022 X axis specified interface axis No. (restart)
Y axis specified interface axis No. (restart)
Z axis specified interface axis No. (restart)
4 axes specified interface axis No. (restart)
B axis specified interface axis No. (restart)
C axis specified interface axis No. (restart)
Range
Unit
Authority
Default
Effective time
Note
023 X axis encoder wire number
ADTECH4 SeriesCNC Maintenance Manual
This function is used to prevent the logic counting of axis exceeding the
maximum counting range (2147483648) and causing overflow error;
Generally, overflow occurs only when the axis is set to rotary. The
system will calculate the corresponding pulse limit according to the gear
ratio of current axis and assign to the ROUND parameter of
corresponding axis, if current axis is set to rotary and uses 360° display
mode after the system getting P2.062~P2.069 parameters. The user can
check the change of this parameter when the rotary axis display function
is enabled. The user can modify the changed parameters, and the finally
displayed number will be effective.
This parameter requires restart to take effect; the corresponding axis must
be rotary and set to 360° display (P2.062~069);
: 0~4
: Pulse port sequence No.
: Super admin
:
: Restart
: In default mode, the actual number of every axis corresponds to the silk
screen number on the shell. If certain function axis is abnormal, you can
replace the axis through this function. For example, set P2.045 to 4,
P2.048 to 1, then, any operation to X axis will be the operation to A axis
encoder port on the shell.
0: no such axis
1~6: corresponding to 1#-6# axis
