Adtech ADTECH4 CNC Series Maintenance Manual page 178

1
IN24
9
IN25
2
IN26
10
IN27
3
IN28
11
IN29
4
IN30
12
IN31
5
IN32
13
IN33
6
HA
14
HB
7
24V-
15
5V-
8
5V+
The definition of 46X series (XS7) follows:
Wire No.
1
2
3
4
5
7
9
10
11
12
13
6
14
15
8
7
Definition
(IN24) gear switch
(IN26) gear switch
(IN28) gear switch
(IN30) button
(IN32) button
24V-
(IN25) axis selection
(IN27) axis selection
(IN29) axis selection
(IN31) axis selection
(IN33) button
HA
HB
5V-
+5V
24V-
ADTECH4 SeriesCNC Maintenance Manual
Function
0.1 gear --- High speed
0.01 gear --- Medium speed
0.001 gear --- Low speed
Cycle start
Pause
Negative pole of internally provided 24V
power supply
X axis
Y axis
Z axis
A axis
Emergency stop
Hand encoder phase A input signal
Hand encoder phase B input signal
Negative pole of internally provided 5V
power supply
Positive pole of internally provided 5V power
supply
Negative pole of internally provided 24V
