Connected Line Identification Presentation

Parameter-
account.X.cp_source
Description
Format
Default Value
Range
Example
Matrix SPARSH VP110 User Guide
Configuration File
<MAC>.cfg
Configures the presentation of the callee's identity
for account X.
0‐PAI‐RPID (Derives the name and number of the
callee from the "PAI" header preferentially. If the
server does not send the "PAI" header, derives from
the "RPID" header).
1-Dialed Digits (Preferentially displays the dialed
digits on the caller's phone).
2-RFC4916 (Derives the name and number of the
callee from "From" header in the Update message).
When the RFC 4916 is enabled on the IP phone, the
caller sends the SIP request message which contains
the from‐change tag in the Supported header. The
caller then receives an UPDATE message from the
callee, and displays the identity in the From header.
X is 1.
Integer
0
0 to 2
account.1.cp_source = 0
