No. Name
10 Ready LED
11 LAN LED
12 Memory Card Slot
IMPORTANT: The White Illumination LED can reach high
temperatures. Be sure not to touch the LED with bare hand.
LED
Live View
Monitoring
Ready
LAN
180
Description
Reflects system status of the camera. See
the below table.
Reflects LAN status of the camera. See the
below table.
Inserts a micro SD/SDHC/SDXC card to
store recording data.
Status Description
• Turns on orange light when
you see the live view.
• Turns on red light when you
start monitoring.
• Turns on green light when the
system is ready.
• Flashes green light when you
load default value.
• Turns on green light when you
connect the LAN Network.
• Turns on blue light when you
connect the Wi-Fi Network (for
GV-CAW120 / 220 only).
