Default output port configuration of L series (lathe)

Wire No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
12.2.4.

Handheld box interface

Port Definition Function
OUT0 Principal axis positive rotation (M03)
OUT1 Principal axis reverse rotation (M04)
OUT2 Tool regulator positive rotation output (M18, M19)
Tool regulator reverse rotation & locking output
OUT3
(M20, M21)
OUT4 Cooling (M08, M09)
OUT5 Lubrication (M32, M33)
OUT6 backup output(M12, M13)
OUT7 backup output(M14, M15)
OUT8 Chuck locking (M10)
OUT9 Chuck loosening (M11)
OUT10 backup output(M22, M23)
OUT11 backup output(M24, M25)
OUT12 backup output(M26, M27)
OUT13 backup output(M128, M129)
OUT14 backup output(M130, M131)
OUT15 backup output(M34, M35)
OUT16 backup output(M36, M37)
OUT17 backup output(M38, M39)
OUT18 backup output(M52, M53)
OUT19 backup output(M54, M55)
OUT20 backup output(M56, M57)
OUT21 backup output(M46, M47)
OUT22 backup output(M48, M49)
OUT23 backup output(M50, M51)
OUTGND12V-, 24V- common power supply of
external output
