Basic Network Settings

In order to get your IP phones running, you must perform basic network setup, such as IP address and subnet
mask configuration. This section describes how to configure basic network parameters for IP phones.
This section mainly introduces IPv4 network parameters. IP phones also support IPv6. For more information on
IPv6, refer to "IPv6 Support".
DHCP
DHCP (Dynamic Host Configuration Protocol) is a network protocol used to dynamically allocate network
parameters to network hosts. The automatic allocation of network parameters to hosts eases the administrative
burden of maintaining an IP network. IP phones comply with the DHCP specifications documented in RFC 2131. If
using DHCP, IP phones connected to the network become operational without having to be manually assigned IP
addresses and additional network parameters. Static DNS address (es) can be configured and used when DHCP is
enabled.
DHCP Option
DHCP provides a framework for passing information to TCP/IP network devices. Network and other control
information are carried in tagged data items that are stored in the options field of the DHCP message. The data
items themselves are also called options.
DHCP can be initiated by simply connecting the IP phone with the network. IP phones broadcast DISCOVER
messages to request the network information carried in DHCP options, and the DHCP server responds with
specific values in corresponding options.
The following table lists common DHCP options supported by IP phones.
Parameter
Subnet Mask
Time Offset
Router
Time Server
Domain Name Server
Log Server
Host Name
Domain Server
Broadcast Address
Network Time Protocol
Servers
Vendor‐Specific
Information
Vendor Class Identifier
TFTP Server Name
Boot file Name
For more information on DHCP options, refer to,
www.ietf.org/rfc/rfc2132.txt?number=2132.
44
DHCP Option
1 Specify the client's subnet mask.
Specify the offset of the client's subnet in seconds from
2
Coordinated Universal Time (UTC).
3 Specify a list of IP addresses for routers on the client's subnet.
4 Specify a list of time servers available to the client.
6 Specify a list of domain name servers available to the client.
7 Specify a list of MIT‐LCS UDP servers available to the client.
12 Specify the name of the client.
Specify the domain name that client should use when resolving
15
host names via DNS.
28 Specify the broadcast address in use on the client's subnet.
42 Specify a list of NTP servers available to the client by IP address.
43 Identify the vendor‐specific information.
60 Identify the vendor type.
Identify a TFTP server when the 'sname' field in the DHCP header
66
has been used for DHCP options.
Identify a boot file when the 'file' field in the DHCP header has
67
been used for DHCP options.
http://www.ietf.org/rfc/rfc2131.txt?number=2131
Description
