 360, Stream 16:9 448 x 252 GV-FD320D 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 629 Connectors TV-Out BNC connector (640 x 480 resolution) LED Indicator 2 LEDs: Power, Status Note: SDXC and UHS-I card types are not supported. The TV-Out function only works in 640 x 480 resolution. For TV-Out to work properly, you must set the video resolution to 1280 x 1024 or lower.
  • Page 630 Specifications: Fixed IP Dome (Part 1) Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change video quality, bandwidth control, image Access from Web snapshot, digital I/O control, audio, Picture in Browser Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch /...

  • Page 631: Specifications: Fixed Ip Dome (Part 2)

    Specifications: Fixed IP Dome (Part 2) This section details the specifications on GV-FD1200 / 1210 / 1500 / 1510 / 2400 / 2410 / 2500 / 2510 / 3400 / 3410 / 5300. Camera GV-FD1200 1/3" progressive scan low lux CMOS GV-FD1210 GV-FD1500 1/3"...
  • Page 632 Specifications: Fixed IP Dome (Part 2) GV-FD3400 2048 (H) x 1536 (V) Picture GV-FD3410 Elements GV-FD5300 2560 (H) x 1920 (V) Color 0.05 GV-FD1200 0.03 Lux GV-FD1210 IR ON 0 Lux Color 0.01 Lux GV-FD1500 0.01 Lux GV-FD1510 IR ON 0 Lux Color 0.02 Lux...
  • Page 633 GV-FD2500 52 dB GV-FD2510 GV-FD2400 S/N Ratio GV-FD2410 47 dB GV-FD3400 GV-FD3410 GV-FD5300 45 dB GV-FD2400 GV-FD2410 WDR Pro GV-FD3400 GV-FD3410 Lens Megapixel Day/Night Yes (with removable IR-cut filter) GV-FD1200 GV-FD1500 GV-FD2400 Varifocal GV-FD2500 GV-FD3400 GV-FD5300 Lens Type GV-FD1210 GV-FD1510 GV-FD2410 Motorized varifocal GV-FD2510...
  • Page 634 Specifications: Fixed IP Dome (Part 2) GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 3 ~ 9 mm Focal GV-FD2410 Length GV-FD2500 GV-FD2510 GV-FD3400 GV-FD3410 GV-FD5300 4.5 ~ 10 mm GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 F/1.2 Maximum GV-FD2410 Aperture GV-FD2500 GV-FD2510 GV-FD3410 GV-FD3400 GV-FD5300 F/1.6...
  • Page 635 GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 ø 14 mm GV-FD2410 Mount GV-FD2500 GV-FD2510 GV-FD3400 GV-FD3410 GV-FD5300 CS Mount GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 1/2.7’’ Image GV-FD2410 Format GV-FD2500 GV-FD2510 GV-FD3400 GV-FD3410 GV-FD5300 1/2.5’’...
  • Page 636 Specifications: Fixed IP Dome (Part 2) GV-FD1200 86° ~ 32° GV-FD1210 GV-FD1500 90° ~ 32° GV-FD1510 GV-FD2400 82° ~ 30° Horizontal GV-FD2410 GV-FD2500 103° ~ 36° GV-FD2510 GV-FD3400 86° ~ 31° GV-FD3410 GV-FD5300 70° ~ 34° GV-FD1200 Focus Manual (w/lock) GV-FD1500 GV-FD2400 Zoom...
  • Page 637 GV-FD1200 15 m (50 ft) GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 Max. IR GV-FD2410 Distance 30 m (98.4 ft) GV-FD3400 GV-FD3410 GV-FD2500 GV-FD2510 GV-FD5300 25 m (82 ft) GV-FD1200 GV-FD1500 Max. Torque GV-FD2400 0.049 N.m (Focus / Zoom GV-FD2500 Screws) GV-FD3400 GV-FD5300 Operation Video Compression H.264, MJPEG...
  • Page 638 Specifications: Fixed IP Dome (Part 2) GV-FD3400 20 fps at 2048 x 1536 GV-FD3410 GV-FD5300 10 fps at 2560 x 1920 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Image Setting Orientation, Shutter Speed, Backlight Compensation, D/N Sensitivity, WDR, Defog, Super Low Lux Audio Compression G.711, AAC (Optional)
  • Page 639 640 x 480, 320 x 240 GV-FD2410 1920 x 1080, 1280 x 720, 16:9 GV-FD2500 Stream 640 x 360, 448 x 252 GV-FD2510 1280 x 1024, 640 x 512, 320 x 256 GV-FD2400 640 x 480, 320 x 240 GV-FD2410 16:9 640 x 360, 448 x 252 Stream...
  • Page 640 Specifications: Fixed IP Dome (Part 2) Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF (Profile S), PSIA, QoS (DSCP), Protocol RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical 0° ~ 350° Camera Angle Tilt 10° ~ 90° Adjustment Rotate 0°...
  • Page 641 General Environment Temperature 0°C ~ 50°C (32°F ~ 122°F) Humidity 10% to 90% (no condensation) Power Source 12V DC / 24V AC / PoE Max. Power Consumption 12 W Dimensions (L X W X H) 155 x 110 mm (6.1” x 4.33”) Weight 580 g (1.28 lb) Vandal Resistance...
  • Page 642 Specifications: Fixed IP Dome (Part 2) Web Interface Installation Web-based configuration Management Maintenance Firmware upgrade through Web Browser or Utility Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital Access from Web I/O control, audio, Picture in Picture, Picture and Browser Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ...

