GeoVision GV-IPCAM User Manual page 156

No. Name
7 Status LED
8 Power LED
9 Focus Ring
10 IR
11 Microphone
12 Default
130
Description
Turns green when the system operates
normally and turns off when system error
occurs.
Turns green when the power is on and
turns off when the power is off.
Manually rotates this ring left or right to
adjust focus.
Turns on to automatically illuminate a
surveillance area by infrared light to
produce clearer images during the night.
Records the sounds.
Resets to system default settings. For
details, see 18.3 Restoring to Factory
Default Settings.
