7.4.2 Waterproofing the Cable

Waterproof the LAN / PoE cable using the supplied cable connector. The
cable connector can be dissembled into 5 parts:
1
1. Prepare an internet cable with the RJ-45 connector on one end only.
Figure 7-13
2. Connect the internet cable to the LAN / PoE connector (No. 2, Figure
7-1).
3. Paste the sticker to the camera cable and slide in all the components
as shown below.
2 3
Figure 7-12
Figure 7-14
5
4
Ultra Bullet Camera
7
93
