System Configuration - GeoVision GV-IPCAM User Manual

8.8.8 System Configuration

To configure lens settings, open the VISCA OSD Configuration dialog box
and select System Configure .
Zoom + AF: Automatically focuses after zooming. It is advised to use
this feature with a zooming distance of at least 1 meter.
Digital Zoom: Allows up to 10x Digital Zoom. This function is enabled
after the Optical Zoom level is fully reached Use the drop-down list to
select among off, 2x, 4x, 6x, 8x and 10x.
Load Camera Default: Loads the factory default setting of Iris, White
Balance, Image Reverse and Other in the VISCA OSD Configuration
dialog box (Figure 8-17).
Figure 8-21
8
PTZ Camera
125
