LAN LED, WAN LED, Monitoring LED: Note this option is only
available in Advanced Cube Camera. Select Disable if you do not
wish to use the LEDs. For details on LED status, see 13.3 Overview.
Alarm LED: Sets the white illumination LED (No. 4, Figure 11-1) in
Advanced Cube Camera. The LED is enabled by default.
Auto: Select Auto for the white illumination LED to illuminate the
scene automatically when the PIR sensor detects any motion
within 5 meters.
Sensitivity: Set the sensitivity for low light detection. The higher
the value, the easier the white illumination LED is to be triggered.
The default value is 5.
The Interval between triggering: Select the duration for the white
illumination LED to light up at full intensity. If a motion persists
over the specified period, the white illumination LED will light up
with less intensity. This option is designed to keep the camera
temperature within its precautious range. The default value is 60
seconds.
Off: Select to disable the white illumination LED.
[Special View Setting]
D/N: Sets the sensitivity of day-night mode switch. The higher the
sensitivity value, the more sensitive the switch is from day mode to
night mode. The default value is 5.
Auto: Select Auto for the camera to detect the amount of light
present and automatically switch to monochrome in a poorly-lit
scene. Move the slider to adjust the sensitivity level from 0 to 10.
Black and White: Select this option for the live view to be in
monochrome.
Color: Select this option for the live view to be in color.
