4. Type the user name and password of the camera selected. The
default is admin for both user name and password. This window
appears.
5. For GV-VD120D / 121D, VD-220D / 221D and VD-320D / 321D, hold
the supplied Focus Adjustment Cap over the camera view. For details,
see 14.2.1 Using Focus Adjustment Cap for details.
6. Adjust the Focus Screw and the Zoom Screw of the camera slowly
until the focus value reaches the maximum. For example, the
maximum focus value in Step 4 is 103. For locations of adjustment
screws in each model, see 14.2.2 Locations of Adjustment Screws.
Note:
1. Do not over tighten the screws. The screws only need to be as
tight as your fingers can get them to be. Do not bother using any
tool to get them tighter. Doing so can damage the structure of lens.
2. The maximum focus value may vary when the environment
changes.
Figure 14-9
