11.5 Connecting the Camera

3
3
2
1. Use a standard network cable to connect the camera to your network.
2. Optionally connect a speaker and an external microphone.
3. Optionally connect a monitor using a Video Out wire. Enable this
function by selecting your signal format at the TV Out field on the
Web interface. See 16.1.1 Video Settings.
4. Optionally connect to input / output devices. For details, see 11.6 I/O
Terminal Block.
5. Connect power using one of the following methods:
•
plugging the supplied power adapter to power port.
•
using the Power over Ethernet (PoE) function and the power will
be provided over the network cable.
6. The status LED of the camera will be on.
166
2 1
Figure 11-20
5
4
