3.3 Overview

No. Name
1 Audio Out
2 Default
3 LAN / PoE
4 Microphone
5 Memory Card Slot
6 DC 5V Terminal Block
LED Indicator
Status LED
Power LED
1
2
3
Figure 3-1
Description
Connects a speaker for audio output.
Resets the camera to factory defaults.
See 18.3 Restoring to Factory Default
Settings.
Connects to a 10/100 Ethernet or PoE.
Records sounds.
Inserts a micro SD / SDHC / SDXC card
to store recording data.
Connects to power.
Description
The status LED turns on (green) when the system
is ready for use.
The power LED turns on (green) when power is
supplied to the camera.
3
Ultra Box Camera
4
5
6
31
