Power Connection
There are two ways to supply power to the camera:
•
Use a Power over Ethernet (PoE) adapter to connect the camera to
the network, and the power will be provided at the same time.
•
Use the supplied Terminal Block and power adapter. Follow the steps
below to connect the Terminal Block and the power adapter.
1. Insert the black wire of the data cable to the left pin and the red
wire to the right pin.
Figure 7-10
2. Connect the DC 5V power adapter to the terminal block.
Terminal Block
92
Figure 7-11
DC 12V Power Adaptor
