Hardware Component Instructions

The main hardware components of the SPARSH VP110 IP phone are the LCD screen and the keypad.
12
11
10
Hardware component instructions of the IP phone are:
Key Label
1 LCD Screen
2 Power Indicator LED
8
Item
Shows information about calls, messages, soft keys, time,
date and other relevant data:
Indicates phone power status and phone status.
Description
• Call information — caller ID, call duration
• Icons (for example,)
• Missed call text or second incoming caller
information
• Prompt text (for example, "Saving config
file!")
• Time and date
Matrix SPARSH VP110 User Guide
1
2
3
4
5
6
7
8
9
