014
Spindle encoder bits
Range
Unit
Authority
Default
Effective time
Note
021
Spi.Max Speed
Range
Unit
Authority
Default
Effective time
Note
ADTECH4 SeriesCNC Maintenance Manual
the function.
0: variable frequency principal axis adjusted by analog
1~4: for CNC4640(20), corresponding to 1#-4# axis
7: for CNC4960(40), corresponding to independent spindle interface
Note: If a pulse port is specified as the function port of principal axis, the
pulse port should be removed from previously corresponding function
axis number, or else the system will assign to principal axis after restarted
and the original function axis will be invalid.
: 0~5000
: None
: Operation admin
: 2500
: Instant
: The received wire number of the encoder when the principal axis rotates
one circle;
Same as common axis encoder, it can only receive AB phase pulse, and
thus the wire number of the encoder must be pulses of one circle divided
by 4.
This parameter will affect G74 and G84 tap instructions. Please set it
properly.
: 1~30000
: None
: Operation admin
: 24000
: Instant
: This setting is used to calculate the analog output of the controller, and
suppose that the analog of variable frequency control is in linear control
mode;
This method is to set the rotation to this parameter according to the
