4 axes pitch compensation end position
B axis pitch compensation end position
C axis pitch compensation end position
Range
Unit
Authority
Default
Effective time
Note

11.4 Management parameter (P3.)

001
Select administrator mode
002
Edit super user password
003
Edit operation user password
Range
Unit
Authority
Default
Effective time
Note
ADTECH4 SeriesCNC Maintenance Manual
: -9999.999 ~ 9999.999
: Mm
: Super admin
: 0
: Instant
: Set the compensation of the end position, corresponding to the machine
coordinate position. This value depends on the measured travel and has
both positive and negative values. To measure pitch compensation from
mechanical zero position to mechanical -110mm position, the value is set
to -110mm; to measure from mechanical zero position to mechanical 110,
the value is set to 110mm. After setting the starting position and end
position, the mechanical coordinate position of the system trajectory only
compensates the pitch error in this region.
: None
: None
: None
: None
: Instant
In this menu, type the password and press 'Insert'. If the password is
:
valid, the system will enter this user mode;
After entering, this menu will turn into "Exit XXX admin mode",
indicating entering successfully;
In the new menu, press the Insert key to exit the admin mode. To modify
the parameter table at this moment, you need to enter the admin mode
