Function
Other functions

2.2 System Functions

2.2.1. Self-diagnosis

Diagnose CPU, memory, LCD, I/O interface, parameter state, coordinates and processing program
comprehensively every time the system is started or reset; diagnose power supply, principal axis, limits and I/O
ports in real-time during operating.

2.2.2. Compensation

Automatic reverse clearance compensation
Automatic tool length compensation
Automatic tool radius compensation
Automatic tool radius offset and automatic tool tip transition

2.2.3. Abundant Instruction System

Scaling instruction
Mirror processing instruction
Tool biasing instructions
Program cycle, program skip, program shift, program transfer, different end processing modes, macro
definition and program management instructions
Fixed-point instructions: starting point, setting point, etc.
Point punching, arc nibbling, linear nibbling, grid punching, etc.
Six workpiece coordinate systems, nine extension coordinate systems and one reference point
2.2.4. Full Chinese Menu Operation & Full Screen Edit
4640/4620 CNC system uses cascading menu structure and full Chinese operation to ensure simple
operation and visibility.

2.2.5. Abundant Error-correction Functions

Point out the nature and correct the errors in operation.
Name
Reverse clearance compensation
Measurement centering
Automatic tool setting gauge
Specify arc radius R / center position
Electronic gear ratio
ADTECH4 SeriesCNC Maintenance Manual
Yes
Yes
Yes
Yes
Specification
