Default
Effective
time
Note
002
X axis rapid traverse rate (mm/min)
Y axis rapid traverse rate (mm/min)
Z axis rapid traverse rate (mm/min)
4 axes rapid traverse rate (mm/min)
B axis rapid traverse rate (mm/min)
C axis rapid traverse rate (mm/min)
003
X axis start rate (mm/min)
Y axis start rate (mm/min)
Z axis start rate (mm/min)
4 axes start rate (mm/min)
: 1
: Restart
: When screws of different pitches and motors of different step angles or
servo motors of different pulses are matched, or connected through
gears, it allows keeping the program and actual motion distance
consistent through electronic gear ratio setting of the system.
CMR/CMD =P/(L× 1000)
CMR: gear ratio numerator
CMD: gear ratio denominator
P: Pulses corresponding to one rotation of the motor
L: Machine tool movement corresponding to one rotation of the motor
(mm)
CMD/CMR is the pulse equivalent actually, i.e. the motion distance
corresponding to every pulse (unit: 0.001mm).
Ex 1: the motor rotates one cycle every 5000 pulses, and the machine
tool moves 5mm when the motor rotates one cycle, then
CMR/CMD=5000/(5*1000)=1/1
Then, CMR=1, CMD=1, the pulse equivalent is 0.001mm
Ex 2: the motor rotates one cycle every 5000 pulses, and the machine
tool moves 10mm when the motor rotates one cycle, then
CMR/CMD=5000/(10*1000)=1/2
Then, CMR=1, CMD=2, the pulse equivalent is 0.002mm
