15.2.13 Visual Automation
Note this function is only available for Box Camera, Bullet Camera, Ultra
Bullet Camera, Vandal Proof IP Dome and Fixed IP Dome.
The Visual Automation allows you to change the current state of the
electronic device by simply clicking on its image, e.g. turning the light ON.
This feature is only available when the Visual Automation is set ahead by
the Administrator. For details, see 16.1.6 Visual Automation.
• To access this feature, click the I/O Control button (No. 10, Figure 15-3)
and select Visual Automation.
• To change the style of the set areas, click the green I/O button on the
top left corner. You will have these options:
Show All: Displays all set areas.
Rect Float: Embosses all set areas.
Set Color: Changes the frame color of all set areas
228
Figure 15-17
