D. Move all the components toward the RJ-45 connector, fit item 4
to item 2, secure item 3 to the camera cable and finally secure
item 5 to item 2 tightly.
Figure 5-11
IMPORTANT: Item 5 must be secured tightly to waterproof the
cable.
7. Access the live view. For details, see 14.1 Accessing the Live View.
8. Adjust the angles based on the live view.
Pan Adjustment
Figure 5-12
5 Mini Fixed & Rugged Dome
59
