1 ECA+
2 ECA-
3 ECB+
4 ECB-
5 ECZ+
6 ECZ-
7 NC
8 NC
9 5V-
10 5V-
11 5V+
12 5V+
13 5V-
14 NC
15 NC
Principal axis encoder wiring diagram (49 series XS10):
ADTECH4 SeriesCNC Maintenance Manual
Encoder phase A input +
Encoder phase A input -
Encoder phase B input +
Encoder phase B input -
Encoder phase Z input + (backup )
Encoder phase Z input - (backup )
Null
Null
Negative end of internal 5V power supply; can't be connected to
external power supply
Negative end of internal 5V power supply; can't be connected to
external power supply
Positive end of internal 5V power supply; can't be connected to
external power supply
Positive end of internal 5V power supply; can't be connected to
external power supply
Negative end of internal 5V power supply; can't be connected to
external power supply
Null
Null
