Adtech ADTECH4 CNC Series Maintenance Manual page 169

No.
1 IN0 (X_LMT+)
2 IN1 (X_LMT-)
3 IN2 (Y_LMT+)
4 IN3(Y_LMT-)
5 IN4(Z_LMT+)
6 IN5(Z_LMT-)
7 IN6 (A_LMT+)
8 IN7 (A_LMT-)
9 INCOM1
10 IN8 (X_STOP0)
11 IN9 (Y_STOP0)
12 IN10 (Z_STOP0)
13 IN11 (A_STOP0)
14 IN12 (B_STOP0)
15 IN13 (C_STOP0)
16 IN14
17 IN15
18 INCOM2
ADTECH4 SeriesCNC Maintenance Manual
X axis positive
limit
X axis negative
limit
Y axis positive
limit
Y axis negative
limit
Z axis positive
limit
Z axis negative
limit
A axis positive
limit
A axis negative
limit
Input common
terminal (24v+,
12v+)
X axis zero point
Y axis zero point
Z axis zero point
A axis zero point
B axis zero point
C axis zero point
Backup input
Backup input
Input common
terminal (24v+,
12v+)
IN00
IN01
IN02
IN03
IN04
IN05
IN06
IN07
+24V
IN08
IN09
IN10
IN11
IN12
IN13
IN14
IN15
+24V