  • Page 643: Specifications: Cube Camera

    Specifications: Cube Camera Camera Image Sensor 1/2.5’’ progressive scan CMOS GV-CB120 1280 (H) x 1024 (V) GV-CBW120 Picture Elements GV-CB220 1920 (H) x 1080 (V) GV-CBW220 Color 0.15 Lux Minimum Illumination 0.10 Lux Automatic, Manual (1/5 ~ 1/8000 sec) Shutter Speed White Balance Automatic, Manual (2800 ~ 8500K) Gain Control...
  • Page 644 Specifications: Cube Camera Image Format 1/3’’ GV-CB120 67° GV-CBW120 Horizontal GV-CB220 77° GV-CBW220 Operation Fixed (Focus / Zoom / Iris) Operation H.264, MJPEG Video Compression Dual streams from H.264 or MJPEG Video Stream GV-CB120 30 fps at 1280 x 1024 GV-CBW120 Frame Rate GV-CB220...
  • Page 645 Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 1280 x 1024, 640 x 512, 320 x 256 GV-CB120 GV-CBW120 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252...
  • Page 646 Regulatory CE, FCC, C-Tick, RoHS compliant IMPORTANT: Be sure to use the GeoVision power adapter to power up the camera. To use your own power cable, make sure you look up the power source value indicated at the camera’s back panel.
  • Page 647 Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change video quality, bandwidth control, image Access from Web snapshot, , audio, Picture in Picture, Picture Browser and Picture, Privacy Mask, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek /...

  • Page 648: Specifications: Advanced Cube Camera

    Specifications: Advanced Cube Camera Specifications: Advanced Cube Camera Camera Image Sensor 1/2.5’’ progressive scan CMOS GV-CA120 1280 (H) x 1024 (V) GV-CAW120 Picture Elements GV-CA220 1920 (H) x 1080 (V) GV-CAW220 Color 0.15 Lux Minimum 0.10 Lux Illumination LED on 0 Lux Automatic, Manual (1/5 ~ 1/8000 sec) Shutter Speed...
  • Page 649 Image Format 1/3’’ GV-CA120 67° GV-CAW120 Horizontal GV-CA220 77° GV-CAW220 Operation Fixed (Focus / Zoom / Iris) Operation H.264, MJPEG Video Compression Dual streams from H.264 or MJPEG Video Stream GV-CA120 30 fps at 1280 x 1024 GV-CAW120 Frame Rate GV-CA220 30 fps at 1920 x 1080 GV-CAW220...
  • Page 650 Specifications: Advanced Cube Camera Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 1280 x 1024, 640 x 512, 320 x 256 GV-CA120 GV-CAW120 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252...
  • Page 651 Mechanical Temperature Detector Power DC Jack / PoE (only for CA120/CA220) Ethernet Ethernet (10/100 Base-T), RJ-45 cable Connectors Audio Built-in speaker & microphone Micro SD card slot Local Storage (SD/SDHC, version 2.0 only, Class 10) LED Indicator 4 LEDs: Status x 3, LAN / Wi-Fi PIR Sensor Built-in White Illumination LED...
  • Page 652 Specifications: Advanced Cube Camera Power over Ethernet IEEE 802.3af Class 3 Power over Ethernet PoE Standard / PD PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance Utility...
  • Page 653 GV-VSM All specifications are subject to change without prior notice...
  • Page 654 Specifications: Advanced Cube Camera Application GV-NVR, GV-System, GV-Backup Center, Network Storage GV-Recording Server GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, and iPod Touch; GV-Eye HD for iPad Live Viewing IE, mobile phone GV-Control Center, GV-Center V2, CMS Server Support GV-VSM All specifications are subject to change without prior notice...

This manual is also suitable for:

Gv-bx130d-0Gv-bx130d-1Gv-bx220d-3Gv-bx320d-0Gv-bx140dwGv-bx320d-1 ... Show all

Table of Contents
