Failover Mode
Parameter
account.1.sip_server.
Y.failback_mode
(Y ranges from 1 to 2)
account.1.sip_server.
Y.failback_timeout
(Y ranges from 1 to 2.)
account.1.sip_server.
Y.register_on_enable
(Y ranges from 1 to 2.)
• Save the configuration files to the root directory of the provisioning server.
The following shows an example of SIP account and server redundancy configurations for account 1 (since the IP
phone supports single SIP account) in the configuration files:
##Account Configuration and Registration
account.1.enable = 1
account.1.register.enable = 1
account.1.label = 1234
account.1.display_name = 1234
account.1.auth_name = 1234
account.1.user_name = 1234
account.1.password = 1234
128
Valid Values
It configures the mode for the phone to retry
the primary server in failover mode for the
account.
0‐newRequests: all requests are forwarded to
the primary server first, regardless of the last
used server.
1‐DNSTTL: the phone retries to use the
primary server after the timeout of the
0, 1, 2 or 3
DNSTTL configured for the SIP server.
2‐Registration: the phone retries to use the
primary server when the SIP server's
registration requires renewal.
3‐duration: the phone retries to use the
primary server after the timeout defined by
the parameter "account.1.failback_timeout".
The default value is 0.
It configures the timeout (in seconds) for the
phone to retry to use the primary server after
failing over to the current working server for
the account when the parameter
Integer 0, from
"account.1.sip_server.Y.failback_mode" is set
60 to 65535
to 3 (duration).
If you set the parameter between 1 and 59,
the timeout will be 60 seconds.
The default value is 3600.
It enables or disables the phone to send
registration requests to the secondary server
for the account when encountering a failover.
0 or 1
0‐Disabled
1‐Enabled
The default value is 0.
Descriptions
Matrix SPARSH VP110 User Guide
Web Interface Path
NA
NA
NA
