009
Spi.Pulse Mode
010
Spi.Pulse Logic Mode
011
Spi.HomeDect ELevel
012
Spi.ExtHome Check En
013
Spi.Round Setting (restart)
015
Spi.ZeroOffset(p)
016
Spi.PulseLogic Level
017
Spi.Rolling Display Usage
018
Spi.Max Acc(Kpps)
019
Spi.Ext HomeDir
020
Spi.Servo HomeDir
022
Spi.Home Speed(rpm)
025
Spindle encoder logic direction
Range
Unit
Authority
Default
Effective time
Note
001 Spindle physical Assign Num (restart)
Range
Unit
Authority
Default
Effective time
Note
ADTECH4 SeriesCNC Maintenance Manual
:
:
: Operation admin
:
:
: Servo principal axis parameters are same as common positioning axis
parameters. If only the principal axis is controlled with servo port, you
can set the number according to axis parameters.
: 0~7
: Pulse port sequence No.
: Super admin
:
: Restart
: It is set to 0 by default, indicating that the principal axis is in variable
frequency control mode, i.e. analog or gear position control mode. To use
servo principal axis, a coding port is required (servo principal axis must
be in position control mode); you can modify this parameter to specify
