No. Name
7 Power LED
8 Auto Iris
Connector
9 DC 12V Port
10 LAN / PoE
11 Default
12 Iris Screw
13 Zoom Screw
14 Microphone
15 Focus Screw
16 Status LED
LED
Power LED turns green
Status LED turns green
Description
Indicates the power is supplied. For detail, see
the table below.
Plug the iris control cable to the connector.
Note that Auto Iris Connector is not functional
in GV-BX1200-0F ~ 2F, GV-BX1300-0F ~ 2F,
GV-BX2400-0F ~ 2F and GV-BX3400-0F ~ 2F.
Connects to power.
Connects to a 10/100 Ethernet or PoE.
Resets all configurations of the GV-IPCAM
H.264 to the default factory settings. See 18.3
Restoring to Factory Default Settings.
Adjusts the iris of the camera.
Adjusts the zoom of the camera.
Records the sounds.
Adjusts the focus of the camera.
Turns on when the unit is ready for use. For
detail, see the table below.
Description
The system powers on and succeeds to boot
up.
The system is ready for use.
